111399 - Starter (111399)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.


Voltage: 24, kW 4.0, Mount. flange 89.00, Drive dist. 38.00, Dist./back 252.50, Dist./front >85, No. of teeth 9, B+ M10, B- M8, Gear type DD, Dist. 89.00, Dist. 2 126.00, Dist. 3 89.00,
Rotation: CR, No./mount. holes 3 (0), Clutch type Dry,
Drive Type: Steel,
Total Length: 352.50, Oil sealed No, Waterproof No

Electrical specifications (Starter)
Voltage 24
kW 4.0

Physical specifications (Starter)
A Mount. flange 89.00
B Drive dist. 38.00
F Dist./back 252.50
G Dist./front >85
H No. of teeth 9
I B+ M10
S B- M8
N Gear type DD
O Dist. 89.00
O Dist. 2 126.00
O Dist. 3 89.00
P Rotation CR
R Total length 352.50

Further information (Starter)
No./mount. holes 3 (0)
Clutch type Dry
Drive type Steel
Oil sealed No
Waterproof No

Replacing
0001368083 BOSCH
1201327 DAF
19024262 REMY (DELCO)
859022 BUTEC
859506 BUTEC
AELB426 DAF
lns4524/9 BUTEC

UNISTART Price: £149.94

Sorry, this item is out of stock.

The 111399 - Starter is shown in: Starters & Alternators > Starters , Trucks, Trailers and Buses > Starters & Alternators.

Fast Delivery - UK & Europe

We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.

You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us.  Replacements & refunds will be dispatched / issued on receipt of the returned items only.

Mfg. Model Engine Size Fuel From To KW HP Volume Cylinders Engine Type Brand Chassis Model Type Series
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 96 131 5880 6 CN96 Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 107 146 5880 6 CT108 Platform / Chassis 45.15
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 107 146 5880 6 CS107M Platform / Chassis 45.15
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 119 162 5880 6 CS119 Platform / Chassis 45.16
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 119 162 5880 6 CT119 Platform / Chassis 45.16
DAF, Trucks EU 45 5.9 Diesel 1995 05 2000 12 133 181 5880 6 CS133M Platform / Chassis 45.18
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 108 147 5880 6 CT108 Platform / Chassis 45.15
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 107 146 5880 6 CB108 Platform / Chassis 45.15
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 85 116 5880 6 CD85 Platform / Chassis 45.12
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 96 131 5880 6 CS97M Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 97 132 5880 6 CS97M Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 97 132 5880 6 CT97 Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 96 131 5880 6 CT97 Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1995 05 2000 12 158 215 5880 6 CS158M Platform / Chassis 45.21
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 107 146 5880 6 CB108 Platform / Chassis 45.15
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 107 146 5880 6 CS107M Platform / Chassis 45.15
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 119 162 5880 6 CS119 Platform / Chassis 45.16
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 119 162 5880 6 CT119 Platform / Chassis 45.16
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 96 131 5880 6 CN96 Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 107 146 5880 6 CT108 Platform / Chassis 45.15
DAF, Trucks EU 45 5.9 Diesel 1995 05 2000 12 133 181 5880 6 CS133M Platform / Chassis 45.18
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 108 147 5880 6 CT108 Platform / Chassis 45.15
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 85 116 5880 6 CD85 Platform / Chassis 45.12
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 96 131 5880 6 CS97M Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 97 132 5880 6 CS97M Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 97 132 5880 6 CT97 Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1995 05 2000 12 158 215 5880 6 CS158M Platform / Chassis 45.21
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 96 131 5880 6 CT97 Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 119 162 5880 6 CT119 Platform / Chassis 45.16
DAF, Trucks EU 45 5.9 Diesel 1995 05 2000 12 133 181 5880 6 CS133M Platform / Chassis 45.18
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 108 147 5880 6 CT108 Platform / Chassis 45.15
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 107 146 5880 6 CB108 Platform / Chassis 45.15
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 107 146 5880 6 CT108 Platform / Chassis 45.15
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 107 146 5880 6 CS107M Platform / Chassis 45.15
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 119 162 5880 6 CS119 Platform / Chassis 45.16
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 85 116 5880 6 CD85 Platform / Chassis 45.12
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 96 131 5880 6 CS97M Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 96 131 5880 6 CT97 Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1995 05 2000 12 158 215 5880 6 CS158M Platform / Chassis 45.21
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 97 132 5880 6 CS97M Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 97 132 5880 6 CT97 Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1995 05 2000 12 133 181 5880 6 CS133M Platform / Chassis 45.18
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 108 147 5880 6 CT108 Platform / Chassis 45.15
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 107 146 5880 6 CS107M Platform / Chassis 45.15
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 119 162 5880 6 CS119 Platform / Chassis 45.16
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 119 162 5880 6 CT119 Platform / Chassis 45.16
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 96 131 5880 6 CN96 Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 107 146 5880 6 CT108 Platform / Chassis 45.15
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 107 146 5880 6 CB108 Platform / Chassis 45.15
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 85 116 5880 6 CD85 Platform / Chassis 45.12
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 96 131 5880 6 CS97M Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1991 05 2000 12 96 131 5880 6 CT97 Platform / Chassis 45.13
DAF, Trucks EU 45 5.9 Diesel 1995 05 2000 12 158 215 5880 6 CS158M Platform / Chassis 45.21
