111409 - Alternator (111409)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.


Voltage: 14,
Amp: 100,
Bracket Hole: 12.25, Belt. adj. bracket hole 10.80,
Width/Holder Arm: 22.00, Belt. adj. brackethole pos. 3,
Mount. Bracket Dist.: 54.35,
Pulley Dia.: 61.90,
Pulley Dist.: 41.00,
Grooves/Pulley: 7,
Radius: 90.00,
Radius: 90.00,
B+ Position: M8,
Rotation: CR,
Regulator Plug: or plug PL_NA,
Blower: IF, Pulley SP,
Total Length: 207.00

Electrical specifications (Alternator)
Voltage 14
Amp 100

Physical specifications (Alternator)
D Bracket hole 12.25
G Belt. adj. bracket hole 10.80
B Width/holder arm 22.00
E Belt. adj. brackethole pos. 3
C Mount. bracket dist. 54.35
H Pulley dia. 61.90
A Pulley dist. 41.00
i Grooves/pulley 7
j Radius 90.00
j Radius 90.00
k B+ position M8
n Rotation CR
o Regulator plug PL_NA
R Total length 207.00

Further information (Alternator)
Blower IF
Pulley SP

Replacing
111533 CARGO
46765835 FIAT
46765836 FIAT
60812583 ALFA ROMEO
63320226 MAGNETI MARELLI
63320256 MAGNETI MARELLI
63320292 MAGNETI MARELLI
63321241 MAGNETI MARELLI
63321246 MAGNETI MARELLI
63321349 MAGNETI MARELLI

UNISTART Price: £111.33

Sorry, this item is out of stock.

The 111409 - Alternator is shown in: Starters & Alternators > Alternators , Automotive > Starters & Alternators.

Fast Delivery - UK & Europe

We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.

You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us.  Replacements & refunds will be dispatched / issued on receipt of the returned items only.

Mfg. Model Engine Size Fuel From To KW HP Volume Cylinders Engine Type Brand Chassis Model Type Series
Alfa Romeo, Passenger Car EU Alfa 145 1.6 Gasoline 1994 10 1996 12 76 103 1596 4 i.e. AR33201 Hatchback Alfa 145
Alfa Romeo, Passenger Car EU Alfa 155 2 Gasoline 1995 03 1997 12 110 150 1970 4 Twin Spark 16V AR67299 Alfa 155
Alfa Romeo, Passenger Car EU Alfa 155 1.7 Gasoline 1996 05 1997 12 103 140 1747 4 Twin Spark 16V AR67106 Alfa 155
Alfa Romeo, Passenger Car EU Alfa 145 1.4 Gasoline 1996 12 2001 01 76 103 1370 4 i.e. 16V AR33503 Hatchback Alfa 145
Alfa Romeo, Passenger Car EU Alfa 146 1.4 Gasoline 1996 11 2001 01 76 103 1370 4 i.e. 16V AR33503 Hatchback Alfa 146
Alfa Romeo, Passenger Car EU Alfa 145 1.6 Gasoline 1996 12 2001 01 88 120 1598 4 i.e. 16V AR67601 Hatchback Alfa 145
Alfa Romeo, Passenger Car EU Alfa 156 1.6 Gasoline 1997 09 2005 09 88 120 1598 4 Twin Spark 16V AR32102 Alfa 156
Alfa Romeo, Passenger Car EU Alfa 156 2 Gasoline 1997 09 2000 10 114 155 1970 4 Twin Spark 16V AR32301 Alfa 156
Alfa Romeo, Passenger Car EU Spider 2 Gasoline 1998 05 2000 08 114 155 1970 4 16V AR32301 Convertible Spider
Alfa Romeo, Passenger Car EU GTV 1.8 Gasoline 1998 05 - 106 144 1747 4 16V AR32201 Coupe GTV
Alfa Romeo, Passenger Car EU Alfa 156 1.6 Gasoline 2000 05 - 88 120 1598 4 Twin Spark 16V AR32102 Estate Alfa 156
Alfa Romeo, Passenger Car EU Alfa 156 2 Gasoline 2000 05 2002 06 114 155 1970 4 Twin Spark 16V AR32301 Estate Alfa 156
Alfa Romeo, Passenger Car EU Alfa 156 1.8 Gasoline 2000 10 2006 05 103 140 1747 4 Twin Spark 16V AR32205 Estate Alfa 156
Alfa Romeo, Passenger Car EU Alfa 156 2 Gasoline 2000 10 2002 03 110 150 1970 4 Twin Spark 16V AR32310 Alfa 156
Alfa Romeo, Passenger Car EU Alfa 166 2.4 Diesel 2000 10 - 103 140 2387 5 JTD 839A6.000 Alfa 166
Alfa Romeo, Passenger Car EU Alfa 146 1.8 Gasoline 1998 03 2001 01 106 144 1747 4 Twin Spark i.e. 16V AR32201 Hatchback Alfa 146
Alfa Romeo, Passenger Car EU Alfa 146 2 Gasoline 1998 03 2001 01 114 155 1970 4 16V AR32301 Hatchback Alfa 146
Alfa Romeo, Passenger Car EU Alfa 156 1.6 Gasoline 2000 05 2006 05 88 120 1598 4 Twin Spark 16V AR32104 Estate Alfa 156
Alfa Romeo, Passenger Car EU Alfa 156 1.6 Gasoline 2000 05 - 88 120 1598 4 Twin Spark 16V AR32103 Estate Alfa 156
Alfa Romeo, Passenger Car EU Alfa 145 2 Gasoline 1995 10 2001 01 110 150 1970 4 Twin Spark i.e. 16V AR67204 Hatchback Alfa 145
Alfa Romeo, Passenger Car EU Alfa 146 1.6 Gasoline 1994 12 1996 12 76 103 1596 4 i.e. AR33201 Hatchback Alfa 146
Alfa Romeo, Passenger Car EU Alfa 156 1.9 Diesel 1997 09 2000 10 77 105 1910 4 JTD AR32302 Alfa 156
Alfa Romeo, Passenger Car EU Alfa 156 1.6 Gasoline 1997 09 2005 09 88 120 1598 4 Twin Spark 16V AR32103 Alfa 156
Alfa Romeo, Passenger Car EU Alfa 156 1.8 Gasoline 1997 09 2000 10 106 144 1747 4 Twin Spark 16V AR32201 Alfa 156
Alfa Romeo, Passenger Car EU Alfa 146 1.6 Gasoline 1996 11 2001 01 88 120 1598 4 i.e. 16V AR67601 Hatchback Alfa 146
Alfa Romeo, Passenger Car EU Alfa 145 2 Gasoline 1998 03 2001 01 114 155 1970 4 16V AR32301 Hatchback Alfa 145
Alfa Romeo, Passenger Car EU Spider 1.8 Gasoline 1998 05 2005 04 106 144 1747 4 16V AR32201 Convertible Spider
Alfa Romeo, Passenger Car EU Alfa 166 2 Gasoline 1998 09 2000 10 114 155 1970 4 Twin Spark AR34103 Alfa 166
Alfa Romeo, Passenger Car EU Alfa 156 1.8 Gasoline 2000 05 2000 10 106 144 1747 4 Twin Spark 16V AR32201 Estate Alfa 156
Alfa Romeo, Passenger Car EU Alfa 156 2.4 Diesel 2000 05 2003 09 100 136 2387 5 JTD AR32501 Estate Alfa 156
Alfa Romeo, Passenger Car EU Alfa 146 2 Gasoline 1995 10 2001 01 110 150 1970 4 Twin Spark 16V AR67204 Hatchback Alfa 146
Alfa Romeo, Passenger Car EU Spider 2 Gasoline 1995 06 2005 04 110 150 1970 4 Twin Spark 16V AR16201 Convertible Spider
Alfa Romeo, Passenger Car EU Alfa 155 2 Gasoline 1995 03 1997 12 110 150 1970 4 Twin Spark 16V AR67204 Alfa 155
Alfa Romeo, Passenger Car EU Alfa 145 1.4 Gasoline 1996 12 2001 01 76 103 1370 4 i.e. 16V AR38501 Hatchback Alfa 145
Alfa Romeo, Passenger Car EU Alfa 145 1.8 Gasoline 1996 12 1998 12 103 140 1747 4 i.e. 16V AR67106 Hatchback Alfa 145
Alfa Romeo, Passenger Car EU Alfa 156 2.4 Diesel 1997 09 2003 09 100 136 2387 5 JTD AR32501 Alfa 156
Alfa Romeo, Passenger Car EU Alfa 156 1.6 Gasoline 1997 09 2005 09 88 120 1598 4 Twin Spark 16V AR67601 Alfa 156
Alfa Romeo, Passenger Car EU Alfa 166 2.4 Diesel 1998 09 2000 10 100 136 2387 5 JTD AR34202 Alfa 166
Alfa Romeo, Passenger Car EU Alfa 145 1.8 Gasoline 1998 03 2001 01 106 144 1747 4 i.e. 16V AR32201 Hatchback Alfa 145
Alfa Romeo, Passenger Car EU Alfa 147 1.6 Gasoline 2001 01 2010 03 77 105 1598 4 Twin Spark 16V AR37203 Hatchback Alfa 147
Alfa Romeo, Passenger Car EU Alfa 156 1.8 Gasoline 2000 10 2005 09 103 140 1747 4 Twin Spark 16V AR32205 Alfa 156
Alfa Romeo, Passenger Car EU Alfa 166 2 Gasoline 2000 10 - 110 150 1970 4 Twin Spark AR36301 Alfa 166
Alfa Romeo, Passenger Car EU Alfa 156 2.4 Diesel 2000 10 2005 09 103 140 2387 5 JTD 839A6.000 Alfa 156
Alfa Romeo, Passenger Car EU Alfa 156 1.9 Diesel 2000 05 2000 10 77 105 1910 4 JTD AR32302 Estate Alfa 156
Alfa Romeo, Passenger Car EU Alfa 155 1.8 Gasoline 1992 02 1997 12 77 105 1756 4 Twin Spark AR67402 Alfa 155
Alfa Romeo, Passenger Car EU GTV 2 Gasoline 1995 06 - 110 150 1970 4 Twin Spark 16V AR32310 Coupe GTV
Alfa Romeo, Passenger Car EU Alfa 155 1.6 Gasoline 1996 05 1998 01 88 120 1598 4 Twin Spark AR67601 Alfa 155
Alfa Romeo, Passenger Car EU Alfa 146 1.8 Gasoline 1996 11 2001 01 103 140 1747 4 i.e. 16V AR67106 Hatchback Alfa 146
Alfa Romeo, Passenger Car EU Alfa 156 1.6 Gasoline 1997 09 2005 09 88 120 1598 4 Twin Spark 16V AR32104 Alfa 156
Alfa Romeo, Passenger Car EU GTV 2 Gasoline 1998 05 2000 08 114 155 1970 4 16V AR32301 Coupe GTV
Alfa Romeo, Passenger Car EU Alfa 147 2 Gasoline 2001 01 2010 03 110 150 1970 4 Twin Spark 16V AR32310 Hatchback Alfa 147
Alfa Romeo, Passenger Car EU Alfa 147 1.6 Gasoline 2001 01 2010 03 88 120 1598 4 Twin Spark 16V AR32104 Hatchback Alfa 147
Alfa Romeo, Passenger Car EU Alfa 156 1.6 Gasoline 2000 05 - 88 120 1598 4 Twin Spark 16V AR67601 Estate Alfa 156
Fiat, Passenger Car EU Brava 1.9 Diesel 1998 12 2001 10 77 105 1910 4 JTD 182B4.000 Hatchback Brava
Fiat, Passenger Car EU Multipla 1.9 Diesel 2001 03 2002 07 81 110 1910 4 JTD 186A6.000 MPV Multipla
Fiat, Passenger Car EU Marea 2.4 Diesel 1996 09 1999 04 91 125 2387 5 TD 185A2.000 Marea
Fiat, Passenger Car EU Barchetta 1.8 Gasoline 1995 04 2000 09 96 130 1747 4 16V 183A1.000 Convertible Barchetta
Fiat, Passenger Car EU Barchetta 1.8 Gasoline 2000 10 - 96 131 1747 4 16V 188A6.000 Convertible Barchetta
Fiat, Passenger Car EU Marea 1.9 Diesel 1999 04 2001 01 77 105 1910 4 JTD 182B4.000 Marea
Fiat, Passenger Car EU Marea 1.9 Diesel 2001 01 - 81 110 1910 4 JTD 186A6.000 Marea
Fiat, Passenger Car EU Brava 1.8 Gasoline 1995 10 2001 10 83 113 1747 4 16V 182A2.000 Hatchback GT Brava
Fiat, Passenger Car EU Marea 2.4 Diesel 1996 09 1999 04 91 125 2387 5 TD 185A2.000 Estate Marea
Fiat, Passenger Car EU Coupe 1.8 Gasoline 1996 03 2000 08 96 131 1747 4 16V 183A1.000 Coupe Coupe
Fiat, Passenger Car EU Bravo 1.9 Diesel 1998 12 2001 10 77 105 1910 4 JTD 182B4.000 Hatchback Bravo
Fiat, Passenger Car EU Punto 1.8 Gasoline 1999 09 - 96 130 1747 4 183A1.000 Hatchback HGT Punto
Fiat, Passenger Car EU Marea 1.9 Diesel 1999 04 - 77 105 1910 4 JTD 182B4.000 Estate Marea
Fiat, Passenger Car EU Punto 1.9 Diesel 1999 09 - 59 80 1910 4 JTD 188A2.000 Hatchback Punto
Fiat, Passenger Car EU Multipla 1.9 Diesel 1999 04 2010 06 77 105 1910 4 JTD 182B4.000 MPV Multipla
Fiat, Passenger Car EU Marea 1.9 Diesel 2001 01 - 81 110 1910 4 JTD 186A6.000 Estate Marea
Lancia, Passenger Car EU Kappa 2 Gasoline 1994 10 2001 10 107 146 1998 5 20V 838A1.000 Kappa
