113336 - Alternator (113336)
Not what you're looking for? Click Here to return to the category page. For detailed Servicing data, click on the Servicing tab at the foot of the page.
Voltage: 14,
Amp: 120,
Bracket Hole: 12.30, Belt. adj. bracket hole 10.60,
Width/Holder Arm: 22.60, Belt. adj. brackethole pos. 3,
Mount. Bracket Dist.: 54.80,
Pulley Dia.: 61.50,
Pulley Dist.: 44.00,
Grooves/Pulley: 6,
Radius: 90.00,
Radius: 90.00,
B+ Position: M8,
Rotation: CR,
Blower: IF, Pulley SP/FW,
Total Length: 204.00
Electrical specifications (Alternator) | ||||
| Voltage | 14 | |||
| Amp | 120 | |||
Physical specifications (Alternator) | ||||
| D | Bracket hole 12.30 | |||
| G | Belt. adj. bracket hole 10.60 | |||
| B | Width/holder arm 22.60 | |||
| E | Belt. adj. brackethole pos. 3 | |||
| C | Mount. bracket dist. 54.80 | |||
| H | Pulley dia. 61.50 | |||
| A | Pulley dist. 44.00 | |||
| i | Grooves/pulley 6 | |||
| j | Radius 90.00 | |||
| j | Radius 90.00 | |||
| k | B+ position M8 | |||
| n | Rotation CR | |||
| R | Total length 204.00 | |||
Further information (Alternator) | ||||
| Blower | IF | |||
| Pulley | SP/FW | |||
Replacing | ||||
| 112386 | CARGO | |||
| 46543023 | FIAT | |||
| 46748353 | FIAT | |||
| 46809068 | FIAT | |||
| 63321414 | MAGNETI MARELLI | |||
| 63321491 | MAGNETI MARELLI | |||
| 63321497 | MAGNETI MARELLI | |||
| 63321501 | MAGNETI MARELLI | |||
| 63321507 | MAGNETI MARELLI | |||
| 63321804 | MAGNETI MARELLI | |||
UNISTART Price: £158.41
Fast Delivery - UK & Europe
We happily accept returns within 14 days from date of delivery. All returns must be received in the same condition and packaging we sent them. Postage charges will not be refunded on unwanted products.
You are solely responsible for ensuring the goods are returned to us. We will not be liable for returns that are lost in the post or lost for any other reason. If a product arrives damaged we will advise the customer how to return the item with all return costs covered by us. Replacements & refunds will be dispatched / issued on receipt of the returned items only.
| Mfg. | Model | Engine Size | Fuel | From | To | KW | HP | Volume | Cylinders | Engine Type | Brand | Chassis | Model Type | Series |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Lancia, Passenger Car EU | Kappa | 2.4 | Diesel | 1996 07 | 2001 10 | 91 | 124 | 2387 | 5 | TD | 838A3.000 | Estate | Kappa | |
| Lancia, Passenger Car EU | Lybra | 2.4 | Diesel | 2002 05 | - | 110 | 150 | 2387 | 5 | JTD | 841C.000 | Lybra | ||
| Lancia, Passenger Car EU | Lybra | 2.4 | Diesel | 2002 05 | - | 110 | 150 | 2387 | 5 | JTD | 841C.000 | Estate | Lybra | |
| Lancia, Passenger Car EU | Lybra | 1.9 | Diesel | 2001 05 | - | 85 | 116 | 1910 | 4 | JTD | 937A2.000 | Lybra | ||
| Lancia, Passenger Car EU | Lybra | 2.4 | Diesel | 2000 09 | 2002 05 | 103 | 140 | 2387 | 5 | JTD | 839A6.000 | Lybra | ||
| Lancia, Passenger Car EU | Lybra | 2.4 | Diesel | 1999 07 | 2000 09 | 99 | 135 | 2387 | 5 | JTD | 839A5.000 | Lybra | ||
| Lancia, Passenger Car EU | Lybra | 1.9 | Diesel | 2000 09 | 2001 05 | 81 | 110 | 1910 | 4 | JTD | AR37101 | Lybra | ||
| Lancia, Passenger Car EU | Lybra | 1.9 | Diesel | 2000 09 | 2001 05 | 81 | 110 | 1910 | 4 | JTD | AR37101 | Estate | SW | Lybra |
| Lancia, Passenger Car EU | Lybra | 1.9 | Diesel | 2001 05 | - | 85 | 116 | 1910 | 4 | JTD | 937A2.000 | Estate | Lybra | |
| Lancia, Passenger Car EU | Lybra | 2.4 | Diesel | 1999 07 | 2000 09 | 99 | 135 | 2387 | 5 | JTD | AR32501 | Lybra | ||
| Lancia, Passenger Car EU | Lybra | 1.9 | Diesel | 1999 07 | 2000 09 | 77 | 105 | 1910 | 4 | JTD | AR32302 | Estate | Lybra | |
| Lancia, Passenger Car EU | Lybra | 2.4 | Diesel | 2000 09 | - | 103 | 140 | 2387 | 5 | JTD | 839A6.000 | Estate | SW | Lybra |
| Lancia, Passenger Car EU | Lybra | 2.4 | Diesel | 1999 10 | 2000 09 | 99 | 135 | 2387 | 5 | JTD | AR32501 | Estate | Lybra | |
| Lancia, Passenger Car EU | Lybra | 1.9 | Diesel | 1999 07 | 2000 09 | 77 | 105 | 1910 | 4 | JTD | AR32302 | Lybra | ||
| Lancia, Passenger Car EU | Lybra | 2.4 | Diesel | 1999 10 | 2000 09 | 99 | 135 | 2387 | 5 | JTD | 839A5.000 | Estate | Lybra | |
| Lancia, Passenger Car EU | Musa | 1.9 | Diesel | 2004 10 | - | 74 | 101 | 1910 | 4 | Multijet | 188B2.000 | MPV | Musa | |
| Fiat, Passenger Car EU | Brava | 1.9 | Diesel | 1998 12 | 2001 10 | 77 | 105 | 1910 | 4 | JTD | 182B4.000 | Hatchback | Brava | |
| Fiat, Passenger Car EU | Multipla | 1.9 | Diesel | 2001 03 | 2002 07 | 81 | 110 | 1910 | 4 | JTD | 186A6.000 | MPV | Multipla | |
| Fiat, Passenger Car EU | Stilo | 1.8 | Gasoline | 2001 10 | - | 98 | 133 | 1747 | 4 | 16V | 192A4.000 | Hatchback | Stilo | |
| Fiat, Passenger Car EU | Idea | 1.9 | Diesel | 2004 01 | - | 74 | 101 | 1910 | 4 | JTD | 188B2.000 | MPV | Idea | |
| Fiat, Passenger Car EU | Marengo | 1.9 | Diesel | 2000 08 | 2002 09 | 81 | 110 | 1910 | 4 | JTD | 186A6.000 | Estate | Marengo | |
| Fiat, Passenger Car EU | Punto | 1.9 | Diesel | 1999 09 | - | 44 | 60 | 1910 | 4 | Diesel | 188A3.000 | Hatchback | Punto | |
| Fiat, Passenger Car EU | Marea | 1.9 | Diesel | 2001 01 | - | 81 | 110 | 1910 | 4 | JTD | 186A6.000 | Marea | ||
| Fiat, Passenger Car EU | Stilo | 1.9 | Diesel | 2002 02 | - | 59 | 80 | 1910 | 4 | JTD | 192A3.000 | Hatchback | Stilo | |
| Fiat, Passenger Car EU | Stilo | 1.9 | Diesel | 2001 10 | - | 85 | 115 | 1910 | 4 | JTD | 192A1.000 | Hatchback | Stilo | |
| Fiat, Passenger Car EU | Brava | 1.9 | Diesel | 2000 09 | 2001 10 | 74 | 100 | 1910 | 4 | JTD | 182B9.000 | Hatchback | Brava | |
| Fiat, Passenger Car EU | Bravo | 1.9 | Diesel | 1998 12 | 2001 10 | 77 | 105 | 1910 | 4 | JTD | 182B4.000 | Hatchback | Bravo | |
| Fiat, Passenger Car EU | Bravo | 1.9 | Diesel | 2000 09 | 2001 10 | 74 | 100 | 1910 | 4 | JTD | 182B9.000 | Hatchback | Bravo | |
| Fiat, Passenger Car EU | Bravo | 1.9 | Diesel | 2006 11 | - | 85 | 116 | 1910 | 4 | Multijet | 192A1.000 | Hatchback | Bravo | |
| Fiat, Passenger Car EU | Marea | 1.9 | Diesel | 2001 01 | - | 81 | 110 | 1910 | 4 | JTD | 186A6.000 | Estate | Marea | |
| Fiat, Passenger Car EU | Stilo | 2.4 | Gasoline | 2001 10 | - | 125 | 170 | 2446 | 5 | 20V | 192A2.000 | Hatchback | Stilo | |
| Alfa Romeo, Passenger Car EU | Alfa 166 | 2.4 | Diesel | 2003 10 | 2007 06 | 120 | 163 | 2387 | 5 | JTD | 841M.000 | Alfa 166 | ||
| Alfa Romeo, Passenger Car EU | Alfa 166 | 2.4 | Diesel | 2003 10 | 2007 06 | 120 | 163 | 2387 | 5 | JTD | 841N.000 | Alfa 166 |
