112336 - Starter (112336)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.


Voltage: 12, kW 2.0, Mount. flange 82.50, Drive dist. 15.50, Dist./back 157.00, Dist./front 28.50, No. of teeth 10,11, B+ M8, Gear type GR, Dist. 135.00,
Rotation: CR, No./mount. holes 2 (1), Clutch type Wet,
Drive Type: Steel,
Total Length: 230.00, Oil sealed No, Waterproof No

Electrical specifications (Starter)
Voltage 12
kW 2.0

Physical specifications (Starter)
A Mount. flange 82.50
B Drive dist. 15.50
F Dist./back 157.00
G Dist./front 28.50
H No. of teeth 10,11
I B+ M8
N Gear type GR
O Dist. 135.00
P Rotation CR
R Total length 230.00

Further information (Starter)
No./mount. holes 2 (1)
Clutch type Wet
Drive type Steel
Oil sealed No
Waterproof No

Replacing
228000-0640 DENSO
228000-2120 DENSO
228000-2121 DENSO
228000-2122 DENSO
228000-2123 DENSO
228000-2124 DENSO
228000-2680 DENSO
228000-2682 DENSO
228000-2690 DENSO
228000-6611 DENSO

UNISTART Price: £127.02

Sorry, this item is out of stock.

The 112336 - Starter is shown in: Starters & Alternators > Starters , Automotive > Starters & Alternators.

Fast Delivery - UK & Europe

We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.

You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us.  Replacements & refunds will be dispatched / issued on receipt of the returned items only.

Mfg. Model Engine Size Fuel From To KW HP Volume Cylinders Engine Type Brand Chassis Model Type Series
Toyota, Passenger Car EU Hilux 2.4 Diesel 1992 01 2005 07 59 80 2466 4 Diesel 2L Pick Up Hilux
Toyota, Passenger Car EU Land Cruiser 2.4 Diesel 1990 01 1993 05 66 90 2446 4 TD 2L-T Land Cruiser
Toyota, Passenger Car EU Hiace 2.4 Diesel 1995 08 2006 08 58 79 2446 4 Diesel 2L Bus Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1995 08 2006 08 66 90 2446 4 TD 2L-T Bus Hiace
Toyota, Passenger Car EU Hiace 2.4 Gasoline 1995 08 1998 04 85 115 2438 4 2RZ-E Bus Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1990 02 1995 08 55 75 2446 4 Diesel 2L Van Hiace
Toyota, Passenger Car EU Hilux 2.4 Diesel 1998 08 2002 01 66 90 2446 4 TD 2L-T Pick Up 4WD Hilux
Toyota, Passenger Car EU Hiace 2.4 Diesel 1995 08 2006 08 58 79 2446 4 Diesel 2L Van Hiace
Toyota, Passenger Car EU Dyna 2.4 Diesel 1984 01 1995 05 53 72 2445 Diesel 2L Dyna 100
Toyota, Passenger Car EU Dyna 2.8 Diesel 1985 08 1995 05 58 79 2778 4 Diesel 3L Dyna 150
Toyota, Passenger Car EU Hiace 2.4 Diesel 1995 08 2006 08 61 83 2446 4 Diesel 2L Van Hiace
Toyota, Passenger Car EU Hilux 2.4 Diesel 1995 03 2005 07 58 79 2446 4 Diesel 2L Pick Up Hilux
Toyota, Passenger Car EU Hiace 2.4 Gasoline 1995 08 1998 04 85 116 2438 4 2RZ-E Bus 4WD Hiace
Toyota, Passenger Car EU Land Cruiser 2.4 Diesel 1990 07 1996 05 66 90 2446 4 TD 2L-T Convertible Land Cruiser
Toyota, Passenger Car EU Hiace 2.4 Diesel 1989 08 1995 08 55 75 2446 4 Diesel 2L Bus Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1993 10 1995 08 57 78 2446 4 Diesel 2L Bus Hiace
Toyota, Passenger Car EU Dyna 2.4 Diesel 1995 05 2001 08 55 75 2445 4 Diesel 2L Dyna 100
Toyota, Passenger Car EU Hiace 2.4 Diesel 1995 08 2006 08 66 90 2446 4 TD 2L-T Van Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1995 08 2006 08 66 90 2446 4 TD 2L-T Van 4WD Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1995 08 2006 08 61 83 2446 4 Diesel 2L Platform / Chassis Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1999 07 2006 08 55 75 2446 4 Diesel 2L Platform / Chassis Hiace
Toyota, Passenger cars AO Hilux 2.4 Diesel 1989 08 1995 11 66 90 2446 4 TD 2L-TE 4x4 Hilux
Toyota, Passenger Car EU Dyna 2.4 Diesel 1995 05 2001 08 55 75 2445 4 Diesel 2L Dyna 100
Toyota, Passenger Car EU Hiace 2.4 Diesel 1995 08 2006 08 61 83 2446 4 Diesel 2L Platform / Chassis Hiace
Toyota, Passenger Car EU Hiace 2.4 Diesel 1999 07 2006 08 55 75 2446 4 Diesel 2L Platform / Chassis Hiace
