110682 - Alternator (110682)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.


Voltage: 14,
Amp: 70,
Bracket Hole: 10.35, Belt. adj. bracket hole M8,
Width/Holder Arm: 58.00, Belt. adj. brackethole pos. 55,
Pulley Dia.: 57.50,
Pulley Dist.: 87.50,
Grooves/Pulley: 5,
Radius: 79.60,
Radius: 82.70,
B+ Position: M6,
Rotation: CR,
Regulator Plug: or plug PL12,
Blower: IF, Pulley SP,
Total Length: 160.00

Electrical specifications (Alternator)
Voltage 14
Amp 70

Physical specifications (Alternator)
D Bracket hole 10.35
G Belt. adj. bracket hole M8
B Width/holder arm 58.00
E Belt. adj. brackethole pos. 55
H Pulley dia. 57.50
A Pulley dist. 87.50
i Grooves/pulley 5
j Radius 79.60
j Radius 82.70
k B+ position M6
n Rotation CR
o Regulator plug PL12
R Total length 160.00

Further information (Alternator)
Blower IF
Pulley SP

Replacing
100211-3350 DENSO
100211-3351 DENSO
100211-3352 DENSO
100211-7000 DENSO
100211-7001 DENSO
100211-7050 DENSO
100211-7051 DENSO
100211-7052 DENSO
100211-8030 DENSO
100211-8031 DENSO

UNISTART Price: £97.00

Sorry, this item is out of stock.

The 110682 - Alternator is shown in: Starters & Alternators > Alternators , Automotive > Starters & Alternators.

Fast Delivery - UK & Europe

We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.

You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us.  Replacements & refunds will be dispatched / issued on receipt of the returned items only.

Mfg. Model Engine Size Fuel From To KW HP Volume Cylinders Engine Type Brand Chassis Model Type Series
Toyota, Passenger Car EU Carina 1.6 Gasoline 1987 12 1992 03 75 102 1587 4 4A-FE Hatchback Carina
Toyota, Passenger Car EU Carina 1.6 Gasoline 1987 12 1992 03 72 98 1587 4 4A-FE Estate Carina
Toyota, Passenger Car EU Corolla 1.6 Gasoline 1988 02 1992 05 66 90 1587 4 4A-F Estate Corolla
Toyota, Passenger Car EU Corolla 1.6 Gasoline 1987 10 1990 08 77 105 1587 4 i 4A-FE 4WD Corolla
Toyota, Passenger Car EU Carina 1.6 Gasoline 1987 12 1992 03 72 98 1587 4 4A-FE Hatchback Carina
Toyota, Passenger Car EU Carina 1.6 Gasoline 1987 12 1992 03 75 102 1587 4 4A-FE Estate Carina
Toyota, Passenger Car EU Carina 1.6 Gasoline 1987 12 1989 11 66 90 1587 4 4A-F Hatchback Carina
Toyota, Passenger Car EU Carina 1.6 Gasoline 1987 12 1992 03 75 102 1587 4 4A-FE Carina
Toyota, Passenger Car EU Celica 1.6 Gasoline 1989 10 1993 11 77 105 1587 4 4A-FE Coupe Celica
Toyota, Passenger Car EU Corolla 1.6 Gasoline 1987 08 1989 12 66 90 1587 4 4A-F Corolla
Toyota, Passenger Car EU Corolla 1.6 Gasoline 1989 08 1992 04 77 105 1587 4 i 4A-FE Hatchback Corolla
Toyota, Passenger Car EU Carina 1.6 Gasoline 1987 12 1990 08 66 90 1587 4 4A-F Carina
Toyota, Passenger Car EU Carina 1.6 Gasoline 1987 12 1992 03 72 98 1587 4 4A-FE Carina
Toyota, Passenger Car EU Corolla 1.6 Gasoline 1987 12 1992 04 70 95 1587 4 4A-F Estate Corolla
Toyota, Passenger Car EU Corolla 1.6 Gasoline 1987 08 1992 04 66 90 1587 4 4A-F Hatchback Corolla
Toyota, Passenger Car EU Corolla 1.6 Gasoline 1988 08 1992 06 77 105 1587 4 4A-FE Estate Corolla
Toyota, Passenger Car EU Corolla 1.6 Gasoline 1989 08 1992 04 77 105 1587 4 4A-FE Hatchback Corolla
Toyota, Passenger Car EU Carina 1.6 Gasoline 1987 12 1989 12 66 90 1587 4 4A-F Estate Carina
Toyota, Passenger Car EU Corolla 1.6 Gasoline 1989 11 1992 06 77 105 1587 4 4A-FE Estate XLi Corolla
Toyota, Passenger cars US Corolla 1.6 Gasoline 1988 01 1992 01 0 0 1587 L4 4A-FE DLX All Trac Corolla
Toyota, Passenger cars US Corolla 1.6 Gasoline 1990 01 1992 01 0 0 1587 L4 4A-FE LE Corolla
Toyota, Passenger cars US Corolla 1.6 Gasoline 1988 01 1991 01 0 0 1587 L4 4A-FE SR5 All Trac Corolla
Toyota, Passenger cars US Corolla 1.6 Gasoline 1989 01 1989 01 0 0 1587 L4 4A-FE SR5 ALL TRAC Corolla
Toyota, Passenger cars US Corolla 1.6 Gasoline 1988 01 1989 01 0 0 1587 L4 4A-F LE Corolla
Toyota, Passenger cars US Corolla 1.6 Gasoline 1989 01 1989 01 0 0 1587 L4 Corolla
Toyota, Passenger cars US Corolla 1.6 Gasoline 1990 01 1992 01 0 0 1587 L4 4A-FE Corolla
Toyota, Passenger cars US Corolla 1.6 Gasoline 1992 01 1992 01 0 0 1587 L4 LSX Corolla
Toyota, Passenger cars US Corolla 1.6 Gasoline 1992 01 1992 01 0 0 1587 L4 SR5 ALL TRAC Corolla
Toyota, Passenger cars US Celica 1.6 Gasoline 1990 01 1993 01 0 0 1587 L4 4A-FE ST Celica
Toyota, Passenger cars US Corolla 1.6 Gasoline 1988 01 1989 01 0 0 1587 L4 4A-F SR5 Corolla
Toyota, Passenger cars US Corolla 1.6 Gasoline 1990 01 1992 01 0 0 1587 L4 4A-FE DLX Corolla
Toyota, Passenger cars US Corolla 1.6 Gasoline 1990 01 1991 01 0 0 1587 L4 4A-FE SR5 Corolla
Toyota, Passenger cars US Corolla 1.6 Gasoline 1992 01 1992 01 0 0 1587 L4 SR5 Corolla
Toyota, Passenger cars US Corolla 1.6 Gasoline 1988 01 1989 01 0 0 1587 L4 4A-F DLX Corolla
Toyota, Passenger cars US Corolla 1.6 Gasoline 1988 01 - 0 0 1587 L4 4A-LC FX Corolla
GEO, Passenger cars US Prizm 1.6 Gasoline 1990 01 1992 01 0 0 1588 L4 LSI Prizm
GEO, Passenger cars US Prizm 1.6 Gasoline 1989 01 1991 01 0 0 1588 L4 Prizm
