112124 - Starter (112124)
Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.
Voltage: 12, kW 0.9, Mount. flange 64.10, Drive dist. 11.00, Dist./back 152.00, Dist./front 47.00, No. of teeth 8,9, B+ M8, Gear type DD/GR, Dist. 105.00, Dist. 2 71.50, Dist. 3 72.50,
Rotation: CR, No./mount. holes 3 (3),
Drive Type: Steel,
Total Length: 206.00, Oil sealed No, Waterproof No
Electrical specifications (Starter) | ||||
| Voltage | 12 | |||
| kW | 0.9 | |||
Physical specifications (Starter) | ||||
| A | Mount. flange 64.10 | |||
| B | Drive dist. 11.00 | |||
| F | Dist./back 152.00 | |||
| G | Dist./front 47.00 | |||
| H | No. of teeth 8,9 | |||
| I | B+ M8 | |||
| N | Gear type DD/GR | |||
| O | Dist. 105.00 | |||
| O | Dist. 2 71.50 | |||
| O | Dist. 3 72.50 | |||
| P | Rotation CR | |||
| R | Total length 206.00 | |||
Further information (Starter) | ||||
| No./mount. | holes 3 (3) | |||
| Drive | type Steel | |||
| Oil | sealed No | |||
| Waterproof | No | |||
Replacing | ||||
| 063103002000 | MAKO | |||
| 063103002010 | MAGNETI MARELLI | |||
| 063103007000 | MAKO | |||
| 063103007010 | MAGNETI MARELLI | |||
| 063216731000 | MAKO | |||
| 063223101000 | MAKO | |||
| 46231540 | FIAT | |||
| 46417006 | FIAT | |||
| 46475793 | FIAT | |||
| 46774415 | FIAT | |||
UNISTART Price: £96.66
Fast Delivery - UK & Europe
We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.
You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us. Replacements & refunds will be dispatched / issued on receipt of the returned items only.
| Mfg. | Model | Engine Size | Fuel | From | To | KW | HP | Volume | Cylinders | Engine Type | Brand | Chassis | Model Type | Series |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Fiat, Passenger Car EU | Tipo | 1.6 | Gasoline | 1988 02 | 1991 05 | 66 | 90 | 1595 | 4 | i.e. | 149C2.046 | Hatchback | Tipo | |
| Fiat, Passenger Car EU | Tempra | 1.6 | Gasoline | 1994 06 | 1996 08 | 66 | 90 | 1581 | 4 | i.e. | 159B9.000 | Tempra | ||
| Fiat, Passenger Car EU | Brava | 1.6 | Gasoline | 1996 02 | 2001 10 | 76 | 103 | 1581 | 4 | 16V | 182A4.000 | Hatchback | SX | Brava |
| Fiat, Passenger Car EU | Punto | 1.4 | Gasoline | 1996 09 | 1999 09 | 96 | 131 | 1372 | 4 | Turbo | 176B6.000 | Hatchback | GT | Punto |
| Fiat, Passenger Car EU | Tempra | 1.6 | Gasoline | 1994 06 | 1996 08 | 63 | 87 | 1581 | 4 | i.e. | 159B9.000 | Tempra | ||
| Fiat, Passenger Car EU | Palio | 1.4 | Gasoline | 1996 04 | - | 51 | 69 | 1372 | 4 | 178B2.016 | Hatchback | Palio | ||
| Fiat, Passenger Car EU | Siena | 1.4 | Gasoline | 1996 04 | - | 51 | 69 | 1372 | 4 | 178B2.000 | Siena | |||
| Fiat, Passenger Car EU | Palio | 1.6 | Gasoline | 1996 04 | 2001 02 | 74 | 100 | 1581 | 4 | 16V | 178B3.000 | Estate | Palio | |
| Fiat, Passenger Car EU | Palio | 1.4 | Gasoline | 1996 04 | - | 51 | 69 | 1372 | 4 | 178B2.000 | Hatchback | Palio | ||
| Fiat, Passenger Car EU | Siena | 1.4 | Gasoline | 1996 04 | - | 51 | 69 | 1372 | 4 | 178B2.016 | Siena | |||
| Fiat, Passenger Car EU | Marea | 1.6 | Gasoline | 1999 04 | - | 76 | 103 | 1581 | 4 | 16V Bipower | 185A3.000 | Marea | ||
| Fiat, Passenger Car EU | Bravo | 1.6 | Gasoline | 1996 03 | 2001 10 | 76 | 103 | 1581 | 4 | 182A4.000 | Hatchback | SX | Bravo | |
| Fiat, Passenger Car EU | Marea | 1.6 | Gasoline | 1996 09 | - | 76 | 103 | 1581 | 4 | i 16V | 182A4.000 | Estate | Marea | |
| Fiat, Passenger Car EU | Palio | 1.6 | Gasoline | 1996 04 | - | 74 | 100 | 1581 | 4 | 16V | 178B3.000 | Hatchback | Palio | |
| Fiat, Passenger Car EU | Siena | 1.6 | Gasoline | 1998 09 | - | 78 | 106 | 1581 | 4 | 16V | 178B3.000 | Siena | ||
| Fiat, Passenger Car EU | Tempra | 1.6 | Gasoline | 1994 06 | 1996 08 | 66 | 90 | 1581 | 4 | i.e. | 159B9.000 | Estate | Tempra | |
| Fiat, Passenger Car EU | Punto | 1.4 | Gasoline | 1994 01 | 1996 09 | 98 | 133 | 1372 | 4 | Turbo | 176A4.000 | Hatchback | GT | Punto |
| Fiat, Passenger Car EU | Marea | 1.6 | Gasoline | 1996 09 | - | 76 | 103 | 1581 | 4 | i 16V | 182A4.000 | Marea | ||
| Fiat, Passenger Car EU | Scudo | 1.6 | Gasoline | 1996 02 | 2006 12 | 58 | 79 | 1581 | 4 | 220A2.000 | Estate | Scudo | ||
| Fiat, Passenger Car EU | Brava | 1.6 | Gasoline | 1995 10 | 2001 10 | 66 | 90 | 1581 | 4 | 16V | 182A6.000 | Hatchback | EL | Brava |
| Fiat, Passenger Car EU | Scudo | 1.6 | Gasoline | 1996 02 | - | 58 | 79 | 1581 | 4 | 220A2.000 | Van | Scudo | ||
| Lancia, Passenger Car EU | Delta | 1.6 | Gasoline | 1996 03 | 1999 08 | 66 | 90 | 1581 | 4 | i.e. | 182A6.000 | Hatchback | LE | Delta |
| Lancia, Passenger Car EU | Delta | 1.6 | Gasoline | 1993 06 | 1999 08 | 55 | 75 | 1581 | 4 | i.e. | 835C1.000 | Hatchback | Delta | |
| Lancia, Passenger Car EU | Delta | 1.4 | Gasoline | 1994 10 | 1999 08 | 51 | 69 | 1372 | 4 | i.e. | 836A4.000 | Hatchback | Delta | |
| Lancia, Passenger Car EU | Dedra | 1.6 | Gasoline | 1994 10 | 1999 07 | 66 | 90 | 1581 | 4 | 159B9.000 | Estate | Dedra | ||
| Lancia, Passenger Car EU | Dedra | 1.6 | Gasoline | 1994 07 | 1999 07 | 66 | 90 | 1581 | 4 | 159B9.000 | LE | Dedra | ||
| Lancia, Passenger Car EU | Dedra | 1.6 | Gasoline | 1993 04 | 1999 07 | 55 | 75 | 1581 | 4 | i.e. | 835C1.000 | Dedra | ||
| Lancia, Passenger Car EU | Y | 1 | Gasoline | 1985 03 | 1989 02 | 62 | 84 | 1049 | 4 | Turbo | 156A1.000 | Hatchback | Y10 | |
| Citroen, Passenger Car EU | Jumpy | 1.6 | Gasoline | 1995 10 | - | 58 | 79 | 1581 | 4 | i | 1580SPI | Van | Jumpy | |
| Citroen, Passenger Car EU | Jumpy | 1.6 | Gasoline | 1995 10 | - | 58 | 79 | 1581 | 4 | 1580SPI | MPV | Jumpy | ||
| Peugeot, Passenger Car EU | Expert | 1.6 | Gasoline | 1996 02 | - | 58 | 79 | 1581 | 4 | 222A2 | Platform / Chassis | Expert |
