112197 - Alternator (112197)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.


Voltage: 14,
Amp: 115,
Bracket Hole: 9.00, Belt. adj. bracket hole 9.00,
Width/Holder Arm: 69.80, Belt. adj. brackethole pos. 60,
Mount. Bracket Dist.: 56.00,
Pulley Dia.: 49.50,
Pulley Dist.: 31.00,
Grooves/Pulley: 6,
B+ Position: M8,
Rotation: CR,
Regulator Plug: or plug PL_NA,
Blower: IF, Pulley SP/FW,
Total Length: 176,00

Electrical specifications (Alternator)
Voltage 14
Amp 115

Physical specifications (Alternator)
D Bracket hole 9.00
G Belt. adj. bracket hole 9.00
B Width/holder arm 69.80
E Belt. adj. brackethole pos. 60
C Mount. bracket dist. 56.00
H Pulley dia. 49.50
A Pulley dist. 31.00
i Grooves/pulley 6
k B+ position M8
n Rotation CR
o Regulator plug PL_NA
R Total length 176,00

Further information (Alternator)
Blower IF
Pulley SP/FW

Replacing
0101545902 MERCEDES BENZ
0101549502 MERCEDES BENZ
0101549602 MERCEDES BENZ
0111540902 MERCEDES BENZ
0111547802 MERCEDES BENZ
0121542402 MERCEDES BENZ
0121545402 MERCEDES BENZ
0123510082 BOSCH
0123510107 BOSCH
0123510108 BOSCH

UNISTART Price: £128.69

Sorry, this item is out of stock.

The 112197 - Alternator is shown in: Starters & Alternators > Alternators , Automotive > Starters & Alternators.

Fast Delivery - UK & Europe

We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.

You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us.  Replacements & refunds will be dispatched / issued on receipt of the returned items only.

Mfg. Model Engine Size Fuel From To KW HP Volume Cylinders Engine Type Brand Chassis Model Type Series
Mercedes-Benz, Passenger Car EU 200 2.2 Diesel 1998 03 2001 03 75 102 2151 4 CDi OM611.960 Estate C 200
Mercedes-Benz, Passenger Car EU 220 2.2 Diesel 1999 07 2002 03 105 143 2148 4 CDi OM611.961 E 220
Mercedes-Benz, Passenger Car EU Sprinter 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Bus Sprinter 316
Mercedes-Benz, Passenger Car EU 208 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Van 208
Mercedes-Benz, Passenger Car EU 213 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Van 213
Mercedes-Benz, Passenger Car EU 313 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Van 313
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Bus Sprinter 408
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Bus Sprinter 411
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Platform / Chassis 4x4 Sprinter 411
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Platform / Chassis 4x4 Sprinter 413
Mercedes-Benz, Passenger Car EU 220 2.2 Diesel 1998 06 1999 07 92 125 2151 4 CDi OM611.961 Estate E 220
Mercedes-Benz, Passenger Car EU Sprinter 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Bus Sprinter 416
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Platform / Chassis Sprinter 413
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Van 4x4 Sprinter 413
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Bus Sprinter 208
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Bus Sprinter 308
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Bus Sprinter 313
Mercedes-Benz, Passenger Car EU 308 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Van 308
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Van Sprinter 311
Mercedes-Benz, Passenger Car EU 220 2.2 Diesel 1999 03 2003 07 90 122 2148 4 CDi OM611.980 MPV V 220
Mercedes-Benz, Passenger Car EU 220 2.2 Diesel 1998 06 1999 07 92 125 2151 4 CDi OM611.961 E 220
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Bus Sprinter 413
Mercedes-Benz, Passenger Car EU Sprinter 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Platform / Chassis 4x4 Sprinter 416
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Van Sprinter 413
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Van 4x4 Sprinter 411
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Bus Sprinter 213
Mercedes-Benz, Passenger Car EU 216 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Platform / Chassis 216
Mercedes-Benz, Passenger Car EU 308 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Platform / Chassis 308
Mercedes-Benz, Passenger Car EU 316 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Platform / Chassis 316
Mercedes-Benz, Passenger Car EU 200 2.1 Diesel 1999 07 2002 03 85 116 2148 4 CDi OM611.961 E 200
Mercedes-Benz, Passenger Car EU Vito 2.2 Diesel 1999 03 2003 07 60 82 2151 4 CDi OM611LA Van Vito 108
Mercedes-Benz, Passenger Car EU Vito 2.2 Diesel 1999 03 2003 07 60 82 2148 4 CDi OM611A Bus Vito 108
Mercedes-Benz, Passenger Car EU 220 2.1 Diesel 1999 05 2003 03 100 136 2148 4 CDI OM611.961 Estate E 220 T
Mercedes-Benz, Passenger Car EU 220 2.1 Diesel 1999 07 2002 03 100 136 2148 4 CDI OM611.961 E 220
Mercedes-Benz, Passenger Car EU 220 2.2 Diesel 1997 09 2001 03 92 125 2151 4 CDi OM611.960 Estate C 220
Mercedes-Benz, Passenger Car EU Vito 2.2 Diesel 1999 03 2003 07 75 102 2148 4 CDi OM611LA Bus Vito 110
Mercedes-Benz, Passenger Car EU Sprinter 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Bus Sprinter 216
Mercedes-Benz, Passenger Car EU 208 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Platform / Chassis 208
Mercedes-Benz, Passenger Car EU 211 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Platform / Chassis 211
Mercedes-Benz, Passenger Car EU 316 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Van 316
Mercedes-Benz, Passenger Car EU 313 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Platform / Chassis 313
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Platform / Chassis Sprinter 411
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Van Sprinter 411
Mercedes-Benz, Passenger Car EU Sprinter 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Van Sprinter 416
Mercedes-Benz, Passenger Car EU Sprinter 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Van 4x4 Sprinter 416
Mercedes-Benz, Passenger Car EU 220 2.2 Diesel 1997 09 2000 05 92 125 2151 4 CDi OM611.960 C 220
Mercedes-Benz, Passenger Car EU 200 2.2 Diesel 1998 06 2002 03 75 102 2151 4 CDi OM611.961 E 200
Mercedes-Benz, Passenger Car EU 200 2 Diesel 1998 03 2000 05 75 102 2151 4 CDi OM611.960 C 200
Mercedes-Benz, Passenger Car EU 200 2.2 Diesel 1999 03 2003 07 75 102 2148 4 CDi OM611.980 MPV V 200
Mercedes-Benz, Passenger Car EU Vito 2.2 Diesel 1999 03 2003 07 75 102 2151 4 CDi OM611LA Van Vito 110
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Platform / Chassis Sprinter 408
Mercedes-Benz, Passenger Car EU Sprinter 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Platform / Chassis Sprinter 416
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Bus Sprinter 211
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Bus Sprinter 311
Mercedes-Benz, Passenger Car EU 211 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Van 211
Mercedes-Benz, Passenger Car EU 216 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Van 216
Mercedes-Benz, Passenger Car EU 200 2.2 Diesel 1998 03 2001 03 75 102 2151 4 CDi OM611.960 Estate C 200
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Bus Sprinter 408
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Bus Sprinter 411
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Platform / Chassis 4x4 Sprinter 411
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Platform / Chassis 4x4 Sprinter 413
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Van Sprinter 408
Mercedes-Benz, Passenger Car EU Sprinter 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Bus Sprinter 316
Mercedes-Benz, Passenger Car EU 208 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Van 208
Mercedes-Benz, Passenger Car EU 213 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Van 213
Mercedes-Benz, Passenger Car EU 313 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Van 313
Mercedes-Benz, Passenger Car EU 220 2.2 Diesel 1999 07 2002 03 105 143 2148 4 CDi OM611.961 E 220
Mercedes-Benz, Passenger Car EU 220 2.2 Diesel 1998 06 1999 07 92 125 2151 4 CDi OM611.961 Estate E 220
Mercedes-Benz, Passenger Car EU Sprinter 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Bus Sprinter 416
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Platform / Chassis Sprinter 413
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Van 4x4 Sprinter 413
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Bus Sprinter 208
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Bus Sprinter 308
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Bus Sprinter 313
Mercedes-Benz, Passenger Car EU 308 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Van 308
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Van Sprinter 311
Mercedes-Benz, Passenger Car EU Vito 2.2 Diesel 1999 03 2003 07 90 122 2148 4 CDi OM611.980 Bus Vito 112
Mercedes-Benz, Passenger Car EU 220 2.2 Diesel 1998 06 1999 07 92 125 2151 4 CDi OM611.961 E 220
Mercedes-Benz, Passenger Car EU 220 2.2 Diesel 1999 03 2003 07 90 122 2148 4 CDi OM611.980 MPV V 220
Mercedes-Benz, Passenger Car EU Vito 2.2 Diesel 1999 03 2003 07 60 82 2148 4 CDi OM611A Bus Vito 108
Mercedes-Benz, Passenger Car EU 200 2.1 Diesel 1999 07 2002 03 85 116 2148 4 CDi OM611.961 E 200
Mercedes-Benz, Passenger Car EU 308 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Platform / Chassis 308
Mercedes-Benz, Passenger Car EU 316 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Platform / Chassis 316
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Bus Sprinter 413
Mercedes-Benz, Passenger Car EU Sprinter 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Platform / Chassis 4x4 Sprinter 416
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Van Sprinter 413
Mercedes-Benz, Passenger Car EU 216 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Platform / Chassis 216
Mercedes-Benz, Passenger Car EU 220 2.1 Diesel 1999 05 2003 03 100 136 2148 4 CDI OM611.961 Estate E 220 T
Mercedes-Benz, Passenger Car EU 220 2.1 Diesel 1999 07 2002 03 100 136 2148 4 CDI OM611.961 E 220
Mercedes-Benz, Passenger Car EU 220 2.2 Diesel 1997 09 2001 03 92 125 2151 4 CDi OM611.960 Estate C 220
Mercedes-Benz, Passenger Car EU Vito 2.2 Diesel 1999 03 2003 07 75 102 2148 4 CDi OM611LA Bus Vito 110
Mercedes-Benz, Passenger Car EU Sprinter 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Bus Sprinter 216
Mercedes-Benz, Passenger Car EU 208 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Platform / Chassis 208
Mercedes-Benz, Passenger Car EU 211 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Platform / Chassis 211
Mercedes-Benz, Passenger Car EU 316 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Van 316
Mercedes-Benz, Passenger Car EU 313 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Platform / Chassis 313
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Platform / Chassis Sprinter 411
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Van Sprinter 411
Mercedes-Benz, Passenger Car EU Sprinter 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Van Sprinter 416
Mercedes-Benz, Passenger Car EU Sprinter 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Van 4x4 Sprinter 416
Mercedes-Benz, Passenger Car EU 220 2.2 Diesel 1997 09 2000 05 92 125 2151 4 CDi OM611.960 C 220
Mercedes-Benz, Passenger Car EU 200 2.2 Diesel 1998 06 2002 03 75 102 2151 4 CDi OM611.961 E 200
Mercedes-Benz, Passenger Car EU 200 2 Diesel 1998 03 2000 05 75 102 2151 4 CDi OM611.960 C 200
Mercedes-Benz, Passenger Car EU 200 2.2 Diesel 1999 03 2003 07 75 102 2148 4 CDi OM611.980 MPV V 200
Mercedes-Benz, Passenger Car EU Vito 2.2 Diesel 1999 03 2003 07 75 102 2151 4 CDi OM611LA Van Vito 110
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 60 82 2148 4 CDi OM611.987 Platform / Chassis Sprinter 408
Mercedes-Benz, Passenger Car EU Sprinter 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Platform / Chassis Sprinter 416
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Bus Sprinter 211
Mercedes-Benz, Passenger Car EU Sprinter 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Bus Sprinter 311
Mercedes-Benz, Passenger Car EU 211 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Van 211
Mercedes-Benz, Passenger Car EU 216 2.7 Diesel 2000 04 2006 05 115 156 2685 5 CDi OM612.981 Van 216
Mercedes-Benz, Passenger Car EU 213 2.1 Diesel 2000 04 2006 05 95 129 2148 4 CDi OM611.981 Platform / Chassis 213
Mercedes-Benz, Passenger Car EU 311 2.1 Diesel 2000 04 2006 05 80 109 2148 4 CDi OM611.981 Platform / Chassis 311
Mercedes-Benz, Passenger Car EU 220 2.2 Diesel 1998 06 1999 07 92 125 2151 4 CDi OM611.961 E 220
Mercedes-Benz, Passenger Car EU 220 2.1 Diesel 1999 05 2003 03 100 136 2148 4 CDI OM611.961 Estate E 220 T
Mercedes-Benz, Passenger Car EU 220 2.1 Diesel 1999 07 2002 03 100 136 2148 4 CDI OM611.961 E 220
Mercedes-Benz, Passenger Car EU Vito 2.2 Diesel 1999 03 - 90 122 2151 4 CDi OM611.980 Van Vito 112
