111061 - Starter (111061)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.


Voltage: 12, kW 0.8, Mount. flange 76.10, Drive dist. 44.50, Dist./back 143.00, Dist./front 78.00, No. of teeth 9, B+ M8, Gear type DD/GR, Dist. 105.00,
Rotation: ACR, No./mount. holes 2 (0),
Drive Type: Steel, Remarks Bushing D.E. (clutch house): HC-CARGO 140008.,
Total Length: 230.00, Oil sealed No, Waterproof No

Electrical specifications (Starter)
Voltage 12
kW 0.8

Physical specifications (Starter)
A Mount. flange 76.10
B Drive dist. 44.50
F Dist./back 143.00
G Dist./front 78.00
H No. of teeth 9
I B+ M8
N Gear type DD/GR
O Dist. 105.00
P Rotation ACR
R Total length 230.00

Further information (Starter)
No./mount. holes 2 (0)
Drive type Steel
Remarks Bushing D.E. (clutch house): HC-CARGO 140008.
Oil sealed No
Waterproof No

Replacing
0001211251 BOSCH
0001211252 BOSCH
0001211253 BOSCH
0001211254 BOSCH
091911023a VOLKSWAGEN
091911023ax VOLKSWAGEN
091911023b VOLKSWAGEN
091911023bx VOLKSWAGEN

UNISTART Price: £94.92

Sorry, this item is out of stock.

The 111061 - Starter is shown in: Starters & Alternators > Starters , Automotive > Starters & Alternators.

Fast Delivery - UK & Europe

We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.

You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us.  Replacements & refunds will be dispatched / issued on receipt of the returned items only.

Mfg. Model Engine Size Fuel From To KW HP Volume Cylinders Engine Type Brand Chassis Model Type Series
VW, Passenger Car EU Transporter 2 Gasoline 1979 05 1982 12 51 70 1970 4 CU Bus T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Van T3 Syncro Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1989 06 1992 07 70 95 2110 4 MV Bus T3 Transporter
VW, Passenger Car EU Transporter 2 Gasoline 1979 05 1986 04 51 69 1970 4 CU Van T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1984 12 1992 07 57 78 1913 4 DG Platform / Chassis T3 Syncro Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Platform / Chassis T3 Syncro Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1984 10 1989 02 61 83 1913 4 DH Van T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1984 08 1992 07 82 112 2110 4 DJ Bus T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1983 08 1985 07 66 90 1913 4 GW Bus T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1985 02 1992 07 57 78 1913 4 DG Bus T3 Syncro Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1986 01 1992 07 82 112 2110 4 DJ Bus T3 Syncro Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1984 11 1992 07 57 78 1913 4 DG Van T3 Syncro Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Platform / Chassis T3 Transporter
VW, Passenger Car EU Transporter 2 Gasoline 1979 05 1986 04 51 69 1970 4 CU Platform / Chassis T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1986 03 1992 07 82 112 2110 4 DJ Van T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Van T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1986 03 1992 07 82 112 2110 4 DJ Platform / Chassis T3 Syncro Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1986 03 1992 07 82 112 2110 4 DJ Platform / Chassis T3 Transporter
VW, Passenger Car EU Transporter 1.6 Gasoline 1979 05 1982 12 37 50 1584 4 CT Bus T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1983 01 1985 07 61 83 1913 4 DH Bus T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Bus T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1989 07 1992 07 68 92 2110 4 SS Bus T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1982 10 1992 07 44 60 1913 4 DF Van T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1982 08 1992 07 57 78 1913 4 DG Bus T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Bus T3 Syncro Transporter
VW, Passenger Car EU Transporter 1.6 Gasoline 1979 05 1982 12 37 50 1584 4 CT Van T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1982 10 1992 07 57 78 1913 4 DG Van T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1986 03 1992 07 82 112 2110 4 DJ Van T3 Syncro Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1983 08 1989 02 66 90 1913 4 GW Van T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1984 10 1989 02 61 83 1913 4 DH Platform / Chassis T3 Transporter
VW, Passenger Car EU Transporter 2 Gasoline 1979 05 1982 12 51 70 1970 4 CU Bus T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Van T3 Syncro Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1989 06 1992 07 70 95 2110 4 MV Bus T3 Transporter
VW, Passenger Car EU Transporter 2 Gasoline 1979 05 1986 04 51 69 1970 4 CU Van T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1984 12 1992 07 57 78 1913 4 DG Platform / Chassis T3 Syncro Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Platform / Chassis T3 Syncro Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1984 10 1989 02 61 83 1913 4 DH Van T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1984 08 1992 07 82 112 2110 4 DJ Bus T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1983 08 1985 07 66 90 1913 4 GW Bus T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1985 02 1992 07 57 78 1913 4 DG Bus T3 Syncro Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1986 01 1992 07 82 112 2110 4 DJ Bus T3 Syncro Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1984 11 1992 07 57 78 1913 4 DG Van T3 Syncro Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Platform / Chassis T3 Transporter
VW, Passenger Car EU Transporter 2 Gasoline 1979 05 1986 04 51 69 1970 4 CU Platform / Chassis T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1986 03 1992 07 82 112 2110 4 DJ Van T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Van T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1986 03 1992 07 82 112 2110 4 DJ Platform / Chassis T3 Syncro Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1986 03 1992 07 82 112 2110 4 DJ Platform / Chassis T3 Transporter
VW, Passenger Car EU Transporter 1.6 Gasoline 1979 05 1982 12 37 50 1584 4 CT Bus T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1982 08 1992 07 44 60 1913 4 DF Bus T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Bus T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1989 07 1992 07 68 92 2110 4 SS Bus T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1982 10 1992 07 44 60 1913 4 DF Van T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1982 08 1992 07 57 78 1913 4 DG Bus T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Bus T3 Syncro Transporter
VW, Passenger Car EU Transporter 1.6 Gasoline 1979 05 1982 12 37 50 1584 4 CT Van T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1982 10 1992 07 57 78 1913 4 DG Van T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1986 03 1992 07 82 112 2110 4 DJ Van T3 Syncro Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1983 08 1989 02 66 90 1913 4 GW Van T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1984 10 1989 02 61 83 1913 4 DH Platform / Chassis T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1989 06 1992 07 70 95 2110 4 MV Bus T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1989 07 1992 07 68 92 2110 4 SS Bus T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1983 01 1985 07 61 83 1913 4 DH Bus T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1983 08 1989 02 66 90 1913 4 GW Van T3 Transporter
VW, Passenger Car EU Transporter 2 Gasoline 1979 05 1982 12 51 70 1970 4 CU Bus T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1989 06 1992 07 70 95 2110 4 MV Bus T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Van T3 Syncro Transporter
VW, Passenger Car EU Transporter 2 Gasoline 1979 05 1986 04 51 69 1970 4 CU Van T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1984 12 1992 07 57 78 1913 4 DG Platform / Chassis T3 Syncro Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Platform / Chassis T3 Syncro Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1984 10 1989 02 61 83 1913 4 DH Van T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1984 08 1992 07 82 112 2110 4 DJ Bus T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1983 08 1985 07 66 90 1913 4 GW Bus T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1985 02 1992 07 57 78 1913 4 DG Bus T3 Syncro Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1986 01 1992 07 82 112 2110 4 DJ Bus T3 Syncro Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1984 11 1992 07 57 78 1913 4 DG Van T3 Syncro Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Platform / Chassis T3 Transporter
VW, Passenger Car EU Transporter 2 Gasoline 1979 05 1986 04 51 69 1970 4 CU Platform / Chassis T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1986 03 1992 07 82 112 2110 4 DJ Van T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Van T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1986 03 1992 07 82 112 2110 4 DJ Platform / Chassis T3 Syncro Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1986 03 1992 07 82 112 2110 4 DJ Platform / Chassis T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1982 08 1992 07 44 60 1913 4 DF Bus T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1983 01 1985 07 61 83 1913 4 DH Bus T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Bus T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1989 07 1992 07 68 92 2110 4 SS Bus T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1982 10 1992 07 44 60 1913 4 DF Van T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1982 08 1992 07 57 78 1913 4 DG Bus T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1985 08 1992 07 70 95 2110 4 MV Bus T3 Syncro Transporter
VW, Passenger Car EU Transporter 1.6 Gasoline 1979 05 1982 12 37 50 1584 4 CT Van T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1982 10 1992 07 57 78 1913 4 DG Van T3 Transporter
VW, Passenger Car EU Transporter 2.1 Gasoline 1986 03 1992 07 82 112 2110 4 DJ Van T3 Syncro Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1983 08 1989 02 66 90 1913 4 GW Van T3 Transporter
VW, Passenger Car EU Transporter 1.9 Gasoline 1984 10 1989 02 61 83 1913 4 DH Platform / Chassis T3 Transporter
