111988 - Alternator (111988)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.


Voltage: 14,
Amp: 120,
Bracket Hole: 8.50, Belt. adj. bracket hole 8.50,
Width/Holder Arm: 13.90, Belt. adj. brackethole pos. 45,
Mount. Bracket Dist.: 59.00,
Pulley Dia.: 49.70,
Pulley Dist.: 39.00,
Grooves/Pulley: 6,
Radius: 90.00,
Radius: 90.00,
B+ Position: M8,
Rotation: CR,
Regulator Plug: or plug PL45,
Blower: IF, Pulley SP,
Total Length: 194.00

Electrical specifications (Alternator)
Voltage 14
Amp 120

Physical specifications (Alternator)
D Bracket hole 8.50
G Belt. adj. bracket hole 8.50
B Width/holder arm 13.90
E Belt. adj. brackethole pos. 45
C Mount. bracket dist. 59.00
H Pulley dia. 49.70
A Pulley dist. 39.00
i Grooves/pulley 6
j Radius 90.00
j Radius 90.00
k B+ position M8
n Rotation CR
o Regulator plug PL45
R Total length 194.00

Further information (Alternator)
Blower IF
Pulley SP

Replacing
0123505011 BOSCH
0123510027 BOSCH
0123515014 BOSCH
0123515018 BOSCH
028903018b VOLKSWAGEN
028903018BX VOLKSWAGEN
028903025s VOLKSWAGEN
028903025SX VOLKSWAGEN
028903027d VOLKSWAGEN
1018818 FORD

UNISTART Price: £187.71

Sorry, this item is out of stock.

The 111988 - Alternator is shown in: Starters & Alternators > Alternators , Automotive > Starters & Alternators.

Fast Delivery - UK & Europe

We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.

You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us.  Replacements & refunds will be dispatched / issued on receipt of the returned items only.

Mfg. Model Engine Size Fuel From To KW HP Volume Cylinders Engine Type Brand Chassis Model Type Series
VW, Passenger Car EU Golf 1.9 Diesel 1993 09 1997 08 66 90 1896 4 TDi 1Z Hatchback Golf III
VW, Passenger Car EU Vento 1.9 Diesel 1993 09 1998 09 66 90 1896 4 TDi ALE Vento
VW, Passenger Car EU Golf 1.9 Diesel 1995 08 1998 05 66 90 1896 4 TDi AHU Convertible Golf III
VW, Passenger Car EU Golf 1.9 Diesel 1995 07 1997 08 47 64 1896 4 SDi AEY Hatchback Golf III
VW, Passenger Car EU Golf 1.9 Diesel 1998 04 2001 12 66 90 1896 4 TDi ALE Convertible Golf IV
VW, Passenger Car EU Golf 1.9 Diesel 1993 09 1997 08 66 90 1896 4 TDi AHU Hatchback Golf III
VW, Passenger Car EU Golf 1.9 Diesel 1994 03 1999 04 66 90 1896 4 TDi 1Z Estate Golf III
VW, Passenger Car EU Polo 1.9 Diesel 1996 09 2000 08 66 90 1896 4 TDi AHU Polo
VW, Passenger Car EU Polo 1.9 Diesel 1997 11 1999 08 66 90 1896 4 TDi ALE Estate Polo
VW, Passenger Car EU Passat 1.9 Diesel 1993 10 1996 08 66 90 1896 4 TDi 1Z Passat
VW, Passenger Car EU Golf 1.9 Diesel 1996 04 1997 08 81 110 1896 4 TDi AFN Hatchback Golf III
VW, Passenger Car EU Passat 1.9 Diesel 1993 10 1996 08 66 90 1896 4 TDi AHU Passat
VW, Passenger Car EU Passat 1.9 Diesel 1993 10 1997 05 66 90 1896 4 TDi 1Z Estate Passat
VW, Passenger Car EU Polo 1.9 Diesel 1998 06 2001 09 81 110 1896 4 TDi AFN Polo
VW, Passenger Car EU Passat 1.9 Diesel 1993 10 1997 05 66 90 1896 4 TDi AHU Estate Passat
VW, Passenger Car EU Golf 1.9 Diesel 1994 03 1999 04 66 90 1896 4 TDi AHU Estate Golf III
VW, Passenger Car EU Golf 1.9 Diesel 1996 05 1997 12 66 90 1896 4 TDi ALE Hatchback Syncro Golf III
VW, Passenger Car EU Golf 1.9 Diesel 1995 07 1999 04 66 90 1896 4 TDi 1Z Estate Golf III
VW, Passenger Car EU Golf 1.9 Diesel 1995 07 1999 04 66 90 1896 4 TDi AHU Estate Golf III
VW, Passenger Car EU Polo 1.9 Diesel 1998 06 2001 09 81 110 1896 4 TDi AFN Estate Polo
VW, Passenger Car EU Golf 1.9 Diesel 1997 05 1997 12 66 90 1896 4 TDi ALE Hatchback Golf III
VW, Passenger Car EU Vento 1.9 Diesel 1993 09 1998 09 66 90 1896 4 TDi 1Z Vento
VW, Passenger Car EU Vento 1.9 Diesel 1993 09 1998 09 66 90 1896 4 TDi AHU Vento
VW, Passenger Car EU Golf 1.9 Diesel 1995 08 1998 05 66 90 1896 4 TDi 1Z Convertible Golf III
VW, Passenger Car EU Golf 1.9 Diesel 1995 03 1996 07 66 90 1896 4 TDi 1Z Hatchback Syncro Golf III
VW, Passenger Car EU Golf 1.9 Diesel 1996 08 1997 12 66 90 1896 4 TDi AHU Hatchback Syncro Golf III
VW, Passenger Car EU Golf 1.9 Diesel 1998 04 2000 06 66 90 1896 4 TDi AHU Convertible Golf IV
Seat, Passenger Car EU Cordoba 1.9 Diesel 1996 08 1999 06 66 90 1896 4 TDi 1Z Cordoba
Seat, Passenger Car EU Cordoba 1.9 Diesel 1996 08 1999 06 66 90 1896 4 TDi AHU Cordoba
Seat, Passenger Car EU Alhambra 1.9 Diesel 1996 04 - 66 90 1896 4 TDi AHU MPV Alhambra
Seat, Passenger Car EU Alhambra 1.9 Diesel 1996 04 - 66 90 1896 4 TDi 1Z MPV Alhambra
Seat, Passenger Car EU Cordoba 1.9 Diesel 1997 03 1999 06 81 110 1896 4 TDi AFN Cordoba
Seat, Passenger Car EU Ibiza 1.9 Diesel 1997 02 1999 08 81 110 1896 4 TDi AFN Hatchback Ibiza
Seat, Passenger Car EU Toledo 1.9 Diesel 1996 11 1999 03 81 110 1896 4 TDi AFN Hatchback Toledo
Seat, Passenger Car EU Toledo 1.9 Diesel 1995 08 1999 03 66 90 1896 4 TDi AHU Hatchback Toledo
Seat, Passenger Car EU Ibiza 1.9 Diesel 1996 08 1999 08 66 90 1896 4 TDi 1Z Hatchback Ibiza
Seat, Passenger Car EU Ibiza 1.9 Diesel 1996 08 1999 08 66 90 1896 4 TDi AHU Hatchback Ibiza
VW, Passenger Car EU Passat 1.9 Diesel 1993 10 1996 08 66 90 1896 4 TDi 1Z Passat
VW, Passenger Car EU Polo 1.9 Diesel 1997 11 1999 08 66 90 1896 4 TDi ALE Polo
VW, Passenger Car EU Golf 1.9 Diesel 1997 05 1997 12 66 90 1896 4 TDi ALE Hatchback Golf III
