111833 - Alternator (111833)
Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.
Voltage: 28,
Amp: 140, Terminal W,
Bracket Hole: M12-1.50, Belt. adj. bracket hole M12-1.50,
Width/Holder Arm: 15.70, Belt. adj. brackethole pos. 50,
Mount. Bracket Dist.: 182.00,
Radius: 120.00,
Radius: 120.00,
B+ Position: M8,
Rotation: CR/ACR,
Regulator Plug: or plug PL_NA,
Blower: EF, Pulley w/o, Remarks B- M8. Shaft 30 mm. Heavy duty type: HC-CARGO 113589. 180 A.,
Total Length: 302.00
Electrical specifications (Alternator) | ||||
| Voltage | 28 | |||
| Amp | 140 | |||
| Terminal | W | |||
Physical specifications (Alternator) | ||||
| D | Bracket hole M12-1.50 | |||
| G | Belt. adj. bracket hole M12-1.50 | |||
| B | Width/holder arm 15.70 | |||
| E | Belt. adj. brackethole pos. 50 | |||
| C | Mount. bracket dist. 182.00 | |||
| j | Radius 120.00 | |||
| j | Radius 120.00 | |||
| k | B+ position M8 | |||
| n | Rotation CR/ACR | |||
| o | Regulator plug PL_NA | |||
| R | Total length 302.00 | |||
Further information (Alternator) | ||||
| Blower | EF | |||
| Pulley | w/o | |||
| Remarks | B- M8. Shaft 30 mm. Heavy duty type: HC-CARGO 113589. 180 A. | |||
Replacing | ||||
| 0081547802 | MERCEDES BENZ | |||
| 0111545002 | MERCEDES BENZ | |||
| 0120689530 | BOSCH | |||
| 0120689535 | BOSCH | |||
| 0120689571 | BOSCH | |||
| 0120689574 | BOSCH | |||
| 0120689587 | BOSCH | |||
| 0131547302 | MERCEDES BENZ | |||
| 11.201.519 | ISKRA | |||
| 11.201.757 | ISKRA | |||
UNISTART Price: £367.77
Fast Delivery - UK & Europe
We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.
You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us. Replacements & refunds will be dispatched / issued on receipt of the returned items only.
| Mfg. | Model | Engine Size | Fuel | From | To | KW | HP | Volume | Cylinders | Engine Type | Brand | Chassis | Model Type | Series |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1984 12 | - | 150 | 204 | 11967 | 6 | OM447.913 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1985 11 | - | 177 | 241 | 11967 | 6 | OM447.908 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1985 11 | - | 177 | 241 | 11967 | 6 | OM447.971 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1985 11 | - | 206 | 280 | 11967 | 6 | OM427.950 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1985 11 | - | 206 | 280 | 11967 | 6 | OM447.950 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1985 11 | - | 177 | 241 | 11967 | 6 | OM447.907 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 407 | 12 | Diesel | 1991 11 | 2001 11 | 220 | 299 | 11967 | 6 | OM447.985 | Bus | O 407 | ||
| Mercedes-Benz, Trucks EU | O 408 | 12 | Diesel | 1991 01 | 1998 12 | 184 | 250 | 11967 | 6 | OM447.912 | Bus | O 408 | ||
| Mercedes-Benz, Trucks EU | O 408 | 12 | Diesel | 1992 08 | 1998 12 | 220 | 299 | 11967 | 6 | OM447.987 | Bus | O 408 | ||
| Mercedes-Benz, Trucks EU | O 404 | 14.6 | Diesel | 1994 09 | 1999 10 | 280 | 381 | 14618 | 8 | OM446.938 | Bus | O 404 | ||
| Mercedes-Benz, Trucks EU | O 404 | 14.6 | Diesel | 1994 09 | 1999 10 | 280 | 381 | 14618 | 8 | OM446.934 | Bus | O 404 | ||
| Mercedes-Benz, Trucks EU | O 303 | 11 | Diesel | 1980 01 | 1992 09 | 159 | 216 | 10964 | 6 | OM441.908 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | Citaro | 12 | Diesel | 1998 01 | - | 260 | 354 | 11967 | OM457.957 | Bus | O 530 N | |||
| Mercedes-Benz, Trucks EU | Tourino | 6.4 | Diesel | 2003 10 | - | 205 | 279 | 6374 | 6 | OM906.961 | Bus | O 510 | ||
| Mercedes-Benz, Trucks EU | Citaro | 12 | Gasoline | 2000 04 | - | 240 | 326 | 11967 | 6 | M476.933 | Bus | O 530 NG | ||
| Mercedes-Benz, Trucks EU | O 303 | 11 | Diesel | 1980 01 | 1989 01 | 159 | 216 | 10964 | 6 | OM441.908 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1984 12 | - | 150 | 204 | 11967 | 6 | OM427.905 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1985 11 | - | 177 | 241 | 11967 | 6 | OM447.956 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1991 11 | - | 220 | 299 | 11967 | 6 | OM447.981 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1985 11 | - | 177 | 241 | 11967 | 6 | OM427.911 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 407 | 12 | Diesel | 1987 03 | 2001 11 | 177 | 241 | 11967 | 6 | OM447.906 | Bus | O 407 | ||
| Mercedes-Benz, Trucks EU | O 404 | 15.1 | Diesel | 1991 09 | 1992 01 | 195 | 265 | 15100 | 8 | OM442.931 | Bus | O 404 | ||
| Mercedes-Benz, Trucks EU | Citaro | 12 | Gasoline | 2000 04 | - | 240 | 326 | 11967 | 6 | M476.934 | Bus | O 530 NG | ||
| Mercedes-Benz, Trucks EU | Citaro | 12 | Diesel | 1998 01 | - | 260 | 354 | 11967 | OM457.973 | Bus | O 530 N | |||
| Mercedes-Benz, Trucks EU | Citaro | 12 | Diesel | 1998 01 | - | 220 | 299 | 11967 | 6 | OM457.959 | Bus | O 530 | ||
| Mercedes-Benz, Trucks EU | Citaro | 12 | Diesel | 1998 01 | - | 220 | 299 | 11967 | 6 | OM457.943 | Bus | O 530 | ||
| Mercedes-Benz, Trucks EU | O 404 | 9.6 | Diesel | 1991 09 | 1999 10 | 213 | 290 | 9572 | 6 | OM401.970 | Bus | O 404 | ||
| Mercedes-Benz, Trucks EU | O 404 | 11.3 | Diesel | 1991 09 | 1992 01 | 165 | 224 | 11300 | 6 | OM441.921 | Bus | O 404 | ||
| Mercedes-Benz, Trucks EU | O 404 | 12.8 | Diesel | 1991 09 | 1999 10 | 280 | 381 | 12763 | 8 | OM402.970 | Bus | O 404 | ||
| Mercedes-Benz, Trucks EU | O 404 | 11 | Diesel | 1994 09 | 1999 10 | 213 | 290 | 10964 | 6 | OM445.935 | Bus | O 404 | ||
| Mercedes-Benz, Trucks EU | 25t | 14.6 | Diesel | 1991 01 | 1996 09 | 370 | 503 | 14618 | 8 | OM440.998 | Semi-Trailer | 2550 | ||
| Mercedes-Benz, Trucks EU | O 303 | 14.6 | Diesel | 1980 01 | 1987 09 | 206 | 280 | 14618 | 8 | OM422.908 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 303 | 14.6 | Diesel | 1987 09 | 1992 09 | 260 | 354 | 14618 | 8 | OM442.954 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 303 | 14.6 | Diesel | 1987 09 | 1992 09 | 260 | 354 | 14618 | 8 | OM442.955 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1984 12 | - | 150 | 204 | 11967 | 6 | OM447.914 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1985 11 | - | 177 | 241 | 11967 | 6 | OM447.957 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1985 11 | - | 177 | 241 | 11967 | 6 | OM447.974 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1985 11 | - | 206 | 280 | 11967 | 6 | OM447.951 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1991 11 | - | 220 | 299 | 11967 | 6 | OM447.986 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1991 11 | - | 220 | 299 | 11967 | 6 | OM447.972 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1985 11 | - | 177 | 241 | 11967 | 6 | OM447.959 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1986 01 | - | 206 | 280 | 11967 | 6 | OM447.950 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 407 | 12 | Diesel | 1987 03 | 2001 11 | 177 | 241 | 11967 | 6 | OM447.908 | Bus | O 407 | ||
| Mercedes-Benz, Trucks EU | O 407 | 12 | Diesel | 1987 03 | 2001 11 | 177 | 241 | 11967 | 6 | OM447.954 | Bus | O 407 | ||
| Mercedes-Benz, Trucks EU | O 407 | 12 | Diesel | 1991 11 | 2001 11 | 220 | 299 | 11967 | 6 | OM447.991 | Bus | O 407 | ||
| Mercedes-Benz, Trucks EU | O 303 | 11 | Diesel | 1987 12 | 1992 09 | 200 | 272 | 10964 | 6 | OM441.953 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 303 | 11 | Diesel | 1980 01 | 1989 01 | 159 | 216 | 10964 | 6 | OM441.909 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | Citaro | 12 | Gasoline | 2000 06 | - | 185 | 252 | 11967 | 6 | M476.934 | Bus | O 530 NG | ||
| Mercedes-Benz, Trucks EU | Citaro | 12 | Diesel | 1998 01 | - | 260 | 354 | 11967 | OM457.942 | Bus | O 530 N | |||
| Mercedes-Benz, Trucks EU | Citaro | 12 | Diesel | 1998 01 | - | 220 | 299 | 11967 | OM457.973 | Bus | O 530 N | |||
| Mercedes-Benz, Trucks EU | Citaro | 12 | Diesel | 1998 01 | - | 260 | 354 | 11967 | OM457.950 | Bus | O 530 N | |||
| Mercedes-Benz, Trucks EU | O 404 | 11.3 | Diesel | 1991 09 | 1992 01 | 151 | 205 | 11300 | 6 | OM441.922 | Bus | O 404 | ||
| Mercedes-Benz, Trucks EU | O 404 | 11 | Diesel | 1991 09 | 1999 10 | 250 | 340 | 10964 | 6 | OM445.934 | Bus | O 404 | ||
| Mercedes-Benz, Trucks EU | O 404 | 15.1 | Diesel | 1991 09 | 1992 01 | 213 | 290 | 15100 | 8 | OM442.930 | Bus | O 404 | ||
| Mercedes-Benz, Trucks EU | O 303 | 11 | Diesel | 1980 01 | 1992 09 | 159 | 216 | 10964 | 6 | OM441.909 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 303 | 11 | Diesel | 1985 11 | 1989 04 | 184 | 250 | 10964 | 6 | OM421.951 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 303 | 11 | Diesel | 1987 12 | 1992 09 | 200 | 272 | 10964 | 6 | OM441.950 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 303 | 11 | Diesel | 1980 01 | 1989 01 | 159 | 216 | 10964 | 6 | OM421.908 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 303 | 11 | Diesel | 1980 01 | 1989 01 | 159 | 216 | 10964 | 6 | OM441.918 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 303 | 15.1 | Diesel | 1987 09 | 1992 09 | 213 | 290 | 15080 | 8 | OM442.918 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 303 | 15.1 | Diesel | 1987 09 | 1992 09 | 213 | 290 | 15080 | 8 | OM442.939 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 402 | 6 | Diesel | 1986 02 | 1991 12 | 100 | 136 | 5958 | 6 | OM366.917 | Bus | O 402 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1984 12 | - | 150 | 204 | 11967 | 6 | OM447.973 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1985 11 | - | 177 | 241 | 11967 | 6 | OM427.910 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1985 11 | - | 177 | 241 | 11967 | 6 | OM447.910 | Bus | O 405 | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1985 11 | - | 177 | 241 | 11967 | 6 | OM447.978 | Bus | O 405 GN | ||
| Mercedes-Benz, Trucks EU | O 405 | 12 | Diesel | 1991 09 | - | 220 | 299 | 11967 | 6 | OM447.984 | Bus | O 405 GN | ||
| Mercedes-Benz, Trucks EU | O 408 | 12 | Diesel | 1992 08 | 1998 12 | 220 | 299 | 11967 | 6 | OM447.993 | Bus | O 408 | ||
| Mercedes-Benz, Trucks EU | Axor 2 | 12 | Diesel | 2009 06 | - | 295 | 401 | 11967 | 6 | OM457.956 | Dump Truck | 4140 K | ||
| Mercedes-Benz, Trucks EU | Axor 2 | 12 | Diesel | 2009 06 | - | 295 | 401 | 11967 | 6 | OM457.957 | Dump Truck | 4140 K | ||
| Mercedes-Benz, Trucks EU | Axor 2 | 12 | Diesel | 2009 06 | - | 315 | 428 | 11967 | 6 | OM457.956 | Dump Truck | 4143 K | ||
| Mercedes-Benz, Trucks EU | Axor 2 | 12 | Diesel | 2009 06 | - | 315 | 428 | 11967 | 6 | OM457.957 | Dump Truck | 4143 K | ||
| Mercedes-Benz, Trucks EU | O 303 | 11 | Diesel | 1980 01 | 1989 01 | 159 | 216 | 10964 | 6 | OM441.911 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 303 | 11 | Diesel | 1980 01 | 1992 09 | 159 | 216 | 10964 | 6 | OM421.908 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 303 | 15.1 | Diesel | 1987 09 | 1992 09 | 213 | 290 | 15080 | 8 | OM442.910 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 303 | 15.1 | Diesel | 1987 09 | 1992 09 | 213 | 290 | 15080 | 8 | OM442.919 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 303 | 15.1 | Diesel | 1987 09 | 1992 09 | 213 | 290 | 15080 | 8 | OM442.911 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 303 | 14.6 | Diesel | 1987 09 | 1992 09 | 260 | 354 | 14618 | 8 | OM442.960 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 303 | 14.6 | Diesel | 1987 09 | 1992 09 | 260 | 354 | 14618 | 8 | OM442.961 | Bus | O 303 | ||
| Mercedes-Benz, Trucks EU | O 402 | 6 | Diesel | 1986 02 | 1991 12 | 125 | 170 | 5958 | 6 | OM366.965 | Bus | O 402 | ||
| Mercedes-Benz, Trucks EU | O 408 | 12 | Diesel | 1991 01 | 1998 12 | 184 | 250 | 11967 | 6 | OM447.958 | Bus | O 408 | ||
| Mercedes-Benz, Trucks EU | O 408 | 12 | Diesel | 1991 01 | 1998 12 | 184 | 250 | 11967 | 6 | OM447.992 | Bus | O 408 | ||
| Mercedes-Benz, Trucks EU | Tourismo | 14.6 | Diesel | 1995 08 | - | 280 | 381 | 14618 | 8 | OM446.938 | Bus | O 350 | ||
| Mercedes-Benz, Trucks EU | O 404 | 9.8 | Diesel | 1991 09 | 1999 10 | 200 | 272 | 9800 | 6 | OM401.974 | Bus | O 404 | ||
| Mercedes-Benz, Trucks EU | O 404 | 11 | Diesel | 1991 09 | 1999 10 | 250 | 340 | 10964 | 6 | OM441.980 | Bus | O 404 | ||
| Mercedes-Benz, Trucks EU | 17t | 6 | Diesel | 1984 01 | 1998 12 | 150 | 204 | 5958 | 6 | OM366.995 | Platform / Chassis | 1720 | ||
| Mercedes-Benz, Trucks EU | 11t | 6 | Diesel | 1984 04 | 1998 12 | 125 | 170 | 5958 | 6 | OM357.907 | Dump Truck | 1117 | ||
| Mercedes-Benz, Trucks EU | Tourismo | 11 | Diesel | 1995 08 | - | 250 | 340 | 10964 | 6 | OM445.934 | Bus | O 350 | ||
| Mercedes-Benz, Trucks EU | Citaro | 12 | Diesel | 1998 01 | - | 220 | 299 | 11967 | OM457.942 | Bus | O 530 N | |||
| Mercedes-Benz, Trucks EU | Citaro | 12 | Diesel | 1998 01 | - | 220 | 299 | 11967 | OM457.949 | Bus | O 530 N | |||
| Mercedes-Benz, Trucks EU | Citaro | 12 | Diesel | 1998 01 | - | 220 | 299 | 11967 | 6 | OM457.973 | Bus | O 530 | ||
| Setra, Trucks EU | 300 Series | 12 | Diesel | 1991 09 | 2002 02 | 220 | 299 | 11967 | Bus | S 315 | ||||
| Setra, Trucks EU | 300 Series | 12 | Diesel | 1991 09 | 2002 02 | 220 | 299 | 11967 | Bus | S 321 | ||||
| Setra, Trucks EU | 300 Series | 14.6 | Diesel | 1991 09 | 2002 02 | 320 | 435 | 14618 | OM442.980 | Bus | S 317 | |||
| Setra, Trucks EU | 300 Series | 12 | Diesel | 1991 09 | 2002 02 | 220 | 299 | 11967 | Bus | S 313 | ||||
| Setra, Trucks EU | 300 Series | 14.6 | Diesel | 1991 09 | 2002 02 | 385 | 524 | 14618 | Bus | S 328 | ||||
| Setra, Trucks EU | 300 Series | 14.6 | Diesel | 1991 09 | 2002 02 | 280 | 381 | 14618 | OM446.930 | Bus | S 315 | |||
| Drögmöller, Trucks EU | E | - | - | 0 | 0 | 0 | Bus | Various Models | ||||||
| Various Agriculture Vehicles, Agricultural | Various Agriculture Vehicles | - | - | 0 | 0 | 0 |
