112472 - Alternator (112472)
Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.
Voltage: 14,
Amp: 100,
Bracket Hole: 10.60, Belt. adj. bracket hole 10.40,
Width/Holder Arm: 28.00, Belt. adj. brackethole pos. 45,
Mount. Bracket Dist.: 75.40,
Pulley Dia.: 53.40,
Pulley Dist.: 61.00,
Grooves/Pulley: 5,
Radius: 93.00,
Radius: 93.00,
B+ Position: M8,
Rotation: CR,
Regulator Plug: or plug PL52,
Blower: IF, Pulley SP,
Total Length: 185.00
Electrical specifications (Alternator) | ||||
| Voltage | 14 | |||
| Amp | 100 | |||
Physical specifications (Alternator) | ||||
| D | Bracket hole 10.60 | |||
| G | Belt. adj. bracket hole 10.40 | |||
| B | Width/holder arm 28.00 | |||
| E | Belt. adj. brackethole pos. 45 | |||
| C | Mount. bracket dist. 75.40 | |||
| H | Pulley dia. 53.40 | |||
| A | Pulley dist. 61.00 | |||
| i | Grooves/pulley 5 | |||
| j | Radius 93.00 | |||
| j | Radius 93.00 | |||
| k | B+ position M8 | |||
| n | Rotation CR | |||
| o | Regulator plug PL52 | |||
| R | Total length 185.00 | |||
Further information (Alternator) | ||||
| Blower | IF | |||
| Pulley | SP | |||
Replacing | ||||
| 2542265 | MOTOROLA | |||
| 2542265 | VALEO | |||
| 2542265A | VALEO | |||
| 2542265B | VALEO | |||
| 2542797 | VALEO | |||
| 2542797A | VALEO | |||
| 2542797B | VALEO | |||
| a13vi234 | VALEO | |||
| GNU2562 | ROVER GROUP | |||
| SG12B080 | VALEO | |||
UNISTART Price: £144.33
Fast Delivery - UK & Europe
We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.
You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us. Replacements & refunds will be dispatched / issued on receipt of the returned items only.
| Mfg. | Model | Engine Size | Fuel | From | To | KW | HP | Volume | Cylinders | Engine Type | Brand | Chassis | Model Type | Series |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MG, Passenger Car EU | ZT | 2 | Diesel | 2002 11 | - | 96 | 131 | 1951 | 4 | CDTi | M47R (204D2) | Estate | ZT- T | |
| MG, Passenger Car EU | ZT | 2 | Diesel | 2002 06 | 2003 09 | 85 | 116 | 1951 | 4 | CDTi | 204D2 | ZT | ||
| MG, Passenger Car EU | ZT | 2 | Diesel | 2002 06 | 2003 09 | 85 | 116 | 1951 | 4 | CDTi | 204D2 | Estate | ZT-T | |
| MG, Passenger Car EU | ZT | 2 | Diesel | 2002 11 | - | 96 | 131 | 1951 | 4 | CDTi | M47R (204D2) | ZT | ||
| Rover, Passenger Car EU | 75 | 2 | Diesel | 2003 02 | - | 96 | 131 | 1951 | 4 | CDTi | 204D2 | 75 | ||
| Rover, Passenger Car EU | 75 | 2 | Diesel | 2001 08 | - | 85 | 115 | 1950 | 4 | CDT | M47R | Estate | 75 | |
| Rover, Passenger Car EU | 75 | 2 | Diesel | 1999 02 | - | 85 | 115 | 1950 | 4 | CDT | M47R | 75 | ||
| Rover, Passenger Car EU | 75 | 2 | Diesel | 2003 02 | - | 96 | 131 | 1951 | 4 | CDTi | 204D2 | Estate | 75 | |
| MG, Passenger Car EU | ZT | 2 | Diesel | 2002 11 | - | 96 | 131 | 1951 | 4 | CDTi | M47R (204D2) | Estate | ZT- T | |
| MG, Passenger Car EU | ZT | 2 | Diesel | 2002 11 | - | 96 | 131 | 1951 | 4 | CDTi | M47R (204D2) | ZT | ||
| Land Rover, Passenger Car EU | Freelander | 2 | Diesel | 2001 03 | 2006 10 | 80 | 109 | 1951 | 4 | TD4 | 204D3 | 4x4 | Freelander | |
| Land Rover, Passenger Car EU | Freelander | 2 | Diesel | 2000 11 | - | 82 | 112 | 1951 | 4 | TD4 | 204D3 | Freelander |
