111594 - Alternator (111594)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.


Voltage: 14,
Amp: 75,
Bracket Hole: 10.50, Belt. adj. bracket hole M8,
Width/Holder Arm: 13.00, Belt. adj. brackethole pos. 5,
Mount. Bracket Dist.: 55.00,
Pulley Dia.: 86.00,
Pulley Dist.: 42.50,
Grooves/Pulley: 2,
Radius: 88.00,
Radius: 89.00,
B+ Position: M8,
Rotation: CR,
Regulator Plug: or plug PL07,
Blower: IF, Pulley DP,
Total Length: 227.00

Electrical specifications (Alternator)
Voltage 14
Amp 75

Physical specifications (Alternator)
D Bracket hole 10.50
G Belt. adj. bracket hole M8
B Width/holder arm 13.00
E Belt. adj. brackethole pos. 5
C Mount. bracket dist. 55.00
H Pulley dia. 86.00
A Pulley dist. 42.50
i Grooves/pulley 2
j Radius 88.00
j Radius 89.00
k B+ position M8
n Rotation CR
o Regulator plug PL07
R Total length 227.00

Further information (Alternator)
Blower IF
Pulley DP

Replacing
A002T82899 MITSUBISHI
A002T82899A MITSUBISHI
A002T82899AT MITSUBISHI
A002T82899ZT MITSUBISHI
A002TN0499AT MITSUBISHI
a2t82899 MITSUBISHI
A2T82899A MITSUBISHI
a2t82899at MITSUBISHI
a2t82899zt MITSUBISHI
A2TN0499AT MITSUBISHI

UNISTART Price: £150.71

Sorry, this item is out of stock.

The 111594 - Alternator is shown in: Starters & Alternators > Alternators , Automotive > Starters & Alternators.

Fast Delivery - UK & Europe

We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.

You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us.  Replacements & refunds will be dispatched / issued on receipt of the returned items only.

Mfg. Model Engine Size Fuel From To KW HP Volume Cylinders Engine Type Brand Chassis Model Type Series
Mitsubishi, Passenger Car EU L 400 2.5 Diesel 1996 09 - 64 87 2477 4 TD 4D56T Van 2500 L 400
Mitsubishi, Passenger Car EU L 400 2.5 Diesel 1996 06 - 64 87 2477 4 TD 4D56T Bus 2500 L 400
Mitsubishi, Passenger Car EU L 200 2.5 Diesel 2001 08 2007 12 98 133 2477 4 TD 4D56T Pick Up 4WD L 200
Mitsubishi, Passenger Car EU Pajero 2.5 Diesel 2000 04 2006 12 73 99 2477 4 TDi 4D56T Convertible Pajero
Mitsubishi, Passenger Car EU L 300 2.5 Diesel 1988 11 - 64 87 2477 4 TD 4D56T Bus 4WD L 300
Mitsubishi, Passenger Car EU L 200 2.5 Diesel 1996 06 2007 12 55 75 2477 4 Diesel 4D56 Pick Up L 200
Mitsubishi, Passenger Car EU L 200 2.5 Diesel 2001 09 2007 12 85 115 2477 4 TD 4D56T Pick Up 4WD L 200
Mitsubishi, Passenger Car EU Pajero 2.5 Diesel 1990 12 2000 04 73 99 2477 4 TD 4D56TD Convertible Pajero
Mitsubishi, Passenger Car EU Pajero 2.5 Diesel 1990 12 1999 10 73 99 2477 4 TD 4D56TD Pajero
Mitsubishi, Passenger Car EU L 200 2.5 Diesel 1996 06 2007 12 73 99 2477 4 TD 4D56TD Pick Up 4WD L 200
Mitsubishi, Passenger Car EU L 200 2.5 Diesel 2001 11 2007 12 74 100 2477 4 TD 4D56 Pick Up 4WD L 200
Mitsubishi, Passenger Car EU L 400 2.5 Diesel 1996 09 - 64 87 2477 4 TD 4D56T Van 2500 L 400
Mitsubishi, Passenger Car EU L 400 2.5 Diesel 1996 06 - 64 87 2477 4 TD 4D56T Bus 2500 L 400
Mitsubishi, Passenger Car EU L 200 2.5 Diesel 2001 08 2007 12 98 133 2477 4 TD 4D56T Pick Up 4WD L 200
Mitsubishi, Passenger Car EU Pajero 2.5 Diesel 2000 04 2006 12 73 99 2477 4 TDi 4D56T Convertible Pajero
Mitsubishi, Passenger Car EU L 300 2.5 Diesel 1988 11 - 64 87 2477 4 TD 4D56T Bus 4WD L 300
Mitsubishi, Passenger Car EU L 200 2.5 Diesel 1996 06 2007 12 55 75 2477 4 Diesel 4D56 Pick Up L 200
Mitsubishi, Passenger Car EU L 200 2.5 Diesel 2001 09 2007 12 85 115 2477 4 TD 4D56T Pick Up 4WD L 200
Mitsubishi, Passenger Car EU Pajero 2.5 Diesel 1990 12 2000 04 73 99 2477 4 TD 4D56TD Convertible Pajero
Mitsubishi, Passenger Car EU Pajero 2.5 Diesel 1990 12 1999 10 73 99 2477 4 TD 4D56TD Pajero
Mitsubishi, Passenger Car EU L 200 2.5 Diesel 1996 06 2007 12 73 99 2477 4 TD 4D56TD Pick Up 4WD L 200
Mitsubishi, Passenger Car EU L 200 2.5 Diesel 2001 11 2007 12 74 100 2477 4 TD 4D56 Pick Up 4WD L 200
Mitsubishi, Passenger Car EU L 300 2.5 Diesel 1988 11 - 64 87 2477 4 TD 4D56T Bus 4WD L 300
Mitsubishi, Passenger Car EU L 400 2.5 Diesel 1996 09 - 64 87 2477 4 TD 4D56T Van 2500 L 400
Mitsubishi, Passenger Car EU L 400 2.5 Diesel 1996 06 - 64 87 2477 4 TD 4D56T Bus 2500 L 400
Mitsubishi, Passenger Car EU L 200 2.5 Diesel 2001 08 2007 12 98 133 2477 4 TD 4D56T Pick Up 4WD L 200
Mitsubishi, Passenger Car EU Pajero 2.5 Diesel 2000 04 2006 12 73 99 2477 4 TDi 4D56T Convertible Pajero
Mitsubishi, Passenger Car EU L 200 2.5 Diesel 1996 06 2007 12 55 75 2477 4 Diesel 4D56 Pick Up L 200
Mitsubishi, Passenger Car EU L 300 2.5 Diesel 1988 11 - 64 87 2477 4 TD 4D56T Bus 4WD L 300
Mitsubishi, Passenger Car EU L 200 2.5 Diesel 2001 09 2007 12 85 115 2477 4 TD 4D56T Pick Up 4WD L 200
Mitsubishi, Passenger Car EU Pajero 2.5 Diesel 1990 12 2000 04 73 99 2477 4 TD 4D56TD Convertible Pajero
Mitsubishi, Passenger Car EU Pajero 2.5 Diesel 1990 12 1999 10 73 99 2477 4 TD 4D56TD Pajero
Mitsubishi, Passenger Car EU L 200 2.5 Diesel 1996 06 2007 12 73 99 2477 4 TD 4D56TD Pick Up 4WD L 200
Mitsubishi, Passenger Car EU L 200 2.5 Diesel 2001 11 2007 12 74 100 2477 4 TD 4D56 Pick Up 4WD L 200

TEST & REPAIR SERVICE

Unistart has its own workshops for remanufacturing with the latest testing equipment. This enables us to provide an excellent (and free) technical helpline and aftersales support and backup service.

You can speak to one of our friendly and knowledgeable technicians who will be glad to Help with any enquiries no matter how large or small. Call us on 020 8 983 9969.
