111035 - Alternator (111035)
Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.
Voltage: 14,
Amp: 65, Terminal W,
Bracket Hole: 10.00, Belt. adj. bracket hole 11.00,
Width/Holder Arm: 23.00, Belt. adj. brackethole pos. 6,
Mount. Bracket Dist.: 74.00,
Pulley Dia.: 68.00,
Pulley Dist.: 52.00,
Grooves/Pulley: 1,
Radius: 80.00,
Radius: 86.00,
B+ Position: M6,
Rotation: CR,
Regulator Plug: or plug PL_NA,
Blower: EF, Pulley P,
Total Length: 164.50
Electrical specifications (Alternator) | ||||
| Voltage | 14 | |||
| Amp | 65 | |||
| Terminal | W | |||
Physical specifications (Alternator) | ||||
| D | Bracket hole 10.00 | |||
| G | Belt. adj. bracket hole 11.00 | |||
| B | Width/holder arm 23.00 | |||
| E | Belt. adj. brackethole pos. 6 | |||
| C | Mount. bracket dist. 74.00 | |||
| H | Pulley dia. 68.00 | |||
| A | Pulley dist. 52.00 | |||
| i | Grooves/pulley 1 | |||
| j | Radius 80.00 | |||
| j | Radius 86.00 | |||
| k | B+ position M6 | |||
| n | Rotation CR | |||
| o | Regulator plug PL_NA | |||
| R | Total length 164.50 | |||
Further information (Alternator) | ||||
| Blower | EF | |||
| Pulley | P | |||
Replacing | ||||
| 0120489126 | BOSCH | |||
| 0120489186 | BOSCH | |||
| 0120489187 | BOSCH | |||
| 0120489188 | BOSCH | |||
| 063321154000 | MAKO | |||
| 11.201.017 | ISKRA | |||
| 11.201.085 | ISKRA | |||
| 11.201.093 | ISKRA | |||
| 11.201.167 | ISKRA | |||
| 11.201.204 | ISKRA | |||
UNISTART Price: £89.55
Fast Delivery - UK & Europe
We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.
You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us. Replacements & refunds will be dispatched / issued on receipt of the returned items only.
| Mfg. | Model | Engine Size | Fuel | From | To | KW | HP | Volume | Cylinders | Engine Type | Brand | Chassis | Model Type | Series |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Fiat, Passenger Car EU | Tipo | 1.4 | Gasoline | 1989 05 | 1995 04 | 51 | 70 | 1372 | 4 | i.e. | 160A1.046 | Hatchback | Tipo | |
| Fiat, Passenger Car EU | Regata | 1.5 | Gasoline | 1985 07 | 1989 07 | 55 | 75 | 1498 | 4 | i.e. | 149C1.000 | Regata | ||
| Fiat, Passenger Car EU | Fiorino | 1.3 | Gasoline | 1987 12 | 1993 08 | 49 | 67 | 1288 | 4 | 146A5.000 | Van | Fiorino | ||
| Fiat, Passenger Car EU | Ritmo | 1.5 | Gasoline | 1980 01 | 1989 07 | 63 | 86 | 1498 | 4 | 138A4.000 | Convertible | Bertone | Ritmo | |
| Fiat, Passenger Car EU | Ritmo | 1.5 | Gasoline | 1983 03 | 1986 12 | 60 | 82 | 1498 | 4 | 138B3.000 | Convertible | Bertone | Ritmo | |
| Fiat, Passenger Car EU | Ritmo | 1.5 | Gasoline | 1985 09 | 1988 12 | 55 | 75 | 1498 | 4 | 138C2.048 | Hatchback | Ritmo | ||
| Fiat, Passenger Car EU | Tempra | 1.4 | Gasoline | 1991 03 | 1996 08 | 57 | 78 | 1372 | 4 | i.e. | 159A2.000 | Tempra | ||
| Fiat, Passenger Car EU | Fiorino | 1.1 | Gasoline | 1988 05 | 1993 12 | 40 | 54 | 1116 | 4 | 146A9.000 | Van | Fiorino | ||
| Fiat, Passenger Car EU | Tempra | 1.6 | Gasoline | 1990 03 | 1993 04 | 63 | 86 | 1581 | 4 | 159A3.000 | Tempra | |||
| Fiat, Passenger Car EU | Fiorino | 1.1 | Gasoline | 1987 09 | 1988 12 | 41 | 56 | 1036 | 4 | 156A.000 | Pick Up | Fiorino | ||
| Fiat, Passenger Car EU | Fiorino | 1 | Gasoline | 1982 10 | 1987 10 | 37 | 50 | 1036 | 4 | 127A.000 | Pick Up | Fiorino | ||
| Fiat, Passenger Car EU | Uno | 1.4 | Gasoline | 1989 09 | 1993 12 | 53 | 72 | 1372 | 4 | i.e. | 146C1.000 | Hatchback | Uno | |
| Fiat, Passenger Car EU | Ritmo | 1 | Gasoline | 1978 09 | 1982 09 | 44 | 60 | 1049 | 4 | 127A6.000 | Hatchback | Ritmo | ||
| Fiat, Passenger Car EU | Ritmo | 1.3 | Gasoline | 1981 01 | 1982 09 | 55 | 75 | 1301 | 4 | 138A3.000 | Hatchback | Ritmo | ||
| Fiat, Passenger Car EU | Ritmo | 1.5 | Gasoline | 1983 03 | 1987 05 | 55 | 75 | 1498 | 4 | i.e. | 138C2.048 | Hatchback | Ritmo | |
| Fiat, Passenger Car EU | Tipo | 1.4 | Gasoline | 1987 07 | 1989 12 | 52 | 71 | 1372 | 4 | 160A1.000 | Hatchback | Selecta | Tipo | |
| Fiat, Passenger Car EU | Regata | 1.3 | Gasoline | 1983 09 | 1989 07 | 48 | 65 | 1301 | 4 | 149A3.000 | ES | Regata | ||
| Fiat, Passenger Car EU | Regata | 1.5 | Gasoline | 1984 09 | 1989 07 | 55 | 75 | 1498 | 4 | i.e. | 138C3.048 | Estate | Regata | |
| Fiat, Passenger Car EU | Uno | 1.4 | Gasoline | 1989 09 | 1993 12 | 51 | 70 | 1372 | 4 | i.e. | 160A1.046 | Hatchback | Uno | |
| Fiat, Passenger Car EU | Uno | 1.5 | Gasoline | 1985 10 | 1993 12 | 55 | 75 | 1499 | 4 | i.e. | 138C2.048 | Hatchback | Uno | |
| Fiat, Passenger Car EU | Fiorino | 1 | Gasoline | 1980 01 | 1987 12 | 37 | 50 | 1049 | 4 | 127A.000 | Van | Fiorino | ||
| Fiat, Passenger Car EU | Regata | 1.5 | Gasoline | 1983 12 | 1987 12 | 55 | 75 | 1498 | 4 | i.e. | 138C3.048 | Regata | ||
| Fiat, Passenger Car EU | Ritmo | 1.5 | Gasoline | 1985 08 | 1987 05 | 58 | 79 | 1498 | 4 | 149A5.000 | Hatchback | Ritmo | ||
| Fiat, Passenger Car EU | Tipo | 1.6 | Gasoline | 1988 01 | 1991 10 | 61 | 83 | 1581 | 4 | 160A2.000 | Hatchback | Digit | Tipo | |
| Fiat, Passenger Car EU | Fiorino | 1.3 | Gasoline | 1988 01 | 1994 12 | 49 | 67 | 1301 | 4 | 146A5.000 | Van | Fiorino | ||
| Fiat, Passenger Car EU | Elba | 1.3 | Gasoline | 1986 04 | 1993 12 | 43 | 58 | 1297 | 4 | 127A2.011 | Estate | Elba | ||
| Fiat, Passenger Car EU | Regata | 1.5 | Gasoline | 1984 01 | 1989 04 | 60 | 82 | 1498 | 4 | 138B3.000 | Estate | Regata | ||
| Fiat, Passenger Car EU | 126 | 0.7 | Gasoline | 1987 09 | 1996 06 | 19 | 26 | 704 | 2 | 126A2.048 | 700 Bambino | 126 | ||
| Fiat, Passenger Car EU | Ritmo | 1.1 | Gasoline | 1982 10 | 1985 10 | 40 | 55 | 1116 | 4 | 138B.000 | Hatchback | Ritmo | ||
| Fiat, Passenger Car EU | Ritmo | 1.1 | Gasoline | 1985 04 | 1987 12 | 43 | 58 | 1116 | 4 | 146A4.048 | Hatchback | Ritmo | ||
| Fiat, Passenger Car EU | Ritmo | 1.5 | Gasoline | 1983 03 | 1987 05 | 55 | 75 | 1498 | 4 | i.e. | 149C1.000 | Hatchback | Ritmo | |
| Fiat, Passenger Car EU | Tipo | 1.4 | Gasoline | 1987 07 | 1989 12 | 52 | 71 | 1372 | 4 | 160A1.048 | Hatchback | Selecta | Tipo | |
| Fiat, Passenger Car EU | Regata | 1.5 | Gasoline | 1985 07 | 1989 07 | 55 | 75 | 1498 | 4 | i.e. | 138C2.048 | Regata | ||
| Fiat, Passenger Car EU | Uno | 1.3 | Gasoline | 1983 01 | 1985 04 | 50 | 68 | 1302 | 4 | 138B2.000 | Hatchback | Uno | ||
| Fiat, Passenger Car EU | Fiorino | 1.1 | Gasoline | 1986 11 | 1988 04 | 40 | 55 | 1116 | 4 | 146A9.000 | Van | Fiorino | ||
| Fiat, Passenger Car EU | Penny Van | 1.1 | Gasoline | 1986 01 | 1990 12 | 43 | 58 | 1116 | 4 | 146A6.000 | Van | Penny Van | ||
| Fiat, Passenger Car EU | Ritmo | 1.5 | Gasoline | 1985 09 | 1988 12 | 55 | 75 | 1498 | 4 | 149C1.000 | Hatchback | Ritmo | ||
| Fiat, Passenger Car EU | Ritmo | 1.3 | Gasoline | 1983 11 | 1985 08 | 48 | 65 | 1301 | 4 | 149A3.000 | Hatchback | Ritmo | ||
| Fiat, Passenger Car EU | Ritmo | 1.3 | Gasoline | 1983 11 | 1985 08 | 48 | 65 | 1301 | 4 | 149A7.000 | Hatchback | Ritmo | ||
| Fiat, Passenger Car EU | Duna | 1.1 | Gasoline | 1987 01 | 1991 12 | 43 | 58 | 1116 | 4 | 146A6.000 | Estate | Duna | ||
| Fiat, Passenger Car EU | Elba | 1.5 | Gasoline | 1992 01 | 1996 12 | 55 | 75 | 1499 | 4 | 149C3.000 | Estate | Elba | ||
| Fiat, Passenger Car EU | Ritmo | 1.3 | Gasoline | 1985 10 | 1987 12 | 50 | 68 | 1302 | 4 | 138B2.000 | Convertible | Bertone | Ritmo | |
| Fiat, Passenger Car EU | Uno | 1.1 | Gasoline | 1988 02 | 1992 02 | 43 | 58 | 1116 | 4 | 146A6.000 | Van | Uno | ||
| Fiat, Passenger Car EU | Uno | 1.1 | Gasoline | 1988 02 | 1992 02 | 43 | 58 | 1116 | 4 | 146A4.048 | Van | Uno | ||
| Fiat, Passenger Car EU | Penny Van | 1.3 | Gasoline | 1986 01 | 1990 12 | 49 | 67 | 1301 | 4 | 146A5.000 | Van | Penny Van | ||
| Fiat, Passenger Car EU | Regata | 1.6 | Gasoline | 1983 10 | 1990 06 | 60 | 82 | 1585 | 4 | 149A.000 | Regata | |||
| Fiat, Passenger Car EU | Fiorino | 1.5 | Gasoline | 1988 05 | 1993 12 | 55 | 75 | 1499 | 4 | i.e. | 149C1.000 | Van | Fiorino | |
| Fiat, Passenger Car EU | Duna | 1.3 | Gasoline | 1987 01 | 1991 12 | 49 | 67 | 1301 | 4 | 146A5.000 | Estate | Duna | ||
| Fiat, Passenger Car EU | Uno | 1.3 | Gasoline | 1985 05 | 1989 08 | 48 | 65 | 1302 | 4 | 149A7.000 | Hatchback | Uno | ||
| Fiat, Passenger Car EU | Fiorino | 1.5 | Gasoline | 1988 01 | 1993 08 | 55 | 75 | 1499 | 4 | 149C1.000 | Van | Fiorino | ||
| Fiat, Passenger Car EU | Tipo | 1.4 | Gasoline | 1989 05 | 1995 04 | 57 | 78 | 1372 | 4 | i.e. | 159A2.000 | Hatchback | Tipo | |
| Fiat, Passenger Car EU | Uno | 1.4 | Gasoline | 1989 09 | 1992 10 | 52 | 71 | 1372 | 4 | 160A1.048 | Hatchback | S | Uno | |
| Fiat, Passenger Car EU | 126 | 0.7 | Gasoline | 1987 09 | 1996 06 | 19 | 26 | 704 | 2 | 126A2.000 | 700 Bambino | 126 | ||
| Fiat, Passenger Car EU | Ritmo | 1.1 | Gasoline | 1982 10 | 1985 10 | 40 | 55 | 1116 | 4 | 138B1.000 | Hatchback | Ritmo | ||
| Fiat, Passenger Car EU | Regata | 1.5 | Gasoline | 1985 05 | 1987 12 | 58 | 79 | 1498 | 4 | 149A5.000 | Regata | |||
| Fiat, Passenger Car EU | Regata | 1.5 | Gasoline | 1983 09 | 1985 04 | 60 | 82 | 1498 | 4 | 138B3.000 | Super | Regata | ||
| Fiat, Passenger Car EU | Uno | 1.1 | Gasoline | 1985 05 | 1989 08 | 43 | 58 | 1116 | 4 | 146A4.048 | Hatchback | Uno | ||
| Fiat, Passenger Car EU | Uno | 1.5 | Gasoline | 1985 10 | 1993 12 | 55 | 75 | 1499 | 4 | i.e. | 149C1.000 | Hatchback | Uno | |
| Fiat, Passenger Car EU | Regata | 1.5 | Gasoline | 1983 12 | 1987 12 | 55 | 75 | 1498 | 4 | i.e. | 138B3.048 | Regata | ||
| Fiat, Passenger Car EU | Duna | 1.3 | Gasoline | 1987 01 | 1991 12 | 49 | 67 | 1301 | 4 | 146A5.000 | Duna | |||
| Fiat, Passenger Car EU | Fiorino | 1.3 | Gasoline | 1988 01 | 1994 12 | 49 | 67 | 1301 | 4 | 146A5.000 | Pick Up | Fiorino | ||
| Fiat, Passenger Car EU | Elba | 1.3 | Diesel | 1986 04 | 1992 10 | 33 | 45 | 1301 | 4 | Diesel | 127A5.000 | Estate | Elba | |
| Fiat, Passenger Car EU | Regata | 1.3 | Gasoline | 1983 09 | 1986 07 | 50 | 68 | 1301 | 4 | 138B2.000 | Regata | |||
| VW, Passenger cars US | Dasher | 1.5 | Diesel | 1979 01 | 1980 01 | 0 | 0 | 1471 | L4 | CK | Dasher | |||
| VW, Passenger cars US | Rabbit | 1.6 | Diesel | 1981 01 | 1981 01 | 0 | 0 | 1588 | L4 | CR | L Custom | Rabbit | ||
| VW, Passenger cars US | Rabbit | 1.6 | Diesel | 1982 01 | 1982 01 | 0 | 0 | 1588 | L4 | CR | LS Deluxe | Rabbit | ||
| VW, Passenger cars US | Rabbit | 1.6 | Diesel | 1983 01 | 1983 01 | 0 | 0 | 1588 | L4 | CR | L | Rabbit | ||
| VW, Passenger cars US | Jetta | 1.6 | Diesel | 1981 01 | 1981 01 | 0 | 0 | 1588 | L4 | CR | Deluxe | Jetta | ||
| VW, Passenger cars US | Jetta | 1.6 | Diesel | 1983 01 | 1984 01 | 0 | 0 | 1588 | L4 | JK | Deluxe | Jetta | ||
| VW, Passenger cars US | Jetta | 1.6 | Diesel | 1983 01 | 1984 01 | 0 | 0 | 1588 | L4 | Turbo | CY | Deluxe | Jetta | |
| VW, Passenger cars US | Rabbit | 1.6 | Diesel | 1982 01 | 1982 01 | 0 | 0 | 1588 | L4 | CR | L Custom | Rabbit | ||
| VW, Passenger cars US | Rabbit | 1.6 | Diesel | 1983 01 | - | 0 | 0 | 1588 | L4 | JK | GL DLX | Rabbit | ||
| VW, Passenger cars US | Rabbit | 1.6 | Diesel | 1983 01 | - | 0 | 0 | 1588 | L4 | JK | LS Custom | Rabbit | ||
| VW, Passenger cars US | Jetta | 1.6 | Diesel | 1982 01 | 1982 01 | 0 | 0 | 1588 | L4 | CR | Deluxe | Jetta | ||
| VW, Passenger cars US | Rabbit | 1.6 | Diesel | 1984 01 | 1984 01 | 0 | 0 | 1588 | L4 | JK | L | Rabbit | ||
| VW, Passenger cars US | Quantum | 1.6 | Diesel | 1982 01 | 1983 01 | 0 | 0 | 1588 | L4 | Turbo | CY | DLX | Quantum | |
| VW, Passenger cars US | Rabbit | 1.6 | Diesel | 1981 01 | 1981 01 | 0 | 0 | 1588 | L4 | CR | LS Deluxe | Rabbit | ||
| VW, Passenger cars US | Rabbit | 1.6 | Diesel | 1983 01 | 1983 01 | 0 | 0 | 1588 | L4 | CR | LS Custom | Rabbit | ||
| VW, Passenger cars US | Rabbit | 1.6 | Diesel | 1983 01 | - | 0 | 0 | 1588 | L4 | CR | GL DLX | Rabbit | ||
| VW, Passenger cars US | Rabbit | 1.6 | Diesel | 1983 01 | - | 0 | 0 | 1588 | L4 | JK | L | Rabbit | ||
| Lancia, Passenger Car EU | Delta | 1.5 | Gasoline | 1979 09 | 1992 12 | 63 | 86 | 1498 | 4 | 831A1.000 | Hatchback | Delta | ||
| Lancia, Passenger Car EU | Delta | 1.3 | Gasoline | 1979 09 | 1992 08 | 55 | 75 | 1301 | 4 | 831B.000 | Hatchback | Delta | ||
| Lancia, Passenger Car EU | Delta | 1.3 | Gasoline | 1979 09 | 1992 08 | 55 | 75 | 1301 | 4 | 831A2.000 | Hatchback | Delta | ||
| Lancia, Passenger Car EU | Delta | 1.5 | Gasoline | 1979 09 | 1992 12 | 63 | 86 | 1498 | 4 | 831B1.000 | Hatchback | Delta | ||
| Lancia, Passenger Car EU | Y | 1 | Gasoline | 1985 03 | 1989 02 | 62 | 84 | 1049 | 4 | Turbo | 156A1.000 | Hatchback | Y10 | |
| Lancia, Passenger Car EU | Delta | 1.1 | Gasoline | 1986 01 | 1990 12 | 47 | 64 | 1116 | 4 | 831B8.000 | Hatchback | Delta |
