111601 - Alternator (111601)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.


Voltage: 14,
Amp: 70,
Bracket Hole: 10.30, Belt. adj. bracket hole M8,
Width/Holder Arm: 69.00, Belt. adj. brackethole pos. 2,
Pulley Dia.: 76.35,
Pulley Dist.: 146.50,
Grooves/Pulley: 2,
Radius: 79.00,
Radius: 84.00,
B+ Position: M6,
Rotation: CR,
Regulator Plug: or plug PL42,
Blower: IF, Pulley DP,
Total Length: 231.00

Electrical specifications (Alternator)
Voltage 14
Amp 70

Physical specifications (Alternator)
D Bracket hole 10.30
G Belt. adj. bracket hole M8
B Width/holder arm 69.00
E Belt. adj. brackethole pos. 2
H Pulley dia. 76.35
A Pulley dist. 146.50
i Grooves/pulley 2
j Radius 79.00
j Radius 84.00
k B+ position M6
n Rotation CR
o Regulator plug PL42
R Total length 231.00

Further information (Alternator)
Blower IF
Pulley DP

Replacing
100211-5250 DENSO
100211-5251 DENSO
100211-5252 DENSO
100213-1900 DENSO
100213-1910 DENSO
100213-1911 DENSO
27040-54320 TOYOTA
27040-54340 TOYOTA
27060-54210 TOYOTA

UNISTART Price: £260.24

Sorry, this item is out of stock.

The 111601 - Alternator is shown in: Starters & Alternators > Alternators , Automotive > Starters & Alternators.

Fast Delivery - UK & Europe

We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.

You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us.  Replacements & refunds will be dispatched / issued on receipt of the returned items only.

Mfg. Model Engine Size Fuel From To KW HP Volume Cylinders Engine Type Brand Chassis Model Type Series
Toyota, Passenger Car EU Hiace 2.4 Diesel 1990 02 1995 08 55 75 2446 4 Diesel 2L Van Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1989 08 1995 08 55 75 2446 4 Diesel 2L Bus 4WD Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1989 08 1995 08 55 75 2446 4 Diesel 2L Bus Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1993 10 1995 08 57 78 2446 4 Diesel 2L Bus Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1989 08 1995 08 55 75 2446 4 Diesel 2L Van 4WD Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1990 02 1995 08 55 75 2446 4 Diesel 2L Van Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1989 08 1995 08 55 75 2446 4 Diesel 2L Bus 4WD Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1989 08 1995 08 55 75 2446 4 Diesel 2L Bus Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1993 10 1995 08 57 78 2446 4 Diesel 2L Bus Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1989 08 1995 08 55 75 2446 4 Diesel 2L Van 4WD Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1989 08 1995 08 55 75 2446 4 Diesel 2L Bus 4WD Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1993 10 1995 08 57 78 2446 4 Diesel 2L Bus Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1989 08 1995 08 55 75 2446 4 Diesel 2L Van 4WD Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1990 02 1995 08 55 75 2446 4 Diesel 2L Van Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1989 08 1995 08 55 75 2446 4 Diesel 2L Bus 4WD Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1993 10 1995 08 57 78 2446 4 Diesel 2L Bus Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1989 08 1995 08 55 75 2446 4 Diesel 2L Bus Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1989 08 1995 08 55 75 2446 4 Diesel 2L Van 4WD Hiace
