112067 - Alternator (112067)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.


Voltage: 14,
Amp: 80,
Bracket Hole: M10, Belt. adj. bracket hole 8.50,
Width/Holder Arm: 13.50, Belt. adj. brackethole pos. 60,
Mount. Bracket Dist.: 67.00,
Pulley Dia.: 55.00,
Pulley Dist.: 39.00,
Grooves/Pulley: 4,
Radius: 90.00,
Radius: >85,
B+ Position: M8,
Rotation: CR,
Regulator Plug: or plug PL54,
Blower: IF, Pulley SP,
Total Length: 163.00

Electrical specifications (Alternator)
Voltage 14
Amp 80

Physical specifications (Alternator)
D Bracket hole M10
G Belt. adj. bracket hole 8.50
B Width/holder arm 13.50
E Belt. adj. brackethole pos. 60
C Mount. bracket dist. 67.00
H Pulley dia. 55.00
A Pulley dist. 39.00
i Grooves/pulley 4
j Radius 90.00
j Radius >85
k B+ position M8
n Rotation CR
o Regulator plug PL54
R Total length 163.00

Further information (Alternator)
Blower IF
Pulley SP

Replacing
A002TB0191 MITSUBISHI
A002TB0191A MITSUBISHI
A002TB0191B MITSUBISHI
A002TB7791 MITSUBISHI
a2tb0191 MITSUBISHI
a2tb0191a MITSUBISHI
a2tb0191b MITSUBISHI
A2TB0191BD MITSUBISHI
A2TB7791 MITSUBISHI
BP6D-18-300 MAZDA

UNISTART Price: £113.10

Sorry, this item is out of stock.

The 112067 - Alternator is shown in: Starters & Alternators > Alternators , Automotive > Starters & Alternators.

Fast Delivery - UK & Europe

We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.

You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us.  Replacements & refunds will be dispatched / issued on receipt of the returned items only.

Mfg. Model Engine Size Fuel From To KW HP Volume Cylinders Engine Type Brand Chassis Model Type Series
Mazda, Passenger Car EU 626 2 Gasoline 1998 02 2002 10 100 136 1991 4 FS2C Estate 626
Mazda, Passenger Car EU 626 1.8 Gasoline 1997 05 1999 12 66 90 1840 4 FPY3 Hatchback 626
Mazda, Passenger Car EU 323 1.8 Gasoline 1998 09 2001 01 84 114 1840 4 16V FP Hatchback 323
Mazda, Passenger Car EU 323 2 Gasoline 2001 01 2004 05 96 131 1991 4 FS7G Hatchback 323 F
Mazda, Passenger Car EU 626 2 Gasoline 1997 05 2002 10 85 115 1991 4 FS 626
Mazda, Passenger Car EU 626 2 Gasoline 1998 02 2002 10 100 136 1991 4 FS2C Hatchback 626
Mazda, Passenger Car EU 626 1.8 Gasoline 1999 12 2002 10 74 100 1840 4 FP Hatchback 626
Mazda, Passenger Car EU 323 1.6 Gasoline 2001 01 2004 05 72 98 1598 4 ZM Hatchback 323 F
Mazda, Passenger Car EU 323 1.6 Gasoline 2001 01 2004 05 70 95 1598 4 ZM Hatchback 323 F
Mazda, Passenger Car EU MX 1.9 Gasoline 2000 11 2005 10 102 139 1840 4 16V BPD Convertible MX-5
Mazda, Passenger Car EU MX 1.6 Gasoline 1998 05 2005 10 81 110 1598 4 16V B6D Convertible MX-5
Mazda, Passenger Car EU 626 1.8 Gasoline 1998 02 2000 01 66 90 1840 4 FPY3 Estate 626
Mazda, Passenger Car EU 323 1.9 Gasoline 1998 09 2004 05 84 114 1840 4 16V FP 323
Mazda, Passenger Car EU Premacy 1.8 Gasoline 1999 07 - 74 100 1840 4 FP MPV Premacy
Mazda, Passenger Car EU Premacy 1.8 Gasoline 1999 07 - 84 114 1840 4 FP MPV Premacy
Mazda, Passenger Car EU 626 1.8 Gasoline 1999 12 2002 10 74 100 1840 4 FP9A 626
Mazda, Passenger Car EU Premacy 2 Gasoline 2001 11 - 96 131 1991 4 FS7G MPV Premacy
Mazda, Passenger Car EU 323 2 Gasoline 2001 01 2004 05 96 131 1991 4 FS7E Hatchback 323 F
Mazda, Passenger Car EU 323 2 Gasoline 2001 01 - 96 131 1991 4 FS7E 323 S
Mazda, Passenger Car EU 626 2.2 Gasoline 1991 05 1992 11 85 116 2184 4 12V F2L1 Estate 4WD 626
Mazda, Passenger Car EU 626 2 Gasoline 1997 05 2002 10 85 115 1991 4 FS Hatchback 626
Mazda, Passenger Car EU 626 2 Gasoline 1998 02 2002 10 85 116 1991 4 FS Estate 626
Mazda, Passenger Car EU 323 1.6 Gasoline 2001 01 2004 05 72 98 1598 4 ZM 323 S
Mazda, Passenger Car EU 323 2 Gasoline 2001 01 2004 05 96 131 1991 4 FS7G 323 S
Mazda, Passenger Car EU 626 1.8 Gasoline 1997 05 1999 12 66 90 1840 4 FPY3 626
Mazda, Passenger Car EU MX 1.8 Gasoline 1998 05 2005 10 103 140 1840 4 16V BPZE Convertible MX-5
Mazda, Passenger Car EU 626 2 Gasoline 1998 04 2002 10 100 136 1991 4 FS2C 626
Mazda, Passenger Car EU 626 1.8 Gasoline 2000 01 2002 10 74 100 1840 4 FP9A Estate 626
Mazda, Passenger Car EU MX 1.8 Gasoline 2000 11 2005 10 107 146 1840 4 16V BPD Convertible MX-5
Mazda, Passenger Car EU Xedos 2.5 Gasoline 2000 07 - 120 163 2497 6 V6 KL Xedos 9
Mazda, Passenger Car EU 323 1.6 Gasoline 2001 01 2004 05 70 95 1598 4 ZM 323 S
Mazda, Passenger cars US Protege 2 Gasoline 2002 01 2003 01 0 0 2000 L4 ES Protege
Mazda, Passenger cars US Protege 2 Gasoline 2003 01 - 0 0 2000 L4 DX Protege
Mazda, Passenger cars US Protege 2 Gasoline 2002 01 - 0 0 2000 L4 DX Protege
Mazda, Passenger cars US Protege 2 Gasoline 2001 01 2001 01 0 0 2000 L4 Protege
Mazda, Passenger cars US Protege 2 Gasoline 2002 01 2003 01 0 0 2000 L4 LX Protege
Mazda, Passenger cars US Protege 1.8 Gasoline 1999 01 2000 01 0 0 1839 L4 Protege
Mazda, Passenger cars US Protege 2 Gasoline 2003 01 2003 01 0 0 1975 L4 5 Protege
Mazda, Passenger cars US Protege 2 Gasoline 2002 01 2002 01 0 0 2000 L4 5 Protege
Mazda, Passenger cars US Protege 2 Gasoline 2003 01 2003 01 0 0 2000 L4 Turbo Mazda Speed Protege
Mazda, Passenger cars US Protege 2 Gasoline 2001 01 2002 01 0 0 2000 L4 MP3 Protege
