111740 - Alternator (111740)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.

Voltage: 14,
Amp: 70, Terminal BS/W,
Bracket Hole: 8.20, Belt. adj. bracket hole M8,
Width/Holder Arm: 11.30, Belt. adj. brackethole pos. 50,
Mount. Bracket Dist.: 82.70,
Pulley Dia.: 76.00,
Pulley Dist.: 35.50,
Grooves/Pulley: 1,
Radius: >85,
Radius: >85,
B+ Position: M6,
Rotation: CR,
Regulator Plug: or plug PL22,
Blower: EF, Pulley P, Remarks w/ battery sensor terminal.,
Total Length: 167.00

Electrical specifications (Alternator)
Voltage	14
Amp	70
Terminal	BS/W

Physical specifications (Alternator)
D	Bracket hole 8.20
G	Belt. adj. bracket hole M8
B	Width/holder arm 11.30
E	Belt. adj. brackethole pos. 50
C	Mount. bracket dist. 82.70
H	Pulley dia. 76.00
A	Pulley dist. 35.50
i	Grooves/pulley 1
j	Radius >85
j	Radius >85
k	B+ position M6
n	Rotation CR
o	Regulator plug PL22
R	Total length 167.00

Further information (Alternator)
Blower	EF
Pulley	P
Remarks	w/ battery sensor terminal.

Replacing
11.201.503	ISKRA
11.201.504	ISKRA
24186	LUCAS
24186a	LUCAS
24186b	LUCAS
24186D	LUCAS
24250	LUCAS
24250a	LUCAS
24250B	LUCAS
24274	LUCAS

UNISTART Price: £73.83
