112718 - Alternator (112718)
Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.
Voltage: 14,
Amp: 100, Terminal W,
Bracket Hole: 8.20, Belt. adj. bracket hole M8,
Width/Holder Arm: 14.00, Belt. adj. brackethole pos. 10,
Mount. Bracket Dist.: 83.80,
Pulley Dia.: 66.90,
Pulley Dist.: 32.00,
Grooves/Pulley: 6,
Radius: 86.00,
Radius: 86.00,
B+ Position: M6,
Rotation: CR,
Regulator Plug: or plug PL70,
Blower: IF, Pulley SP,
Total Length: 189.00
Electrical specifications (Alternator) | ||||
| Voltage | 14 | |||
| Amp | 100 | |||
| Terminal | W | |||
Physical specifications (Alternator) | ||||
| D | Bracket hole 8.20 | |||
| G | Belt. adj. bracket hole M8 | |||
| B | Width/holder arm 14.00 | |||
| E | Belt. adj. brackethole pos. 10 | |||
| C | Mount. bracket dist. 83.80 | |||
| H | Pulley dia. 66.90 | |||
| A | Pulley dist. 32.00 | |||
| i | Grooves/pulley 6 | |||
| j | Radius 86.00 | |||
| j | Radius 86.00 | |||
| k | B+ position M6 | |||
| n | Rotation CR | |||
| o | Regulator plug PL70 | |||
| R | Total length 189.00 | |||
Further information (Alternator) | ||||
| Blower | IF | |||
| Pulley | SP | |||
Replacing | ||||
| 11.203.042 | ISKRA | |||
| 54022443 | LUCAS | |||
| 54022527 | LUCAS | |||
| 63321285 | MAGNETI MARELLI | |||
| 63321346 | MAGNETI MARELLI | |||
| 82003307 | NEW HOLLAND | |||
| 82010242 | NEW HOLLAND | |||
| 8210242 | NEW HOLLAND | |||
| aak5326 | ISKRA | |||
| F0NN10B376BB | FORD | |||
UNISTART Price: £126.19
Fast Delivery - UK & Europe
We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.
You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us. Replacements & refunds will be dispatched / issued on receipt of the returned items only.
| Mfg. | Model | Engine Size | Fuel | From | To | KW | HP | Volume | Cylinders | Engine Type | Brand | Chassis | Model Type | Series |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| New Holland, Agricultural | 8000 | 1995 09 | 2001 12 | 0 | 0 | 0 | Ford | 8000 Series | ||||||
| New Holland, Agricultural | 6600 | 5 | Diesel | 1991 11 | 1998 01 | 0 | 0 | 0 | 4 | 6640 | ||||
| New Holland, Agricultural | 7000 | 5 | Diesel | 1991 11 | 1998 01 | 0 | 0 | 0 | 4 | 7740 | ||||
| New Holland, Agricultural | 7000 | 6.6 | Diesel | 1991 11 | 1998 12 | 0 | 0 | 0 | 6 | 7840 | ||||
| New Holland, Agricultural | 8000 | 7.5 | Diesel | 1991 11 | 1996 12 | 0 | 0 | 0 | 6 | 8240 | ||||
| New Holland, Agricultural | TS | Diesel | 2003 07 | - | 0 | 0 | 0 | TS 115 | ||||||
| New Holland, Agricultural | M | 1995 09 | - | 0 | 0 | 0 | M SERIES | |||||||
| New Holland, Agricultural | 5600 | 4.4 | Diesel | 1991 11 | 1998 01 | 0 | 0 | 0 | 4 | 5640 | ||||
| New Holland, Agricultural | TV | Diesel | 1998 01 | - | 0 | 0 | 0 | 6 | TV 140 | |||||
| New Holland, Agricultural | 8000 | 7.5 | 1991 11 | 1998 07 | 0 | 0 | 0 | 6 | 8340 | |||||
| Ford, Agricultural | 6000 Series | Diesel | 1992 01 | 1997 01 | 0 | 0 | 0 | 6640 | ||||||
| Ford, Agricultural | 8000 Series | Diesel | 1992 01 | 1996 01 | 0 | 0 | 0 | 8240 | ||||||
| Ford, Agricultural | 7000 Series | Diesel | 1992 01 | 1997 01 | 0 | 0 | 0 | 7840 | ||||||
| Ford, Agricultural | 7000 Series | Diesel | 1992 01 | 1997 01 | 0 | 0 | 0 | 7740 | ||||||
| Ford, Agricultural | 5000 Series | Diesel | 1992 01 | 1997 01 | 0 | 0 | 0 | 5640 | ||||||
| Ford, Agricultural | 8000 Series | Diesel | 1992 01 | 1997 01 | 0 | 0 | 0 | 8340 |
