110804 - Alternator (110804)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.


Voltage: 14,
Amp: 90,
Bracket Hole: 8.50, Belt. adj. bracket hole M8,
Width/Holder Arm: 13.40, Belt. adj. brackethole pos. 4,
Mount. Bracket Dist.: 77.40,
Pulley Dia.: 65.00,
Pulley Dist.: 35.00,
Grooves/Pulley: 4,
Radius: 89.50,
Radius: 87.50,
B+ Position: M6,
Rotation: CR,
Regulator Plug: or plug PL07,
Blower: IF, Pulley SP,
Total Length: 160.00

Electrical specifications (Alternator)
Voltage 14
Amp 90

Physical specifications (Alternator)
D Bracket hole 8.50
G Belt. adj. bracket hole M8
B Width/holder arm 13.40
E Belt. adj. brackethole pos. 4
C Mount. bracket dist. 77.40
H Pulley dia. 65.00
A Pulley dist. 35.00
i Grooves/pulley 4
j Radius 89.50
j Radius 87.50
k B+ position M6
n Rotation CR
o Regulator plug PL07
R Total length 160.00

Further information (Alternator)
Blower IF
Pulley SP

Replacing
37300-32134 KIA
37300-32800 KIA
37300-33100 KIA
37300-33101 KIA
37300-33102 KIA
37300-33103 KIA
37300-33110 KIA
a000b0441 VALEO
A003T45691 MITSUBISHI
A003T45693 MITSUBISHI

UNISTART Price: £119.17

Sorry, this item is out of stock.

The 110804 - Alternator is shown in: Starters & Alternators > Alternators , Automotive > Starters & Alternators.

Fast Delivery - UK & Europe

We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.

You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us.  Replacements & refunds will be dispatched / issued on receipt of the returned items only.

Mfg. Model Engine Size Fuel From To KW HP Volume Cylinders Engine Type Brand Chassis Model Type Series
Mitsubishi, Passenger Car EU Galant 2 Gasoline 1988 12 1992 10 80 109 1997 4 4G63 4WD Galant
Mitsubishi, Passenger Car EU Galant 2 Gasoline 1989 04 1992 10 80 109 1997 4 4G63 Hatchback Galant
Mitsubishi, Passenger Car EU Galant 2 Gasoline 1988 11 1992 10 107 146 1997 4 16V 4G63 Hatchback Galant
Mitsubishi, Passenger Car EU Galant 2 Gasoline 1988 06 1992 10 106 144 1997 4 16V 4G63 4WD Galant
Mitsubishi, Passenger Car EU Eclipse 2 Gasoline 1995 12 1999 04 157 214 1997 4 16V 4G63 Coupe GT Eclipse 2000
Mitsubishi, Passenger Car EU Galant 2 Gasoline 1988 11 1992 10 106 144 1997 4 16V 4G63 Hatchback Galant
Mitsubishi, Passenger Car EU Galant 2 Gasoline 1987 11 1992 10 80 109 1997 4 4G63 Galant
Mitsubishi, Passenger Car EU Eclipse 2 Gasoline 1991 04 1995 11 110 150 1997 4 i 16V 4G63 Coupe Eclipse
Mitsubishi, Passenger Car EU Galant 2 Gasoline 1989 07 1992 12 106 144 1997 4 GTi 16V 4G63 Hatchback 4WD Galant
Mitsubishi, Passenger Car EU Eclipse 2 Gasoline 1991 04 1995 11 110 150 1997 4 i 16V 4G63 Coupe 4WD Eclipse
Mitsubishi, Passenger Car EU Lancer 1.8 Gasoline 1989 11 1992 05 100 136 1836 4 GTi 16V 4G67 Hatchback Lancer
Mitsubishi, Passenger Car EU Galant 2 Gasoline 1987 11 1992 10 106 144 1997 4 16V 4G63 Galant
Mitsubishi, Passenger Car EU Galant 2 Gasoline 1989 04 1992 10 80 109 1997 4 4G63 Hatchback 4WD Galant
Mitsubishi, Passenger Car EU Galant 2 Gasoline 1991 09 1992 10 110 150 1997 4 16V 4G63 4WD Galant
Hyundai, Passenger Car EU Lantra 1.6 Gasoline 1990 10 1995 11 84 114 1596 4 i 16V G4CR Lantra
Hyundai, Passenger Car EU Sonata 2 Gasoline 1991 01 1993 10 96 130 1997 4 i 16V G4CP-D Sonata
Hyundai, Passenger Car EU Sonata 2 Gasoline 1996 08 1998 06 70 95 1997 4 i G4CP Sonata
Hyundai, Passenger Car EU Lantra 1.6 Gasoline 1990 10 1995 11 78 106 1596 4 i 16V G4CR Lantra
Hyundai, Passenger Car EU Lantra 1.8 Gasoline 1990 10 1995 11 93 127 1836 4 i 16V G4CN Lantra
Hyundai, Passenger Car EU Sonata 2 Gasoline 1996 06 1998 06 92 125 1997 4 i 16V G4CP-DM Sonata
Hyundai, Passenger Car EU Santamo 2 Gasoline 1999 05 - 102 139 1997 4 16V G4CP MPV 4WD Santamo
Hyundai, Passenger Car EU Sonata 2 Gasoline 1994 06 1996 08 77 105 1997 4 i G4CP Sonata
Hyundai, Passenger Car EU Sonata 2 Gasoline 1993 05 1998 06 102 139 1997 4 i 16V G4CP-D Sonata
Hyundai, Passenger Car EU Santamo 2 Gasoline 1999 05 - 102 139 1997 4 16V G4CP MPV Santamo
Eagle, Passenger cars US 2000 2 Gasoline 1993 01 1993 01 0 0 1995 L4 GTX 2000
Eagle, Passenger cars US 2000 2 Gasoline 1992 01 1992 01 0 0 1997 L4 GTX 4x4 2000
Eagle, Passenger cars US Talon 2 Gasoline 1990 01 1992 01 0 0 1997 L4 Talon
Eagle, Passenger cars US 2000 2 Gasoline 1991 01 1992 01 0 0 1997 L4 GTX 2000
