112734 - Alternator (112734)

Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.


Voltage: 14,
Amp: 80,
Bracket Hole: 10.20, Belt. adj. bracket hole 10.20,
Width/Holder Arm: 56.00, Belt. adj. brackethole pos. 10,
Pulley Dia.: 49.80,
Pulley Dist.: 91.50,
Grooves/Pulley: 6,
Radius: 90.00,
Radius: 90.00,
B+ Position: M8,
Rotation: CR,
Regulator Plug: or plug PL_NA,
Blower: EF, Pulley SP,
Total Length: 188.00

Electrical specifications (Alternator)
Voltage 14
Amp 80

Physical specifications (Alternator)
D Bracket hole 10.20
G Belt. adj. bracket hole 10.20
B Width/holder arm 56.00
E Belt. adj. brackethole pos. 10
H Pulley dia. 49.80
A Pulley dist. 91.50
i Grooves/pulley 6
j Radius 90.00
j Radius 90.00
k B+ position M8
n Rotation CR
o Regulator plug PL_NA
R Total length 188.00

Further information (Alternator)
Blower EF
Pulley SP

Replacing
0071546702 MERCEDES BENZ
0071546802 MERCEDES BENZ
0120469744 BOSCH
0120469745 BOSCH
0120469746 BOSCH
0120469811 BOSCH
0120469812 BOSCH
0120469894 BOSCH
0120469896 BOSCH
0120469897 BOSCH

UNISTART Price: £118.12

Sorry, this item is out of stock.

The 112734 - Alternator is shown in: Starters & Alternators > Alternators , Automotive > Starters & Alternators , Trucks, Trailers and Buses > Starters & Alternators.

Fast Delivery - UK & Europe

We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.

You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us.  Replacements & refunds will be dispatched / issued on receipt of the returned items only.

Mfg. Model Engine Size Fuel From To KW HP Volume Cylinders Engine Type Brand Chassis Model Type Series
Mercedes-Benz, Passenger Car EU 300 3 Gasoline 1986 09 1992 02 138 188 2960 6 M103.983 4 Matic 300 E
Mercedes-Benz, Passenger Car EU 300 2.9 Gasoline 1986 01 1991 06 132 180 2960 6 M103.981 300 SE
Mercedes-Benz, Passenger Car EU 300 2.9 Gasoline 1985 09 1989 12 138 188 2960 6 M103.981 300 SE
Mercedes-Benz, Passenger Car EU 210 2.9 Diesel 1988 10 1996 02 70 95 2874 5 Diesel OM602.940 Van 210
Mercedes-Benz, Passenger Car EU 210 2.9 Diesel 1988 11 1996 02 72 98 2874 5 Diesel OM602.940 Bus 210
Mercedes-Benz, Passenger Car EU 300 3 Gasoline 1993 06 1996 06 132 180 2960 6 M103.985 Estate 4 Matic E 300
Mercedes-Benz, Passenger Car EU 310 2.9 Diesel 1989 06 1996 02 70 95 2874 5 Diesel OM602.940 Van 310
Mercedes-Benz, Passenger Car EU 308 2.3 Diesel 1990 05 1996 02 58 79 2299 4 Diesel OM601.940 Bus 308
Mercedes-Benz, Passenger Car EU 4t 2.9 Diesel 1988 11 1995 06 70 95 2874 5 Diesel OM602.940 Twin Cab 410
Mercedes-Benz, Passenger Car EU 4t 2.3 Diesel 1988 11 1995 06 58 79 2299 4 Diesel OM601.940 Platform / Chassis 408
Mercedes-Benz, Passenger Car EU 300 3 Gasoline 1993 06 1996 06 162 220 2960 6 M104.980 Estate E 300 TE-24 AMG
Mercedes-Benz, Passenger Car EU 260 2.5 Gasoline 1985 09 1991 06 122 166 2597 6 M103.941 260 SE
Mercedes-Benz, Passenger Car EU 300 2.9 Gasoline 1986 01 1991 06 132 180 2960 6 M103.981 300 SEL
Mercedes-Benz, Passenger Car EU 300 2.9 Gasoline 1985 09 1989 12 138 188 2960 6 M103.981 300 SEL
Mercedes-Benz, Passenger Car EU 208 2.3 Diesel 1988 11 1996 02 58 79 2299 4 Diesel OM601.940 Van 208
Mercedes-Benz, Passenger Car EU 210 2.9 Diesel 1988 10 1996 02 72 98 2874 5 Diesel OM602.940 Van 210
Mercedes-Benz, Passenger Car EU 260 2.6 Gasoline 1985 09 1989 12 122 166 2597 6 M103.940 Estate 260 E
Mercedes-Benz, Passenger Car EU 260 2.6 Gasoline 1986 09 1992 08 118 160 2597 6 M103.943 4 Matic 260 E
Mercedes-Benz, Passenger Car EU 300 3 Gasoline 1986 09 1993 06 132 180 2960 6 M103.985 4 Matic 300 E
Mercedes-Benz, Passenger Car EU 308 2.3 Diesel 1989 06 1996 02 60 82 2299 4 Diesel OM601.940 Platform / Chassis 308
Mercedes-Benz, Passenger Car EU 5t 2.3 Diesel 1989 03 1994 12 58 79 2299 4 Diesel OM601.941 Dump Truck 508
Mercedes-Benz, Passenger Car EU 5t 2.3 Gasoline 1986 04 1994 12 70 95 2299 4 M102.946 Twin Cab 510
Mercedes-Benz, Passenger Car EU 4t 2.3 Diesel 1988 11 1995 06 58 79 2299 4 Diesel OM601.940 Twin Cab 408
Mercedes-Benz, Passenger Car EU 4t 2.9 Diesel 1988 11 1995 06 70 95 2874 5 Diesel OM602.940 Platform / Chassis 410
Mercedes-Benz, Passenger Car EU 4t 2.3 Gasoline 1982 08 1995 06 70 95 2298 4 M102.942 Platform / Chassis 410
Mercedes-Benz, Passenger Car EU 5t 2.3 Gasoline 1986 04 1994 12 70 95 2299 4 M102.946 Platform / Chassis 510
Mercedes-Benz, Passenger Car EU 260 2.5 Gasoline 1985 09 1991 06 118 160 2597 6 M103.941 260 SE
Mercedes-Benz, Passenger Car EU 210 2.9 Diesel 1988 11 1996 02 70 95 2874 5 Diesel OM602.940 Platform / Chassis 210
Mercedes-Benz, Passenger Car EU 310 2.9 Diesel 1989 06 1996 02 72 98 2874 5 Diesel OM602.940 Van 310
Mercedes-Benz, Passenger Car EU 210 2.3 Gasoline 1982 07 1990 01 70 95 2298 4 M102.942 Bus 210
Mercedes-Benz, Passenger Car EU 208 2.3 Diesel 1988 10 1996 02 58 79 2299 4 Diesel OM601.940 Bus 208
Mercedes-Benz, Passenger Car EU 208 2.3 Diesel 1988 10 1996 02 60 82 2299 4 Diesel OM601.940 Bus 208
Mercedes-Benz, Passenger Car EU 210 2.9 Diesel 1988 11 1996 02 70 95 2874 5 Diesel OM602.940 Bus 210
Mercedes-Benz, Passenger Car EU 310 2.9 Diesel 1990 06 1996 02 72 98 2874 5 Diesel OM602.940 Bus 310
Mercedes-Benz, Passenger Car EU 260 2.6 Gasoline 1985 09 1992 08 118 160 2597 6 M103.940 260 E
Mercedes-Benz, Passenger Car EU 260 2.6 Gasoline 1985 09 1989 12 122 166 2597 6 M103.940 260 E
Mercedes-Benz, Passenger Car EU 300 3 Gasoline 1985 06 1992 08 138 188 2960 6 M103.983 300 E
Mercedes-Benz, Passenger Car EU 210 2.3 Gasoline 1977 04 1989 10 70 95 2298 4 M102.942 Platform / Chassis 210
Mercedes-Benz, Passenger Car EU 310 2.9 Diesel 1989 06 1996 02 72 98 2874 5 Diesel OM602.940 Platform / Chassis 310
Mercedes-Benz, Passenger Car EU 4t 2.3 Gasoline 1982 08 1995 06 70 95 2298 4 M102.945 Platform / Chassis 410
Mercedes-Benz, Passenger Car EU 300 3 Gasoline 1988 09 1992 08 170 231 2960 6 M104.980 300 E-24
Mercedes-Benz, Passenger Car EU 190 2.6 Gasoline 1986 09 1989 12 122 166 2597 6 M103.942 190 E
Mercedes-Benz, Passenger Car EU 190 2.6 Gasoline 1986 09 1993 08 118 160 2597 6 M103.942 190 E
Mercedes-Benz, Passenger Car EU 260 2.6 Gasoline 1986 12 1989 12 122 166 2597 6 M103.940 4 Matic 260 E
Mercedes-Benz, Passenger Car EU 208 2.3 Diesel 1988 11 1996 02 58 79 2299 4 Diesel OM601.940 Platform / Chassis 208
Mercedes-Benz, Passenger Car EU 308 2.3 Diesel 1989 06 1996 02 58 79 2299 4 Diesel OM601.940 Platform / Chassis 308
Mercedes-Benz, Passenger Car EU 308 2.3 Diesel 1989 06 1996 02 60 82 2299 4 Diesel OM601.940 Bus 308
Mercedes-Benz, Passenger Car EU 210 2.3 Gasoline 1977 04 1989 10 63 86 2307 4 M115.955 Platform / Chassis 210
Mercedes-Benz, Passenger Car EU 308 2.3 Diesel 1989 06 1996 02 60 82 2299 4 Diesel OM601.940 Van 308
Mercedes-Benz, Passenger Car EU T1 2.3 Gasoline 1982 01 1994 12 70 95 2299 4 M102.942 Platform / Chassis T1
Mercedes-Benz, Passenger Car EU 4t 2.3 Gasoline 1982 08 1995 06 70 95 2298 4 M102.942 Twin Cab 410
Mercedes-Benz, Passenger Car EU 4t 2.3 Gasoline 1982 08 1995 06 70 95 2298 4 M102.945 Twin Cab 410
Mercedes-Benz, Passenger Car EU 5t 2.3 Diesel 1989 03 1994 12 58 79 2299 4 Diesel OM601.941 Twin Cab 508
Mercedes-Benz, Passenger Car EU 210 2.9 Diesel 1988 11 1996 02 72 98 2874 5 Diesel OM602.940 Platform / Chassis 210
Mercedes-Benz, Passenger Car EU 210 2.3 Gasoline 1989 05 1996 02 77 105 2298 4 M102.945 Van 210
Mercedes-Benz, Passenger Car EU 208 2.3 Diesel 1988 10 1996 02 60 82 2299 4 Diesel OM601.940 Van 208
Mercedes-Benz, Passenger Car EU 310 2.9 Diesel 1989 06 1996 02 70 95 2874 5 Diesel OM602.940 Bus 310
Mercedes-Benz, Passenger Car EU 300 3 Gasoline 1985 08 1992 08 132 180 2960 6 M103.983 300 E
Mercedes-Benz, Passenger Car EU 210 2.3 Gasoline 1982 07 1996 02 70 95 2298 4 M102.942 Van 210
Mercedes-Benz, Passenger Car EU 310 2.9 Diesel 1989 06 1996 02 70 95 2874 5 Diesel OM602.940 Platform / Chassis 310
Mercedes-Benz, Passenger cars US 300 3 Gasoline 1990 01 1993 01 0 0 2962 L6 4 Matic 300 E
Mercedes-Benz, Passenger cars US 300 2.6 Gasoline 1990 01 1992 01 0 0 2599 L6 300 E
Mercedes-Benz, Passenger cars US 350 3.4 Diesel 1990 01 1991 01 0 0 3449 L6 Turbo 350 SDL
Mercedes-Benz, Passenger cars US 300 3 Gasoline 1990 01 1993 01 0 0 2962 L6 4 Matic 300 TE
Mercedes-Benz, Passenger cars US 350 3.4 Diesel 1991 01 1991 01 0 0 3449 L6 Turbo 350 SD
Mercedes-Benz, Trucks EU O 100 2.9 Diesel 1994 01 - 72 98 2974 5 Diesel OM602.940 Bus O 100
