110641 - Alternator (110641)
Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.
Voltage: 14,
Amp: 33, Terminal W,
Bracket Hole: 8.00, Belt. adj. bracket hole 8.00,
Width/Holder Arm: 56.00, Belt. adj. brackethole pos. 50,
Pulley Dia.: 76.00,
Pulley Dist.: 76.50,
Grooves/Pulley: 1,
Radius: 86.00,
Radius: 79.00,
B+ Position: M6,
Rotation: CR,
Regulator Plug: or plug PL_NA,
Blower: EF, Pulley P,
Total Length: 162.00
Electrical specifications (Alternator) | ||||
| Voltage | 14 | |||
| Amp | 33 | |||
| Terminal | W | |||
Physical specifications (Alternator) | ||||
| D | Bracket hole 8.00 | |||
| G | Belt. adj. bracket hole 8.00 | |||
| B | Width/holder arm 56.00 | |||
| E | Belt. adj. brackethole pos. 50 | |||
| H | Pulley dia. 76.00 | |||
| A | Pulley dist. 76.50 | |||
| i | Grooves/pulley 1 | |||
| j | Radius 86.00 | |||
| j | Radius 79.00 | |||
| k | B+ position M6 | |||
| n | Rotation CR | |||
| o | Regulator plug PL_NA | |||
| R | Total length 162.00 | |||
Further information (Alternator) | ||||
| Blower | EF | |||
| Pulley | P | |||
Replacing | ||||
| 01163985 | KHD | |||
| 01171617 | KHD | |||
| 01177481 | KHD | |||
| 0120300514 | BOSCH | |||
| 0120339514 | BOSCH | |||
| 0120339531 | BOSCH | |||
| 0120339552 | BOSCH | |||
| 11.201.027 | ISKRA | |||
| 11.201.096 | ISKRA | |||
| 11.201.372 | ISKRA | |||
UNISTART Price: £65.79
Fast Delivery - UK & Europe
We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.
You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us. Replacements & refunds will be dispatched / issued on receipt of the returned items only.
| Mfg. | Model | Engine Size | Fuel | From | To | KW | HP | Volume | Cylinders | Engine Type | Brand | Chassis | Model Type | Series |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Deutz-Fahr, Agricultural | D Series | 3.8 | Diesel | 1986 06 | - | 0 | 0 | 3770 | 4 | Diesel | F4L912 | D 6807 | ||
| Deutz-Fahr, Agricultural | Intrac | 3.8 | Diesel | 1978 05 | 1988 12 | 51 | 69 | 3770 | 4 | F4L912 | 2004 | |||
| Deutz-Fahr, Agricultural | D Series | 1.9 | Diesel | 1986 06 | - | 0 | 0 | 1890 | 2 | Diesel | F2L912 | D 2807 | ||
| Deutz-Fahr, Agricultural | D Series | 1.9 | Diesel | 1986 06 | - | 0 | 0 | 1890 | 2 | Diesel | F2L912 | D 3607 | ||
| Deutz-Fahr, Agricultural | M Series | 4.7 | Diesel | 1981 01 | - | 0 | 0 | 4712 | 5 | Diesel | F5L912 | M 1080 | ||
| Deutz-Fahr, Agricultural | M Series | 5.7 | Diesel | 1980 01 | - | 0 | 0 | 5655 | 6 | Diesel | F6L912 | M 1202 | ||
| Deutz-Fahr, Agricultural | Intrac | 3.8 | Diesel | 1974 09 | 1980 05 | 44 | 60 | 3770 | 4 | F4L 912 | 2003 | |||
| Deutz-Fahr, Agricultural | D Series | 3.8 | Diesel | 1986 06 | - | 0 | 0 | 3770 | 4 | Diesel | F4L912 | D 7007 | ||
| Deutz-Fahr, Agricultural | M Series | 3.8 | Diesel | 1981 01 | - | 0 | 0 | 3770 | 4 | Diesel | F4L912 | M 980 | ||
| Deutz-Fahr, Agricultural | DX | - | - | 0 | 0 | 0 | DX3 - Various Models | |||||||
| Deutz-Fahr, Agricultural | D Series | - | - | 0 | 0 | 0 | Various Models | |||||||
| Case, Agricultural | 900 Series | - | - | 0 | 0 | 0 | 946 | |||||||
| Case, Agricultural | 300 Series | 1976 10 | - | 0 | 0 | 0 | 321 | |||||||
| Case, Agricultural | 500 Series | 1976 10 | - | 0 | 0 | 0 | 554 | |||||||
| Case, Agricultural | 800 Series | 1974 01 | 1990 12 | 0 | 0 | 0 | 844 | |||||||
| Case, Agricultural | 1000 Series | - | - | 0 | 0 | 0 | 1000 | |||||||
| Case, Agricultural | 400 Series | - | - | 0 | 0 | 0 | 431 | |||||||
| Case, Agricultural | 400 Series | 1976 10 | - | 0 | 0 | 0 | 421 | |||||||
| Case, Agricultural | 500 Series | 1976 10 | - | 0 | 0 | 0 | 531 | |||||||
| Case, Agricultural | 600 Series | 1976 10 | - | 0 | 0 | 0 | 644 | |||||||
| Case, Agricultural | 700 Series | - | - | 0 | 0 | 0 | 744 | |||||||
| Case, Agricultural | 300 Series | 1976 10 | - | 0 | 0 | 0 | 321 | |||||||
| Goldoni, Agricultural | Cingolato | 2 | Diesel | 1991 04 | - | 34 | 46 | 2082 | 3 | Diesel | VM-RA 394 | Cingolato C45 | ||
| Goldoni, Agricultural | Cingolato | 3 | Diesel | 1991 04 | - | 49 | 0 | 2985 | 3 | Diesel | VM-SUN 3105 | Cingolato C60 | ||
| Goldoni, Agricultural | Transcar | 2 | Diesel | 1990 11 | - | 33 | 45 | 2082 | 3 | Diesel | VM-RA 394 | 60 | ||
| Goldoni, Agricultural | 3000 | 2.1 | Diesel | 1990 06 | 1991 06 | 43 | 58 | 2082 | 3 | Diesel | VM-RA 394 | 3070 | ||
| Goldoni, Agricultural | 3000 | 1.8 | Diesel | 1986 04 | 1991 06 | 31 | 42 | 1794 | 3 | Diesel | VM-RA 394 | 3050 | ||
| Goldoni, Agricultural | 1000 | 1.8 | Diesel | 1987 03 | 1990 04 | 31 | 42 | 1794 | 3 | Diesel | VM-RA 394 | 1055 |
TEST & REPAIR SERVICE
Unistart has its own workshops for remanufacturing with the latest testing equipment. This enables us to provide an excellent (and free) technical helpline and aftersales support and backup service.
You can speak to one of our friendly and knowledgeable technicians who will be glad to Help with any enquiries no matter how large or small. Call us on 020 8 983 9969.
