111609 - Alternator (111609)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.


Voltage: 14,
Amp: 70,
Bracket Hole: 10.30, Belt. adj. bracket hole M8,
Width/Holder Arm: 56.50, Belt. adj. brackethole pos. 52,
Pulley Dia.: 67.30,
Pulley Dist.: 90.00,
Grooves/Pulley: 5,
Radius: 80.00,
Radius: >85,
B+ Position: M6,
Rotation: ACR,
Regulator Plug: or plug PL14,
Blower: IF, Pulley SP,
Total Length: 166.00

Electrical specifications (Alternator)
Voltage 14
Amp 70

Physical specifications (Alternator)
D Bracket hole 10.30
G Belt. adj. bracket hole M8
B Width/holder arm 56.50
E Belt. adj. brackethole pos. 52
H Pulley dia. 67.30
A Pulley dist. 90.00
i Grooves/pulley 5
j Radius 80.00
j Radius >85
k B+ position M6
n Rotation ACR
o Regulator plug PL14
R Total length 166.00

Further information (Alternator)
Blower IF
Pulley SP

Replacing
100211-3310 DENSO
100211-3311 DENSO
100211-7770 DENSO
100211-7810 DENSO
100211-7811 DENSO
100211-9980 DENSO
101211-0030 DENSO
101211-0033 DENSO
31100-pk2-003 HONDA
31100-pk2-0031 HONDA

UNISTART Price: £143.73

Sorry, this item is out of stock.

The 111609 - Alternator is shown in: Starters & Alternators > Alternators , Automotive > Starters & Alternators , Trucks, Trailers and Buses > Starters & Alternators.

Fast Delivery - UK & Europe

We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.

You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us.  Replacements & refunds will be dispatched / issued on receipt of the returned items only.

Mfg. Model Engine Size Fuel From To KW HP Volume Cylinders Engine Type Brand Chassis Model Type Series
Honda, Passenger cars US Prelude 2 Gasoline 1988 01 1989 01 0 0 1958 L4 2.0 S Prelude
Honda, Passenger cars US Prelude 2 Gasoline 1990 01 1990 01 0 0 1958 L4 2.0 S Prelude
Honda, Passenger cars US Prelude 2.1 Gasoline 1990 01 1991 01 0 0 2056 L4 B21A1 SI ALB Prelude
Honda, Passenger cars US Prelude 2 Gasoline 1988 01 1989 01 0 0 1958 L4 2.0 SI Prelude
Honda, Passenger cars US Prelude 2 Gasoline 1988 01 1989 01 0 0 1958 L4 2.0 SI 4WS Prelude
Honda, Passenger cars US Prelude 2 Gasoline 1990 01 1990 01 0 0 1958 L4 2.0 SI Prelude
Honda, Passenger cars US Prelude 2.1 Gasoline 1990 01 1991 01 0 0 2056 L4 B21A1 SI 4WS Prelude
Honda, Passenger cars US Prelude 2 Gasoline 1991 01 1991 01 0 0 1958 L4 SE Prelude
Honda, Passenger cars US Prelude 2 Gasoline 1990 01 1990 01 0 0 1958 L4 SR Prelude
Honda, Passenger cars US Prelude 2 Gasoline 1991 01 1991 01 0 0 1958 L4 B20A5 2.0 SI Prelude
Honda, Passenger cars US Prelude 2.1 Gasoline 1990 01 - 0 0 2056 L4 Si B21A1 Prelude
Honda, Passenger Car EU Legend 2.7 Gasoline 1988 01 1990 12 124 169 2675 6 i 24V C27A1 Legend
Honda, Passenger Car EU Prelude 2 Gasoline 1987 04 1992 01 80 109 1958 4 B20A3 Coupe Prelude
Honda, Passenger Car EU Prelude 2 Gasoline 1986 04 1987 12 101 137 1958 4 i 16V B20A1 Coupe EX Prelude
Honda, Passenger Car EU Prelude 2 Gasoline 1987 08 1992 01 84 114 1958 4 B20A4 Coupe Prelude
Honda, Passenger Car EU Prelude 2 Gasoline 1986 04 1987 12 101 137 1958 4 i 16V B20A1 Coupe EX Prelude
Honda, Passenger Car EU Prelude 2 Gasoline 1987 04 1992 01 101 137 1958 4 i 16V B20A5 Coupe EX Prelude
Honda, Passenger Car EU Prelude 2 Gasoline 1990 04 1992 01 103 140 1958 4 i 16V B20A9 Coupe EX Prelude
Honda, Passenger Car EU Legend 2.5 Gasoline 1986 01 1987 12 110 150 2494 6 i C25A1 Legend
Honda, Passenger Car EU Prelude 2 Gasoline 1987 10 1990 12 110 150 1958 4 i 16V B20A7 Coupe EX Prelude
