110611 - Alternator (110611)
Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.
Voltage: 14,
Amp: 55,
Bracket Hole: 12.20, Belt. adj. bracket hole 11.00,
Width/Holder Arm: 17.00, Belt. adj. brackethole pos. 60,
Mount. Bracket Dist.: 65.00,
Pulley Dia.: 69.00,
Pulley Dist.: 48.00,
Grooves/Pulley: 1,
Radius: >85,
Radius: 81.00,
B+ Position: M6,
Rotation: CR,
Regulator Plug: or plug PL_NA,
Blower: EF, Pulley P, Remarks
Regulator Plug: or: HC-CARGO 130613.,
Total Length: 175.00
Electrical specifications (Alternator) | ||||
| Voltage | 14 | |||
| Amp | 55 | |||
Physical specifications (Alternator) | ||||
| D | Bracket hole 12.20 | |||
| G | Belt. adj. bracket hole 11.00 | |||
| B | Width/holder arm 17.00 | |||
| E | Belt. adj. brackethole pos. 60 | |||
| C | Mount. bracket dist. 65.00 | |||
| H | Pulley dia. 69.00 | |||
| A | Pulley dist. 48.00 | |||
| i | Grooves/pulley 1 | |||
| j | Radius >85 | |||
| j | Radius 81.00 | |||
| k | B+ position M6 | |||
| n | Rotation CR | |||
| o | Regulator plug PL_NA | |||
| R | Total length 175.00 | |||
Further information (Alternator) | ||||
| Blower | EF | |||
| Pulley | P | |||
| Remarks | Regulator: HC-CARGO 130613. | |||
Replacing | ||||
| 19025037 | REMY (DELCO) | |||
| 3370000 | ELMOT | |||
| 4152101 | FIAT | |||
| 4166213 | FIAT | |||
| 4174626 | FIAT | |||
| 4242498 | FIAT | |||
| 4329019 | FIAT | |||
| 4474903 | FIAT | |||
| 4474904 | FIAT | |||
| 4475303 | FIAT | |||
UNISTART Price: £74.23
Fast Delivery - UK & Europe
We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.
You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us. Replacements & refunds will be dispatched / issued on receipt of the returned items only.
| Mfg. | Model | Engine Size | Fuel | From | To | KW | HP | Volume | Cylinders | Engine Type | Brand | Chassis | Model Type | Series |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Fiat, Passenger Car EU | 124 | 1.4 | Gasoline | 1973 01 | 1975 07 | 55 | 75 | 1438 | 4 | 124B2.000 | 1400 Special | 124 | ||
| Fiat, Passenger Car EU | 124 | 1.6 | Gasoline | - | 1973 08 | 74 | 100 | 1592 | 4 | 132AC.000 | Convertible | 1600 Sport | 124 | |
| Fiat, Passenger Car EU | 124 | 1.4 | Gasoline | - | 1972 12 | 51 | 70 | 1438 | 4 | 124B2.000 | 1400 Special | 124 | ||
| Fiat, Passenger Car EU | 230 | 1.4 | Gasoline | 1976 06 | 1982 06 | 38 | 52 | 1440 | 4 | 131AZ000 | Bus | 238-Series | ||
| Fiat, Passenger Car EU | 124 | 1.6 | Gasoline | - | 1974 12 | 80 | 108 | 1592 | 4 | 132AC.000 | Convertible | 1600 Sport | 124 | |
| Fiat, Passenger Car EU | 130 | 3.2 | Gasoline | 1971 10 | 1978 03 | 121 | 165 | 3235 | 6 | 130B.000 | Coupe | 3200 | 130 | |
| Fiat, Passenger Car EU | 124 | 1.6 | Gasoline | - | 1973 08 | 82 | 110 | 1608 | 4 | 132AC.000 | Convertible | 1600 Spider Sport | 124 | |
| Fiat, Passenger Car EU | 130 | 3.2 | Gasoline | 1971 12 | 1978 03 | 121 | 165 | 3235 | 6 | 130B.000 | 3200 | 130 | ||
| Fiat, Passenger Car EU | 124 | 1.4 | Gasoline | 1971 01 | 1975 07 | 59 | 80 | 1438 | 4 | 132A.000 | 1400 Special T | 124 | ||
| Fiat, Passenger Car EU | 124 | 1.6 | Gasoline | - | 1974 12 | 76 | 104 | 1592 | 4 | 132AC.000 | Convertible | 1600 Sport | 124 | |
| Fiat, Passenger cars US | 124 | 1.6 | Gasoline | 1971 01 | 1973 01 | 0 | 0 | 1608 | L4 | 124 | ||||
| Fiat, Passenger cars US | 124 | 1.4 | Gasoline | - | 1973 01 | 0 | 0 | 1438 | L4 | 124 | ||||
| Fiat, Passenger cars US | 124 | 1.4 | Gasoline | - | 1970 01 | 0 | 0 | 1438 | L4 | Spider | 124 | |||
| Fiat, Passenger cars US | 124 | 1.4 | Gasoline | - | - | 0 | 0 | 1438 | L4 | 124 | ||||
| Fiat, Passenger cars US | 124 | 1.8 | Gasoline | 1974 01 | 1975 01 | 0 | 0 | 1756 | L4 | 124 | ||||
| Fiat, Passenger cars US | 124 | 1.6 | Gasoline | 1971 01 | 1973 01 | 0 | 0 | 1608 | L4 | Spider | 124 | |||
| Fiat, Passenger cars US | 124 | 1.4 | Gasoline | - | - | 0 | 0 | 1438 | L4 | Spider | 124 | |||
| Fiat, Passenger cars US | 124 | 1.2 | Gasoline | - | - | 0 | 0 | 1197 | L4 | 124 | ||||
| Fiat, Passenger cars US | 124 | 1.8 | Gasoline | 1974 01 | 1978 01 | 0 | 0 | 1756 | L4 | Spider | 124 | |||
| Seat, Passenger Car EU | 127 | 0.9 | Gasoline | 1972 04 | 1982 12 | 33 | 45 | 903 | 4 | Hatchback | 127 |
