111310 - Starter (111310)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.


Voltage: 12, kW 0.8, Mount. flange 75.00, Drive dist. 7.80, Dist./back 149.35, Dist./front 41.20, No. of teeth 8, B+ M8, Gear type GR, Dist. 99.60,
Rotation: CR, No./mount. holes 2 (2),
Drive Type: Steel,
Total Length: 190.50, Oil sealed No, Waterproof No

Electrical specifications (Starter)
Voltage 12
kW 0.8

Physical specifications (Starter)
A Mount. flange 75.00
B Drive dist. 7.80
F Dist./back 149.35
G Dist./front 41.20
H No. of teeth 8
I B+ M8
N Gear type GR
O Dist. 99.60
P Rotation CR
R Total length 190.50

Further information (Starter)
No./mount. holes 2 (2)
Drive type Steel
Oil sealed No
Waterproof No

Replacing
028000-9900 DENSO
028000-9901 DENSO
028000-9902 DENSO
128000-0600 DENSO
128000-0609 DENSO
128000-2860 DENSO
128000-2861 DENSO
128000-2862 DENSO
128000-6210 DENSO
128000-6211 DENSO

UNISTART Price: £94.56

Sorry, this item is out of stock.

The 111310 - Starter is shown in: Starters & Alternators > Starters , Automotive > Starters & Alternators.

Fast Delivery - UK & Europe

We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.

You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us.  Replacements & refunds will be dispatched / issued on receipt of the returned items only.

Mfg. Model Engine Size Fuel From To KW HP Volume Cylinders Engine Type Brand Chassis Model Type Series
Suzuki, Passenger Car EU Swift 1 Gasoline 1983 10 1989 03 37 50 993 3 G10A Hatchback Swift
Suzuki, Passenger Car EU Swift 1.3 Gasoline 1989 03 1991 12 52 71 1324 4 G13A Swift
Suzuki, Passenger Car EU Swift 1.3 Gasoline 1989 10 1991 12 52 71 1324 4 G13A Hatchback 4WD Swift
Suzuki, Passenger Car EU Swift 1 Gasoline 1989 03 2001 05 37 50 993 3 G10A Hatchback Swift
Suzuki, Passenger Car EU Swift 1.3 Gasoline 1989 03 2001 05 50 68 1324 4 G13A Swift
Suzuki, Passenger Car EU Swift 1.3 Gasoline 1989 03 2001 05 74 101 1298 4 GTi G13B Hatchback Swift
Suzuki, Passenger Car EU Swift 1.6 Gasoline 1990 01 2001 05 68 92 1590 4 i G16B Swift
Suzuki, Passenger Car EU Swift 1.6 Gasoline 1989 11 1991 12 70 95 1590 4 G16B Swift
Suzuki, Passenger Car EU Baleno 1.3 Gasoline 1996 09 2002 05 52 71 1298 4 G13BA Hatchback Baleno
Suzuki, Passenger Car EU Swift 1 Gasoline 1983 10 1989 03 37 50 993 3 G10 Hatchback Swift
Suzuki, Passenger Car EU Swift 1.3 Gasoline 1985 08 1989 03 74 101 1289 4 GTi G13B Hatchback Swift
Suzuki, Passenger Car EU Swift 1 Gasoline 1991 09 2001 05 39 53 993 3 i G10A Hatchback Swift
Suzuki, Passenger Car EU Swift 1.6 Gasoline 1989 11 1991 12 70 95 1590 4 G16B 4WD Swift
Suzuki, Passenger Car EU Baleno 1.3 Gasoline 1995 07 2002 05 63 85 1298 4 i 16V G13BB Hatchback Baleno
Suzuki, Passenger Car EU Baleno 1.6 Gasoline 1995 07 2002 05 72 98 1590 4 i 16V G16B Hatchback Baleno
Suzuki, Passenger Car EU Baleno 1.6 Gasoline 1995 07 2002 05 72 98 1590 4 i 16V G16B Baleno
Suzuki, Passenger Car EU Baleno 1.6 Gasoline 1996 08 2002 05 72 98 1590 4 i 16V G16B Estate 4WD Baleno
Suzuki, Passenger Car EU Baleno 1.3 Gasoline 1997 03 2002 05 63 86 1298 4 16V G13BB Estate Baleno
Suzuki, Passenger Car EU Wagon 1.3 Gasoline 2000 05 2004 12 56 76 1298 4 G13BB MPV Wagon R+
Suzuki, Passenger Car EU Alto 1 Gasoline 2000 01 2002 06 43 58 993 4 G10B Hatchback Alto
Suzuki, Passenger Car EU Wagon 1 Gasoline 2003 07 2005 08 39 53 993 3 MPV Wagon R
Suzuki, Passenger Car EU Swift 1.3 Gasoline 1984 10 1989 03 50 68 1324 4 G13A Hatchback Swift
Suzuki, Passenger Car EU Swift 1.6 Gasoline 1990 01 2001 05 68 92 1590 4 i G16B 4WD Swift
Suzuki, Passenger Car EU Swift 1.3 Gasoline 1984 10 1989 03 54 73 1324 4 G13A Hatchback Swift
Suzuki, Passenger Car EU Swift 1 Gasoline 1989 03 1991 12 40 54 993 3 i G10A Hatchback Swift
Suzuki, Passenger Car EU Swift 1.3 Gasoline 1989 03 - 50 68 1298 4 G13A Hatchback Swift
Suzuki, Passenger Car EU Baleno 1.6 Gasoline 1995 07 2002 05 72 98 1590 4 i 16V G16B Hatchback 4WD Baleno
Suzuki, Passenger Car EU Baleno 1.3 Gasoline 1995 07 2002 05 63 85 1298 4 i 16V G13BB Baleno
Suzuki, Passenger Car EU Baleno 1.6 Gasoline 1995 07 2002 05 72 98 1590 4 i 16V G16B 4WD Baleno
Suzuki, Passenger Car EU Baleno 1.3 Gasoline 1996 09 2002 05 52 71 1298 4 G13BA Baleno
Suzuki, Passenger Car EU Swift 1.3 Gasoline 2001 06 2003 12 63 86 1298 4 G13BB Hatchback Swift
Suzuki, Passenger Car EU Swift 1.3 Gasoline 1991 09 1996 10 50 68 1298 4 G13BA Convertible Swift
Suzuki, Passenger Car EU Alto 1 Gasoline 1994 09 2002 06 39 53 993 4 G10BB Hatchback Alto
Suzuki, Passenger Car EU Baleno 1.6 Gasoline 1996 08 2002 05 72 98 1590 4 i 16V G16B Estate Baleno
Suzuki, Passenger Car EU Alto 1.1 Gasoline 2002 06 - 46 63 1061 4 F10D, F10DN Hatchback Alto
Suzuki, Passenger Car EU Swift 1.3 Gasoline 1989 03 2001 05 50 68 1324 4 G13A Hatchback 4WD Swift
Suzuki, Passenger Car EU Swift 1.3 Gasoline 1989 03 1991 12 52 71 1324 4 G13A Hatchback Swift
Suzuki, Passenger Car EU Swift 1.3 Gasoline 1986 08 1989 03 47 64 1324 4 G13A Hatchback Swift
Suzuki, Passenger cars US Swift 1.3 Gasoline 1991 01 1991 01 0 0 1298 L4 GL Swift
Suzuki, Passenger cars US Swift 1.3 Gasoline 2001 01 2001 01 0 0 1298 L4 Swift
Suzuki, Passenger cars US Swift 1.3 Gasoline 1990 01 1990 01 0 0 1298 L4 GL Swift
Suzuki, Passenger cars US Swift 1.3 Gasoline 1996 01 1997 01 0 0 1298 L4 GA Swift
Suzuki, Passenger cars US Swift 1.3 Gasoline 1990 01 1990 01 0 0 1298 L4 L Swift
Suzuki, Passenger cars US Swift 1.3 Gasoline 1991 01 1991 01 0 0 1298 L4 GLX Swift
Suzuki, Passenger cars US Swift 1.3 Gasoline 1992 01 1994 01 0 0 1298 L4 GS Swift
Suzuki, Passenger cars US Swift 1.3 Gasoline 1995 01 1997 01 0 0 1298 L4 DLX Swift
Suzuki, Passenger cars US Swift 1.3 Gasoline 1999 01 2000 01 0 0 1298 L4 Swift
Suzuki, Passenger cars US Swift 1.3 Gasoline 1998 01 1998 01 0 0 1298 L4 DLX Swift
Suzuki, Passenger cars US Swift 1.3 Gasoline 1998 01 1998 01 0 0 1298 L4 GA Swift
Suzuki, Passenger cars US Swift 1.3 Gasoline 1989 01 1994 01 0 0 1298 L4 GT Swift
Suzuki, Passenger cars US Swift 1.3 Gasoline 1990 01 1990 01 0 0 1298 L4 S Swift
Suzuki, Passenger cars US Swift 1.3 Gasoline 1991 01 1994 01 0 0 1298 L4 L Swift
Suzuki, Passenger cars US Swift 1.3 Gasoline 1989 01 1991 01 0 0 1298 L4 Swift
Suzuki, Passenger cars US Swift 1.3 Gasoline 1990 01 1994 01 0 0 1298 L4 GA Swift
Chevrolet, Passenger cars US Metro 1.3 Gasoline 1998 01 1998 01 0 0 1295 L4 LSI Metro
Chevrolet, Passenger cars US Metro 1 Gasoline 1999 01 2000 01 0 0 993 L3 Metro
Chevrolet, Passenger cars US Metro 1.3 Gasoline 2001 01 2001 01 0 0 1295 L4 LSI Metro
Chevrolet, Passenger cars US Sprint 1 Gasoline 1987 01 1988 01 0 0 993 L3 ER Sprint
Chevrolet, Passenger cars US Metro 1.3 Gasoline 1999 01 2000 01 0 0 1295 L4 Metro
Chevrolet, Passenger cars US Sprint 1 Gasoline 1987 01 1988 01 0 0 993 L3 Turbo Sprint
Chevrolet, Passenger cars US Metro 1 Gasoline 1998 01 1998 01 0 0 993 L3 Metro
Chevrolet, Passenger cars US Sprint 1 Gasoline 1985 01 - 0 0 993 L3 Sprint
Chevrolet, Passenger cars US Sprint 1 Gasoline 1986 01 1988 01 0 0 993 L3 Sprint
Chevrolet, Passenger cars US Sprint 1 Gasoline 1986 01 - 0 0 993 L3 Plus Sprint
