112719 - Alternator (112719)
Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.
Voltage: 14,
Amp: 55,
Bracket Hole: 12.20, Belt. adj. bracket hole 10.80,
Width/Holder Arm: 16.20, Belt. adj. brackethole pos. 60,
Mount. Bracket Dist.: 63.30,
Pulley Dia.: 69.00,
Pulley Dist.: 44.50,
Grooves/Pulley: 1,
Radius: >85,
Radius: 80.00,
B+ Position: M6,
Rotation: CR,
Regulator Plug: or plug PL_NA,
Blower: EF, Pulley P,
Total Length: 159.00, Source Mahle Letrika
Electrical specifications (Alternator) | ||||
| Voltage | 14 | |||
| Amp | 55 | |||
Physical specifications (Alternator) | ||||
| D | Bracket hole 12.20 | |||
| G | Belt. adj. bracket hole 10.80 | |||
| B | Width/holder arm 16.20 | |||
| E | Belt. adj. brackethole pos. 60 | |||
| C | Mount. bracket dist. 63.30 | |||
| H | Pulley dia. 69.00 | |||
| A | Pulley dist. 44.50 | |||
| i | Grooves/pulley 1 | |||
| j | Radius >85 | |||
| j | Radius 80.00 | |||
| k | B+ position M6 | |||
| n | Rotation CR | |||
| o | Regulator plug PL_NA | |||
| R | Total length 159.00 | |||
| Source | Mahle Letrika | |||
Further information (Alternator) | ||||
| Blower | EF | |||
| Pulley | P | |||
Replacing | ||||
| 063321112010 | MAKO | |||
| 063321112020 | MAKO | |||
| 063395575000 | MAKO | |||
| 13470 | EFEL | |||
| 46445102 | FIAT | |||
| 46446292 | FIAT | |||
| 63320003 | MAGNETI MARELLI | |||
| 63320007 | MAGNETI MARELLI | |||
| 63320008 | MAGNETI MARELLI | |||
| 63320031 | MAGNETI MARELLI | |||
UNISTART Price: £148.34
Fast Delivery - UK & Europe
We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.
You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us. Replacements & refunds will be dispatched / issued on receipt of the returned items only.
| Mfg. | Model | Engine Size | Fuel | From | To | KW | HP | Volume | Cylinders | Engine Type | Brand | Chassis | Model Type | Series |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Fiat, Passenger Car EU | Uno | 1.7 | Diesel | 1986 07 | 1989 08 | 44 | 60 | 1698 | 4 | Diesel | 149B3.000 | Hatchback | Uno | |
| Fiat, Passenger Car EU | Tipo | 1.7 | Diesel | 1988 01 | 1994 10 | 43 | 58 | 1697 | 4 | Diesel | 149B4.000 | Hatchback | Tipo | |
| Fiat, Passenger Car EU | Uno | 1.9 | Diesel | 1989 09 | 1994 03 | 44 | 60 | 1929 | 4 | Diesel | 149B5.046 | Hatchback | Uno | |
| Fiat, Passenger Car EU | Fiorino | 1.7 | Diesel | 1988 05 | 1999 10 | 44 | 60 | 1698 | 4 | Diesel | 149B3.000 | Pick Up | Fiorino | |
| Fiat, Passenger Car EU | Fiorino | 1.7 | Diesel | 1988 05 | 1996 10 | 42 | 57 | 1697 | 4 | Diesel | 146B2.000 | Van | Fiorino | |
| Fiat, Passenger Car EU | Tipo | 1.7 | Diesel | 1988 01 | 1995 10 | 45 | 61 | 1697 | 4 | Diesel | 149B4.000 | Hatchback | Tipo | |
| Fiat, Passenger Car EU | Fiorino | 1.7 | Diesel | 1993 10 | 1999 10 | 42 | 57 | 1697 | 4 | Diesel | 146B2.000 | Pick Up | Fiorino | |
| Fiat, Passenger Car EU | Fiorino | 1.7 | Diesel | 1987 12 | 1990 12 | 44 | 60 | 1698 | 4 | Diesel | 149B3.000 | Van | Fiorino | |
| Fiat, Passenger Car EU | Fiorino | 1.7 | Diesel | 1988 05 | 2000 05 | 44 | 60 | 1698 | 4 | Diesel | 149B3.000 | Van | Fiorino | |
| Fiat, Passenger Car EU | Uno | 1.7 | Diesel | 1989 09 | 1993 12 | 42 | 57 | 1698 | 4 | Diesel | 146B2.000 | Hatchback | Uno | |
| Fiat, Passenger Car EU | Fiorino | 1.7 | Diesel | 1997 01 | 2001 05 | 46 | 63 | 1698 | 4 | TD | 146D7.000 | Pick Up | Fiorino | |
| Fiat, Passenger Car EU | Elba | 1.7 | Diesel | 1989 04 | 1996 12 | 43 | 58 | 1698 | 4 | Diesel | 146B2.000 | Estate | Elba | |
| Fiat, Passenger Car EU | Fiorino | 1.7 | Diesel | 1988 01 | 1993 10 | 42 | 57 | 1697 | 4 | Diesel | 149B2.000 | Van | Fiorino | |
| Fiat, Passenger Car EU | Uno | 1.4 | Diesel | 1986 10 | 1990 10 | 52 | 71 | 1367 | 4 | TD | 146B3.000 | Hatchback | Uno | |
| Lancia, Passenger Car EU | Prisma | 1.9 | Diesel | 1983 01 | 1992 02 | 48 | 65 | 1911 | 4 | Diesel | 831D.000 | Prisma | ||
| Fiat, Passenger Car EU | Uno | 1.7 | Diesel | 1986 07 | 1989 08 | 44 | 60 | 1698 | 4 | Diesel | 149B3.000 | Hatchback | Uno | |
| Fiat, Passenger Car EU | Uno | 1.9 | Diesel | 1989 09 | 1994 03 | 44 | 60 | 1929 | 4 | Diesel | 149B5.046 | Hatchback | Uno | |
| Fiat, Passenger Car EU | Fiorino | 1.7 | Diesel | 1987 12 | 1990 12 | 44 | 60 | 1698 | 4 | Diesel | 149B3.000 | Van | Fiorino | |
| Fiat, Passenger Car EU | Fiorino | 1.7 | Diesel | 1997 01 | 2001 05 | 46 | 63 | 1698 | 4 | TD | 146D7.000 | Pick Up | Fiorino | |
| Fiat, Passenger Car EU | Elba | 1.7 | Diesel | 1989 04 | 1996 12 | 43 | 58 | 1698 | 4 | Diesel | 146B2.000 | Estate | Elba | |
| Fiat, Passenger Car EU | Uno | 1.4 | Diesel | 1986 10 | 1990 10 | 52 | 71 | 1367 | 4 | TD | 146B3.000 | Hatchback | Uno |
