110360 - Alternator (110360)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.


Voltage: 14,
Amp: 45,
Bracket Hole: 8.00, Belt. adj. bracket hole 8.00,
Width/Holder Arm: 56.00, Belt. adj. brackethole pos. 5,
Radius: 80.00,
Radius: 86.00,
B+ Position: 9.40,
Rotation: CR,
Regulator Plug: or plug PL22,
Blower: w/o, Pulley w/o,
Total Length: 154.00, Source Mahle Letrika

Electrical specifications (Alternator)
Voltage 14
Amp 45

Physical specifications (Alternator)
D Bracket hole 8.00
G Belt. adj. bracket hole 8.00
B Width/holder arm 56.00
E Belt. adj. brackethole pos. 5
j Radius 80.00
j Radius 86.00
k B+ position 9.40
n Rotation CR
o Regulator plug PL22
R Total length 154.00
Source Mahle Letrika

Further information (Alternator)
Blower w/o
Pulley w/o

Replacing
0120489012 BOSCH
0120489013 BOSCH
0120489076 BOSCH
0120489557 BOSCH
0120489558 BOSCH
0120489581 BOSCH
0120489744 BOSCH
0120489745 BOSCH
0120489791 BOSCH
0120489799 BOSCH

UNISTART Price: £109.41

Sorry, this item is out of stock.

The 110360 - Alternator is shown in: Brands > 5 Star , Automotive > Starters & Alternators , Agriculture > Starters & Alternators.

Fast Delivery - UK & Europe

We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.

You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us.  Replacements & refunds will be dispatched / issued on receipt of the returned items only.

Mfg. Model Engine Size Fuel From To KW HP Volume Cylinders Engine Type Brand Chassis Model Type Series
VW, Passenger Car EU Polo 1.1 Gasoline 1975 03 1981 09 37 50 1093 4 HB Hatchback Polo
VW, Passenger Car EU Derby 1.1 Gasoline 1977 02 1981 09 37 50 1093 4 HB Derby
VW, Passenger Car EU Polo 1 Gasoline 1981 10 1986 10 29 40 1043 4 GL Hatchback Polo
VW, Passenger Car EU Derby 1.1 Gasoline 1981 10 1983 07 37 50 1093 4 HB Derby
VW, Passenger Car EU Derby 1.3 Gasoline 1983 08 1984 12 40 55 1272 4 HK Derby
VW, Passenger Car EU Derby 1.3 Gasoline 1981 08 1983 07 44 60 1272 4 HH Derby
VW, Passenger Car EU Golf 1.1 Gasoline 1974 04 1983 07 37 50 1093 4 FA Hatchback Golf I
VW, Passenger Car EU Golf 1.1 Gasoline 1974 04 1983 07 37 50 1093 4 GG Hatchback Golf I
VW, Passenger Car EU Golf 1.5 Gasoline 1977 08 1983 07 51 70 1457 4 JB Hatchback Golf I
VW, Passenger Car EU Golf 1.5 Diesel 1976 08 1980 07 37 50 1471 4 Diesel CK Hatchback Golf I
VW, Passenger Car EU Golf 1.6 Diesel 1980 08 1983 07 40 54 1588 4 Diesel CR Hatchback Golf I
VW, Passenger Car EU Jetta 1.1 Gasoline 1978 08 1984 02 37 50 1093 4 GG Jetta
VW, Passenger Car EU K 70 1.8 Gasoline 1973 08 1974 10 74 100 1807 4 DC K 70
VW, Passenger Car EU Polo 1.3 Gasoline 1981 10 1983 07 44 60 1272 4 HH Coupe Polo
VW, Passenger Car EU Caddy 1.6 Diesel 1982 08 1992 07 40 55 1588 4 Diesel JK Pick Up Caddy
VW, Passenger Car EU Transporter 1.6 Diesel 1981 01 1987 07 37 50 1588 4 Diesel CS Van T3 Transporter
VW, Passenger Car EU Derby 1.3 Gasoline 1982 09 1984 12 55 75 1272 4 GK Derby
VW, Passenger Car EU Polo 0.8 Gasoline 1975 09 1981 09 25 34 771 4 HE Hatchback Polo
VW, Passenger Car EU Golf 1.3 Gasoline 1982 08 1983 12 43 58 1272 4 GS Hatchback Golf I
VW, Passenger Car EU Transporter 1.6 Diesel 1981 01 1987 07 37 50 1588 4 Diesel CS Bus T3 Transporter
VW, Passenger Car EU Passat 1.3 Gasoline 1980 08 1986 07 44 60 1272 4 FZ Estate Passat
VW, Passenger Car EU Passat 1.3 Gasoline 1973 05 1980 07 40 55 1272 4 FY Estate Passat
VW, Passenger Car EU Derby 1.3 Gasoline 1977 02 1981 09 44 60 1272 4 HH Derby
VW, Passenger Car EU Polo 1.3 Gasoline 1989 10 1991 03 55 75 1272 4 3F Hatchback Polo
VW, Passenger Car EU Golf 1.6 Diesel 1980 08 1983 07 40 54 1588 4 Diesel JK Hatchback Golf I
VW, Passenger Car EU Golf 1.6 Diesel 1982 03 1983 07 51 70 1588 4 TD CY Hatchback Golf I
VW, Passenger Car EU Jetta 1.6 Diesel 1982 03 1984 02 51 70 1588 4 TD CY Jetta
VW, Passenger Car EU Passat 1.3 Gasoline 1973 05 1980 07 40 55 1272 4 FY Hatchback Passat
VW, Passenger Car EU Passat 1.3 Gasoline 1980 08 1983 07 40 55 1272 4 FY Hatchback Passat
VW, Passenger Car EU Passat 1.3 Gasoline 1980 08 1986 07 44 60 1272 4 FZ Hatchback Passat
VW, Passenger Car EU Caddy 1.6 Diesel 1982 08 1992 07 40 55 1588 4 Diesel ME Pick Up Caddy
VW, Passenger Car EU Polo 1 Gasoline 1985 01 1986 10 29 40 1043 4 GL Polo
VW, Passenger Car EU Polo 1.3 Gasoline 1982 09 1989 09 55 75 1272 4 GK Coupe Polo
VW, Passenger Car EU Polo 1.3 Gasoline 1982 08 1988 07 43 58 1272 4 HJ Hatchback Polo
VW, Passenger Car EU Polo 1.3 Gasoline 1989 10 1994 09 55 75 1272 4 3F Coupe Polo
VW, Passenger Car EU Polo 1.1 Gasoline 1981 10 1989 09 37 50 1093 4 HB Hatchback Polo
VW, Passenger Car EU Polo 1.3 Gasoline 1981 10 1983 07 44 60 1272 4 HH Hatchback Polo
VW, Passenger Car EU Jetta 1.6 Diesel 1980 08 1984 02 40 54 1588 4 Diesel CR Jetta
VW, Passenger Car EU Caddy 1.6 Gasoline 1983 01 1992 07 55 75 1595 4 EW Pick Up Caddy
VW, Passenger Car EU Polo 1.3 Gasoline 1987 07 1994 09 40 55 1272 4 MH Polo
VW, Passenger Car EU Polo 1.3 Gasoline 1983 08 1988 07 55 54 1272 4 HK Hatchback Polo
VW, Passenger Car EU Polo 1.3 Gasoline 1985 01 1987 07 55 54 1272 4 HK Polo
VW, Passenger Car EU Polo 1.3 Gasoline 1983 08 1985 07 37 50 1272 4 HW Hatchback Polo
VW, Passenger Car EU Santana 1.3 Gasoline 1981 08 1983 07 44 60 1272 4 FZ Santana
VW, Passenger Car EU Scirocco 1.3 Gasoline 1979 08 1980 07 44 60 1272 4 GF Coupe Scirocco
VW, Passenger Car EU Polo 0.9 Gasoline 1975 09 1981 09 29 40 895 4 HA Hatchback Polo
VW, Passenger Car EU Polo 1.3 Gasoline 1976 12 1981 09 44 60 1272 4 HH Hatchback Polo
VW, Passenger Car EU Derby 0.9 Gasoline 1977 02 1981 09 29 40 895 4 HA Derby
VW, Passenger Car EU Derby 1 Gasoline 1981 10 1984 12 29 40 1043 4 GL Derby
VW, Passenger Car EU K 70 1.6 Gasoline 1970 08 1974 10 66 90 1605 4 DA K 70
VW, Passenger Car EU Polo 0.9 Gasoline 1981 10 1981 12 29 39 895 4 HA Hatchback Polo
VW, Passenger Car EU Transporter 1.6 Diesel 1981 01 1987 07 37 50 1588 4 Diesel CS Platform / Chassis T3 Transporter
VW, Passenger Car EU Polo 1.3 Gasoline 1982 08 1988 07 43 58 1272 4 GT Coupe Polo Classic
VW, Passenger Car EU Polo 1.1 Gasoline 1975 03 1981 09 44 60 1093 4 HC Hatchback Polo
VW, Passenger Car EU Golf 1.3 Gasoline 1979 08 1983 07 44 60 1272 4 GF Hatchback Golf I
VW, Passenger Car EU Jetta 1.3 Gasoline 1979 08 1984 02 44 60 1272 4 GF Jetta
VW, Passenger Car EU Jetta 1.6 Diesel 1980 08 1984 02 40 54 1588 4 Diesel JK Jetta
VW, Passenger Car EU Passat 1.3 Gasoline 1980 08 1986 07 44 60 1272 4 EU Hatchback Passat
VW, Passenger Car EU Scirocco 1.3 Gasoline 1980 08 1983 12 44 60 1272 4 GF Coupe Scirocco
VW, Passenger Car EU Passat 1.3 Gasoline 1980 08 1983 07 40 55 1272 4 FY Estate Passat
VW, Passenger Car EU Polo 1 Gasoline 1982 05 1986 10 29 40 1043 4 GL Coupe Polo
VW, Passenger Car EU Polo 1.1 Gasoline 1981 10 1983 07 37 50 1093 4 HB Coupe Polo
VW, Passenger Car EU Polo 1.3 Gasoline 1983 08 1987 06 55 54 1272 4 HK Coupe Polo
VW, Passenger Car EU Polo 1.3 Gasoline 1985 08 1988 07 55 54 1272 4 MH Hatchback Polo
VW, Passenger Car EU Polo 1.3 Gasoline 1982 09 1989 09 55 75 1272 4 GK Hatchback Polo
VW, Passenger Car EU Derby 1.3 Gasoline 1977 02 1981 09 43 58 1272 4 HJ Derby
VW, Passenger Car EU Jetta 1.3 Gasoline 1982 08 1984 02 43 58 1272 4 GS Jetta
Deutz-Fahr, Agricultural D Series 3.8 Diesel 1986 06 - 0 0 3770 4 Diesel F4L912 D 6807
Deutz-Fahr, Agricultural DX - - 0 0 0 DX4 - Various Models
Deutz-Fahr, Agricultural D Series 1.9 Diesel 1986 06 - 0 0 1890 2 Diesel F2L912 D 2807
Deutz-Fahr, Agricultural D Series 1.9 Diesel 1986 06 - 0 0 1890 2 Diesel F2L912 D 3607
Deutz-Fahr, Agricultural DX 3.8 Diesel 1986 06 - 0 0 3770 4 Diesel F4L912 DX 4.10
Deutz-Fahr, Agricultural DX 4.1 Diesel 1990 01 - 0 0 4068 4 Diesel BF4L913 DX 4.51
Deutz-Fahr, Agricultural M Series 4.7 Diesel 1981 01 - 0 0 4712 5 Diesel F5L912 M 1080
Deutz-Fahr, Agricultural M Series 5.7 Diesel 1980 01 - 0 0 5655 6 Diesel F6L912 M 1202
Deutz-Fahr, Agricultural DX - - 0 0 0 DE6 - Various Models
Deutz-Fahr, Agricultural DX 4.1 Diesel 1991 01 - 0 0 4086 4 Diesel F4L913 DX 4.31
Deutz-Fahr, Agricultural DX - - 0 0 0 DX7 - Various Models
Deutz-Fahr, Agricultural DX 4.1 Diesel 1986 06 - 0 0 4086 4 Diesel F4L913 DX 3.80
Deutz-Fahr, Agricultural DX 5.7 Diesel 1986 06 - 0 0 5655 6 Diesel F6L912 DX 6.05
Deutz-Fahr, Agricultural D Series 3.8 Diesel 1986 06 - 0 0 3770 4 Diesel F4L912 D 7007
Deutz-Fahr, Agricultural DX 6 Diesel 1988 10 - 0 0 6128 6 Diesel BF6L913 DX 6.60
Deutz-Fahr, Agricultural DX - - 0 0 0 DX3 - Various Models
Deutz-Fahr, Agricultural DX 3.8 Diesel 1986 06 - 0 0 3770 4 Diesel F4L912 DX 4.10
Deutz-Fahr, Agricultural DX 4.1 Diesel 1990 01 - 0 0 4068 4 Diesel BF4L913 DX 4.51
Deutz-Fahr, Agricultural DX 4.1 Diesel 1986 06 - 0 0 4086 4 Diesel F4L913 DX 3.80
Deutz-Fahr, Agricultural DX 4.1 Diesel 1991 01 - 0 0 4086 4 Diesel F4L913 DX 4.31
Deutz-Fahr, Agricultural DX 5.7 Diesel 1986 06 - 0 0 5655 6 Diesel F6L912 DX 6.05
Deutz-Fahr, Agricultural DX 6 Diesel 1988 10 - 0 0 6128 6 Diesel BF6L913 DX 6.60
Audi, Passenger Car EU 50 1.1 Gasoline 1974 08 1977 07 44 60 1093 4 HC Hatchback 50
Audi, Passenger Car EU 80 1.3 Gasoline 1978 09 1986 07 44 60 1297 4 FZ 80
Audi, Passenger Car EU 50 1.1 Gasoline 1974 08 1978 07 37 50 1093 4 HB Hatchback 50
Audi, Passenger Car EU 50 1.3 Gasoline 1977 08 1978 07 44 60 1272 4 HH Hatchback 50
Audi, Passenger Car EU 80 1.3 Gasoline 1978 09 1981 07 40 55 1272 4 FY 80
