112274 - Alternator (112274)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.


Voltage: 14,
Amp: 90,
Bracket Hole: 8.50, Belt. adj. bracket hole 8.50,
Width/Holder Arm: 14.10, Belt. adj. brackethole pos. 45,
Mount. Bracket Dist.: 61.40,
Pulley Dia.: 49.60,
Pulley Dist.: 39.50,
Grooves/Pulley: 6,
Radius: 90.00,
Radius: 90.00,
B+ Position: M8,
Rotation: CR,
Regulator Plug: or plug PL61,
Blower: IF, Pulley SP,
Total Length: 185.00

Electrical specifications (Alternator)
Voltage 14
Amp 90

Physical specifications (Alternator)
D Bracket hole 8.50
G Belt. adj. bracket hole 8.50
B Width/holder arm 14.10
E Belt. adj. brackethole pos. 45
C Mount. bracket dist. 61.40
H Pulley dia. 49.60
A Pulley dist. 39.50
i Grooves/pulley 6
j Radius 90.00
j Radius 90.00
k B+ position M8
n Rotation CR
o Regulator plug PL61
R Total length 185.00

Further information (Alternator)
Blower IF
Pulley SP

Replacing
0124325013 BOSCH
0124325032 BOSCH
0124325150 BOSCH
037903025m VOLKSWAGEN
037903025t VOLKSWAGEN
038903018a VOLKSWAGEN
038903018R VOLKSWAGEN
038903018RX VOLKSWAGEN
047903015h VOLKSWAGEN
11.203.314 ISKRA

UNISTART Price: £164.21

Sorry, this item is out of stock.

The 112274 - Alternator is shown in: Starters & Alternators > Alternators , Automotive > Starters & Alternators.

Fast Delivery - UK & Europe

We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.

You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us.  Replacements & refunds will be dispatched / issued on receipt of the returned items only.

Mfg. Model Engine Size Fuel From To KW HP Volume Cylinders Engine Type Brand Chassis Model Type Series
VW, Passenger Car EU Transporter 2 Gasoline 1990 07 2003 04 62 84 1968 4 AAC Van T4 Transporter
VW, Passenger Car EU Polo 1.4 Gasoline 1999 10 2001 09 44 60 1390 4 AKK Polo
VW, Passenger Car EU Lupo 1 Gasoline 1998 09 2005 07 37 50 999 4 ANV Hatchback Lupo
VW, Passenger Car EU Lupo 1 Gasoline 1998 09 2005 07 37 50 999 4 ALL Hatchback Lupo
VW, Passenger Car EU Lupo 1.4 Gasoline 1999 08 2005 07 74 100 1390 4 16V AFK Hatchback Lupo
VW, Passenger Car EU Polo 1.4 Gasoline 1999 10 2001 09 55 75 1390 4 16V AUA Polo
VW, Passenger Car EU Polo 1 Gasoline 1999 10 2001 09 37 50 999 4 ALD Hatchback Polo
VW, Passenger Car EU Polo 1.4 Gasoline 1999 10 2001 09 44 60 1390 4 AUD Hatchback Polo
VW, Passenger Car EU Polo 1.4 Gasoline 1998 12 2001 09 40 54 1390 4 AKP Estate Polo
VW, Passenger Car EU Lupo 1.6 Gasoline 2000 09 2005 07 92 125 1598 4 GTi AVY Hatchback Lupo
VW, Passenger Car EU Polo 1.4 Gasoline 2003 07 - 55 75 1390 4 BBY Polo
VW, Passenger Car EU Polo 1.4 Gasoline 1999 10 2000 08 44 60 1390 4 ANW Polo
VW, Passenger Car EU Lupo 1.4 Gasoline 1999 08 2005 07 74 100 1390 4 16V AQQ Hatchback Lupo
VW, Passenger Car EU Lupo 1 Gasoline 1998 09 2005 07 37 50 999 4 AUC Hatchback Lupo
VW, Passenger Car EU Lupo 1.4 Gasoline 1998 09 2005 07 55 75 1390 4 AKQ Hatchback Lupo
VW, Passenger Car EU Lupo 1.4 Gasoline 1998 09 2005 07 55 75 1390 4 APE Hatchback Lupo
VW, Passenger Car EU Polo 1.6 Gasoline 1997 05 2001 09 55 75 1598 4 ALM Estate Polo
VW, Passenger Car EU Polo 1.4 Gasoline 1999 10 2001 09 55 75 1390 4 16V AHW Hatchback Polo
VW, Passenger Car EU Polo 1.4 Gasoline 1999 10 2001 09 55 75 1390 4 16V AUA Hatchback Polo
VW, Passenger Car EU Polo 1.4 Gasoline 1999 10 2001 09 55 75 1390 4 16V APE Hatchback Polo
VW, Passenger Car EU Polo 1.4 Gasoline 1999 10 2001 09 74 101 1390 4 16V AUB Hatchback Polo
VW, Passenger Car EU Fox 1.4 Gasoline 2005 04 - 55 75 1390 4 BKR Hatchback Fox
VW, Passenger Car EU Polo 1.4 Gasoline 2001 10 - 74 101 1390 4 16V BBZ Hatchback Polo
VW, Passenger Car EU Polo 1.6 Gasoline 1998 07 2001 09 55 75 1598 4 ALM Polo
VW, Passenger Car EU Lupo 1 Gasoline 1998 09 2005 07 37 50 999 4 ALD Hatchback Lupo
VW, Passenger Car EU Polo 1.4 Gasoline 1997 05 2001 09 44 60 1390 4 ANW Estate Polo
VW, Passenger Car EU Lupo 1.4 Gasoline 2000 05 2005 07 74 100 1390 4 16V AUB Hatchback Lupo
VW, Passenger Car EU Bora 1.6 Gasoline 2000 02 2005 05 77 105 1598 4 16V AUS Estate Bora
VW, Passenger Car EU Polo 1.6 Gasoline 2000 05 2001 09 92 125 1598 4 GTi 16V AVY Hatchback Polo
VW, Passenger Car EU Polo 1.4 Gasoline 1999 10 2001 09 55 75 1390 4 16V APE Polo
VW, Passenger Car EU Polo 1.4 Gasoline 1999 10 2001 09 55 75 1390 4 16V AUA Estate Polo
VW, Passenger Car EU Polo 1.4 Gasoline 1999 10 2001 09 74 101 1390 4 16V AFK Hatchback Polo
VW, Passenger Car EU Polo 1.4 Gasoline 2001 10 - 55 75 1390 4 16V BBY Hatchback Polo
VW, Passenger Car EU Polo 1.4 Gasoline 2001 10 - 55 75 1390 4 16V BKY Hatchback Polo
VW, Passenger Car EU Polo 1.4 Gasoline 2009 06 - 63 85 1390 4 CGGB Hatchback Polo
VW, Passenger Car EU Lupo 1 Gasoline 1998 09 2005 07 37 50 999 4 AER Hatchback Lupo
VW, Passenger Car EU Lupo 1.6 Gasoline 2004 01 2009 12 74 101 1598 4 BLH Hatchback Lupo
VW, Passenger Car EU Polo 1.4 Gasoline 1999 10 2001 09 55 75 1390 4 16V APE Estate Polo
VW, Passenger Car EU Polo 1 Gasoline 1999 10 2001 09 37 50 999 4 AUC Hatchback Polo
VW, Passenger Car EU Polo 1.4 Gasoline 1999 10 2001 09 74 101 1390 4 16V AQQ Hatchback Polo
VW, Passenger Car EU Bora 1.6 Gasoline 2000 02 2005 05 77 105 1598 4 16V BCB Estate Bora
VW, Passenger Car EU Polo 1.4 Gasoline 2003 11 - 101 100 1390 4 BBZ Polo
VW, Passenger Car EU Caddy 1.4 Gasoline 2000 08 2004 01 55 75 1390 4 16V AUA Estate Caddy
VW, Passenger Car EU Polo 1.4 Gasoline 2000 06 2001 09 44 60 1390 4 AUD Polo
VW, Passenger Car EU Caddy 1.4 Gasoline 1995 11 2004 01 44 60 1390 4 AUD Van Caddy
VW, Passenger Car EU Transporter 2 Gasoline 1990 07 2004 03 62 84 1968 4 AAC Platform / Chassis T4 Transporter
VW, Passenger Car EU Lupo 1.4 Gasoline 1999 08 2005 07 74 100 1390 4 16V ANM Hatchback Lupo
VW, Passenger Car EU Polo 1.4 Gasoline 1997 05 2001 09 44 60 1390 4 AKK Estate Polo
VW, Passenger Car EU Polo 1.6 Gasoline 1999 10 2001 09 92 125 1598 4 GTi 16V ARC Hatchback Polo
VW, Passenger Car EU Polo 1.4 Gasoline 1999 10 2001 09 44 60 1390 4 AAK Hatchback Polo
VW, Passenger Car EU Polo 1.4 Gasoline 1999 10 2001 09 40 54 1390 4 AKP Hatchback Polo
VW, Passenger Car EU Polo 1.4 Gasoline 2001 10 2002 04 74 101 1390 4 AUB Hatchback Polo
VW, Passenger Car EU Caddy 1.4 Gasoline 1995 11 2004 01 44 60 1390 4 AUD Estate Caddy
Seat, Passenger Car EU Arosa 1 Gasoline 1997 05 2004 06 37 50 999 4 AER Hatchback Arosa
Seat, Passenger Car EU Arosa 1 Gasoline 1998 01 2004 06 37 50 999 4 AHT Hatchback Arosa
Seat, Passenger Car EU Arosa 1 Gasoline 1997 05 - 37 50 999 4 ANV Hatchback Arosa
Seat, Passenger Car EU Arosa 1 Gasoline 1997 05 - 37 50 999 4 AUC Hatchback Arosa
Seat, Passenger Car EU Arosa 1.4 Gasoline 1997 05 2004 06 44 60 1390 4 AUD Hatchback Arosa
Seat, Passenger Car EU Ibiza 1.4 Gasoline 1999 08 2002 02 44 60 1390 4 ANW Hatchback Ibiza
Seat, Passenger Car EU Ibiza 1.4 Gasoline 1999 08 2002 02 44 60 1390 4 AKK Hatchback Ibiza
Seat, Passenger Car EU Ibiza 1.4 Gasoline 2000 05 2002 02 55 75 1390 4 16V APE Hatchback Ibiza
Seat, Passenger Car EU Cordoba 1.4 Gasoline 2000 05 2002 10 55 75 1390 4 16V APE Hatchback Cordoba
Seat, Passenger Car EU Ibiza 1.4 Gasoline 2008 03 - 63 85 1390 4 CGGB Hatchback Ibiza
Seat, Passenger Car EU Ibiza 1 Gasoline 1999 08 2002 02 37 50 999 4 ANV Hatchback Ibiza
Seat, Passenger Car EU Ibiza 1.4 Gasoline 2008 07 - 63 85 1390 4 CGGB Coupe Ibiza
Seat, Passenger Car EU Arosa 1 Gasoline 1997 05 - 37 50 999 4 ALL Hatchback Arosa
Seat, Passenger Car EU Ibiza 1 Gasoline 2000 05 2002 02 51 69 999 4 16V AST Hatchback Ibiza
Seat, Passenger Car EU Cordoba 1.4 Gasoline 2002 09 - 55 75 1390 4 16V BBY Cordoba
Seat, Passenger Car EU Cordoba 1 Gasoline 1999 06 2002 10 37 50 999 4 ALD Hatchback Cordoba
Seat, Passenger Car EU Cordoba 1 Gasoline 1999 06 2002 10 37 50 999 4 ANV Hatchback Cordoba
Seat, Passenger Car EU Ibiza 1.4 Gasoline 2002 02 - 74 100 1390 4 16V BBZ Hatchback Ibiza
Seat, Passenger Car EU Inca 1.4 Gasoline 2000 04 - 55 75 1390 4 16V AUA Van Inca
Seat, Passenger Car EU Cordoba 1.6 Gasoline 1993 02 1999 06 55 75 1598 4 i ALM Cordoba
Seat, Passenger Car EU Arosa 1.4 Gasoline 2000 01 2004 06 74 100 1390 4 16V AQQ Hatchback Arosa
Seat, Passenger Car EU Ibiza 1.6 Gasoline 1999 08 2002 02 55 75 1598 4 ALM Hatchback Ibiza
Seat, Passenger Car EU Ibiza 1.4 Gasoline 1999 08 2002 02 74 100 1390 4 16V AQQ Hatchback Ibiza
Seat, Passenger Car EU Cordoba 1.4 Gasoline 1999 06 - 44 60 1390 4 ANW Estate Cordoba
Seat, Passenger Car EU Inca 1.4 Gasoline 1995 11 - 44 60 1390 4 i AUD Van Inca
Seat, Passenger Car EU Arosa 1 Gasoline 1997 05 - 37 50 999 4 ALD Hatchback Arosa
Seat, Passenger Car EU Ibiza 1.6 Gasoline 1993 03 1999 08 55 75 1598 4 i ALM Hatchback Ibiza
Seat, Passenger Car EU Cordoba 1.4 Gasoline 1999 06 2002 10 44 60 1390 4 AKK Hatchback Cordoba
Seat, Passenger Car EU Ibiza 1.4 Gasoline 2002 02 - 55 75 1390 4 16V BBY Hatchback Ibiza
Seat, Passenger Car EU Ibiza 1.4 Gasoline 2008 03 - 63 85 1390 4 BXW Hatchback Ibiza
Seat, Passenger Car EU Ibiza 1.4 Gasoline 2008 07 - 63 85 1390 4 BXW Coupe Ibiza
Seat, Passenger Car EU Ibiza 1.4 Gasoline 2010 03 - 63 85 1390 4 CGGB Estate Ibiza
Seat, Passenger Car EU Ibiza 1.6 Gasoline 2003 02 - 74 101 1598 4 BAH Hatchback Ibiza
Seat, Passenger Car EU Ibiza 1 Gasoline 2000 05 2002 02 51 69 999 4 16V AVZ Hatchback Ibiza
Seat, Passenger Car EU Cordoba 1.4 Gasoline 2002 10 - 74 100 1390 4 16V BBZ Cordoba
Seat, Passenger Car EU Arosa 1.4 Gasoline 1997 05 2004 06 44 60 1390 4 ANW Hatchback Arosa
Seat, Passenger Car EU Arosa 1.4 Gasoline 1997 05 2004 06 44 60 1390 4 AKK Hatchback Arosa
Seat, Passenger Car EU Cordoba 1.4 Gasoline 1999 06 2002 10 44 60 1390 4 ANW Hatchback Cordoba
Seat, Passenger Car EU Cordoba 1.4 Gasoline 1999 06 - 44 60 1390 4 AKK Estate Cordoba
Seat, Passenger Car EU Cordoba 1.6 Gasoline 2003 04 - 74 101 1598 4 BAH Cordoba
Seat, Passenger Car EU Ibiza 1 Gasoline 1999 08 2002 02 37 50 999 4 ALD Hatchback Ibiza
Seat, Passenger Car EU Ibiza 1 Gasoline 1999 08 2002 02 37 50 999 4 AUC Hatchback Ibiza
Seat, Passenger Car EU Ibiza 1.4 Gasoline 2002 02 - 74 100 1390 4 16V AUB Hatchback Ibiza
Skoda, Passenger Car EU Roomster 1.4 Gasoline 2006 09 - 63 86 1390 4 CGGB MPV Roomster
Skoda, Passenger Car EU Fabia 1.4 Gasoline 2007 10 - 63 86 1390 4 CGGB Estate Fabia
Skoda, Passenger Car EU Fabia 1.4 Gasoline 2007 10 - 63 86 1390 4 BXW Estate Fabia
Skoda, Passenger Car EU Roomster 1.4 Gasoline 2006 09 - 63 86 1390 4 BXW MPV Roomster
Skoda, Passenger Car EU Fabia 1.4 Gasoline 2007 03 - 63 86 1390 4 BXW Hatchback Fabia
Skoda, Passenger Car EU Fabia 1.4 Gasoline 2007 03 - 63 86 1390 4 CGGB Hatchback Fabia
Skoda, Passenger Car EU Fabia 1.4 Gasoline 2007 06 - 63 86 1390 4 BXW Van Fabia
Skoda, Passenger Car EU Fabia 1.4 Gasoline 2007 06 - 63 86 1390 4 CGGB Van Fabia
